Supero 2122TG-HIBQRF User Manual

A+ server
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S
UPER
®
A+ SERVER
2122TG-HIBQRF/HTRF
USER'S MANUAL
Revision 1.0c

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2122TG-HIBQRF and is the answer not in the manual?

Questions and answers

Related Manuals for Supero 2122TG-HIBQRF

Summary of Contents for Supero 2122TG-HIBQRF

  • Page 1 UPER ® A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Revision 1.0c...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.
  • Page 3 Chapter 2: Server Installation This chapter describes the steps necessary to install the A+ Server 2122TG-HIBQRF/HTRF into a rack and check out the server configuration prior to powering up the system. If your server was ordered without processor and memory components, this chapter will refer you to the appropriate sections of the manual for their installation.
  • Page 4 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the H8DGT-HIBQF/HF serverboard, including the locations and functions of connections, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfiguring the serverboard.

  • Page 5: Table Of Contents

    Preface Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 SAS ........................ 1-2 PCI Expansion Slots ..................1-2 Onboard Controllers/Ports ................1-3 Graphics Controller ..................1-3 InfiniBand ......................1-3 Other Features ....................1-3 Server Chassis Features ................
  • Page 6 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Reliable Ground ..................2-3 Installing the System into a Rack ..............2-4 Identifying the Sections of the Rack Rails ............2-4 Locking Tabs ....................2-5 Releasing the Inner Rail ................. 2-5 Installing the Inner Rail Extension ..............2-6 Installing the Outer Rails on the Rack ............
  • Page 7 Using the Adaptec RAID Utility ..............5-22 Installing the RAID Driver During OS Installation ......... 5-22 5-13 Installing Drivers .................... 5-23 Supero Doctor III ................... 5-24 5-14 Serverboard Battery ..................5-26 Chapter 6 Advanced Chassis Setup Static-Sensitive Devices .................. 6-1 Precautions .....................
  • Page 8 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Adapter Card Replacement................6-13 Add-on Card/Expansion Slot Setup .............. 6-14 6-10 Drive Bay Installation/Removal ..............6-16 Accessing the Drive Bays ................6-16 6-11 Power Supply ....................6-20 Power Supply Replacement ................6-20 Installation Complete ..................6-21 Chapter 7 BIOS Introduction ......................

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview The A+ Server 2122TG-HIBQRF/HTRF is a high-end server comprised the SC217HQ-R1400BP 2U server chassis and with four distinct computing nodes each with the H8DGT-HIBQF/HF dual processor serverboard. Please refer to our web site for information on operating systems that have been certified for use with the system (www.supermicro.com).

  • Page 10: Serverboard Features

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Serverboard Features At the heart of the A+ Server 2122TG-HIBQRF/HTRF lies the H8DGT-HIBQF/HF, a dual processor serverboard based on the AMD SR5670/SP5100 Chipset and designed to provide maximum performance. Up to four of these serverboards can be mounted in the SC217 chassis.

  • Page 11: Onboard Controllers/Ports

    G200 graphics controller ® with 16 MB DDR2 memory. InfiniBand The A+ Server 2122TG-HIBQRF includes a QDR (quad data rate) speed InfiniBand QSFP connector. InfiniBand is a scalable serial communications link intended for connecting processors with high-speed peripherals. Other Features...

  • Page 12: Front Control Panel

    Front Control Panel SC217 models include four front panels on the handles of the chassis which control each of the systems. Each control panel on the A+ Server 2122TG-HIBQRF/HTRF provides you with system monitoring and control for one server node. LEDs indicate system power, HDD activity, network activity, system overheat and power supply failure.
  • Page 13 Chapter 1: Introduction Figure 1-1. AMD SR5670/SP5100 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. DIMM A1 DIMM A1 HT3 Link DIMM A0 16x16-6.4GT/s DIMM A0 DIMM B1 DIMM B1 DIMM B0 HT3 Link DIMM B0 Socket G34...

