Installation and User's Guide

We value your feedback!

Your input helps to create even better

products and experiences.

Share the warmth and leave a review.

dimplex.com/sharethewarmth

@DimplexNorthAmerica

IMPORTANT SAFETY INFORMATION:

Read this manual first before attempting to install or use this electric fireplace. Always comply with the

warnings and safety instructions contained in this manual to prevent personal injury or property damage.

To view the full line of Dimplex products, visit www.dimplex.com

7216940100R00

Aura

Model

3STEP-RGB-AM

Need help?

Do you have a question about the Optimyst Aura and is the answer not in the manual?

Questions and answers

Summary of Contents for Dimplex Optimyst Aura

Page 1 Read this manual first before attempting to install or use this electric fireplace. Always comply with the warnings and safety instructions contained in this manual to prevent personal injury or property damage. To view the full line of Dimplex products, visit www.dimplex.com 7216940100R00...
Page 2 Procedures and techniques techniques that are which, if not carefully which, if not carefully followed, considered important followed, will result in will expose the user to the risk enough to emphasize. damage to the equipment. of fire, serious injury, or death. www.dimplex.com...
Page 3 If you have questions regarding the operation of this product or if you require service, before returning this product to the place of purchase. For technical support, contact us at: www .dimplex .com/support Toll-Free 1-888-346-7539 Please have your model number and product serial number ready.
Page 4 ⑱ Regular cleaning and maintenance is required to contact Glen Dimplex Americas Technical ensure safe and correct operation. Service at 1-888-346-7539. ! NOTE: Changes or modifications not ⑦...
Page 5 IMPORTANT INSTRUCTIONS FCC Compliance WARNING: This product can expose you to chemicals including nickel which is known to CAUTION: This unit has been tested and found the State of California to cause cancer. For more to comply with the limits for Class B digital information, visit www.P65Warnings.ca.gov device, pursuant to part 15 of the FCC Rules.
Page 6 Electrical Rating Voltage: 120 V (3-Wire) Power: 1275 W UL Listing File Number: E71416 Model Reference 500003866 3STEP-RGB-AM 6914230100 Product Dimensions " 747 mm Two-sided 30" Three-sided " 762 mm 391 mm " Single-sided 732 mm " 290 mm www.dimplex.com...
Page 7 Installation Optimyst components Refillable water tank Top cover Transducer Water reservoir Optimyst features antimicrobial technology to inhibit the growth of bacteria by up to 99.99% (tested to ISO 22196 standard.) Regular cleaning and maintenance is required. Water quality • Normal clean tap water should be used. •...
Page 8 This electrical appliance is NOT watertight. To prevent electric shock, it must be installed as to prevent water from entering unit, or installed away from showers, tubs, etc. Never locate fireplace where it may fall into a bathtub or other water container. www.dimplex.com...
Page 9 Installation CAUTION: Do not put water in the unit until it is secured Optional step: remove the side panels (ONLY for open-sided installation) 1. Using the suction cups, lift the front glass upwards and then down and out to remove it. 2.
Page 10 Failure to do so will result in poor flame performance and damage to the fireplace NOTE: Wiring connections are located at the back of the firebox, in the bottom left corner. Install mounting brackets Install the mounting brackets to the firebox with the black screws provided. www.dimplex.com...
Page 11 Installation Connect power supply WARNING: Use the appropriate wire to meet CAUTION: A dedicated, properly fused 15 local and national electrical codes for rated Amp circuit is recommended, rated for 120 V. power consumption. A dedicated circuit will be required if, after installation, the circuit breaker trips or fuse blows on a regular basis when the heater is WARNING: The installation of the electric...
Page 12 CAUTION: Ensure air intake requirements are met and that finishing materials do not obstruct airflow. > 16 in > 100 cm NOTE: The fireplace trim is designed to be installed with 1/2" drywall or cement board. Other finishing materials can be used. www.dimplex.com...
Page 13 Installation Fill the water tank Allow the water reservoir to fill fully before switching on the product. Close the drawer when filled. Install batteries in remote control The remote control is supplied with two AA batteries in a bag. Lift off the battery cover on the back of the remote control and insert the batteries taking note of the polarity.
Page 14 The fan can be switched to High or Low speed setting, depending on flame intensity. Power switch Note: This switch must be in the ‘ON’ ( I ) position for each appliance to operate Control panel: Open the drawer to access the control panel. www.dimplex.com...
Page 15 Operation Remote Control Operation Display Screen ‘Menu’ Button ‘Back’ Button ‘Advance’ Button(ADV) ‘Up and Down’ Arrows ‘Enter’ Button (Press to Activate the Remote) Navigation To use the functions, press Enter and use the arrows until the desired selection is flashing. Press to confirm selection.
Page 16 4. Press to set the Day, press 5. Press to set the Month, press 6. Press to set the Year, press 7. Press to select ON/OFF for the Daylight saving time, press Enter to confirm and returns to home screen. www.dimplex.com...
Page 17 Operation This features will allow the product to turn on or off automatically at scheduled times. Four times slots are available throughout the day and these can be customised for each day of the week. To toggle the the timer schedule on or off, navigate to .
Page 18 2. Refill the water tank using filtered/decalcified water only. 3. The tank can then be replaced on top of the water reservoir. 4. If the product was not switched into standby mode after experiencing low later, the product will restart automatically after about 20 seconds of refilling. www.dimplex.com...
Page 19 If cleaning does not improve the performance of the flame effect, replacement of the transducer may be required. This unit comes with replacement transducers. Additional transducers may be purchased at www.dimplex.com/replacement-parts (9601210100RP). NOTE: To remove the transducer, release the retaining tab in the water reservoir and remove transducer.
Page 20 8 product. See “Filling the Water been exceeded seconds Tanks” above. Product will not operate. LEDs Switch off the product and the water continuously blink once every 8 Overflow Detection supply. Contact your dealer for seconds assistance. www.dimplex.com...
Page 21 Troubleshooting Problem Cause Solution Transducer not operating correctly Check operation of transducer Transducer is dirty Clean water reservoir and transducer Switch off product, take nozzle Transducer is not sitting correctly in off water reservoir and ensure transducer is fitted in water reservoir water reservoir correctly Little or no mist generation...
Page 22 Wiring Diagram EXTRACTOR FAN ELEMENT ELEMENT HEATER MOTOR 06.01.001.539 Drawing No. 3STEP-RGB-AM烟雾发生器 3STEP-RGB-AM烟雾发生器 06.01.001.540 www.dimplex.com...
Page 23 OPTI-MYST AURA™ 2-YEAR LIMITED WARRANTY charge. If Glen Dimplex Americas is unable to repair or Section 1 Products to which this Limited Warranty replace such product or part, or if repair or replacement...
Page 24 For additional information, visit www .flame-connect .com Available in the App Store and Google Play 1-888-346-7539 | www.dimplex.com In keeping with our policy of continuous product improvement, we reserve the right to make changes without notice. © 2024 Glen Dimplex Americas...