  • Page 14: Contacting Supermicro

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 15: Twin 2 : System Notes

    Note: Redundant power availability will vary by configuration. SAS/SATA Backplane/Drives As a system, the A+ Server 2122TG-HIBQRF/HTRF supports the use of twenty-four (24) SAS/SATA drives. A single SAS/SATA backplane works to apply system-based control for power and fan speed functions, yet at the same time logically connects a set of six SAS/SATA drives to each serverboard.
  • Page 16 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Notes...

  • Page 17: Chapter 2 Server Installation

    Decide on a suitable location for the rack unit that will hold the A+ Server 2122TG-HIBQRF/HTRF. It should be situated in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and electromagnetic fields are generated.

  • Page 18: 2-4 Warnings And Precautions

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL • This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units.

  • Page 19: Rack Mounting Considerations

    Chapter 2: Server Installation • Always keep the rack's front door and all panels and components on the servers closed when not servicing to maintain proper cooling. Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the room.

  • Page 20: Installing The System Into A Rack

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Installing the System into a Rack This section provides information on installing the chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly from the instructions provided.

  • Page 21: Locking Tabs

    Chapter 2: Server Installation Locking Tabs Each inner rail has a locking tab. This tab locks the chassis into place when installed and pushed fully into the rack. These tabs also lock the chassis in place when fully extended from the rack. This prevents the server from coming completely out of the rack when when the chassis is pulled out for servicing.

  • Page 22: Installing The Inner Rail Extension

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Installing the Inner Rail Extension The SC217chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rail extension is attached to the inner rail to mount the chassis in the rack.

  • Page 23: Installing The Outer Rails On The Rack

    Chapter 2: Server Installation Installing the Outer Rails on the Rack Use the procedure below to install the outer rails onto the rack. Installing the Outer Rails (Figure 2-5) 1. Press upward on the locking tab at the rear end of the middle rail. 2.

  • Page 24: Standard Chassis Installation

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Standard Chassis Installation Stability hazard. The rack stabilizing mechanism must be in place, or the rack must be bolted to the floor before you slide the unit out for servicing. Failure to stabilize the rack can cause the rack to tip over.

  • Page 25: Checking The Serverboard Setup

    Chapter 2: Server Installation Checking the Serverboard Setup After you install the 2122TG-HIBQRF/HTRF in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. Before operating the SC217 chassis for the first time, it is important to remove the protective film covering the top of the chassis, in order to allow for proper ventilation and cooling.
  • Page 26 Each processor needs its own heat sink. See Chapter 5 for instructions on processor and heat sink installation. 2. Your 2122TG-HIBQRF/HTRF server system may have come with system memory already installed. Make sure all DIMMs are fully seated in their slots.

  • Page 27: Checking The Drive Bay Setup

    Chapter 2: Server Installation Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the SATA drives have been properly installed and all connections have been made. Checking the Drives 1. All drives are accessable from the front of the server. A hard drive can be installed and removed from the front of the chassis without removing the top chassis cover.
  • Page 28 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Notes 2-12...

  • Page 29: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel and on the drive carriers to keep you constantly informed of the overall status of the system. SC217 chassis models include four front panels on the handles of the chassis which control each of the systems.

  • Page 30: Control Panel Button

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Control Panel Button • Power: The main power button on each of the four control panels is used to apply or remove power from the power supply to each of the four systems in the chassis. Turning power to the system off with this button removes the main power, but keeps standby power supplied to the system.

  • Page 31: Drive Carrier Leds

    Chapter 3: System Interface • Alert: This LED is illuminated when an alert condition occurs. Informational LED Status Description An overheat condition has occured. Continuously on and red (This may be caused by cable congestion.) Blinking red (1Hz) Fan failure, check for an inoperative fan. Blinking red (0.25Hz) Power failure, check for a non-operational power supply.
  • Page 32 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Notes...

  • Page 33: About Standardized Warning Statements

    Chapter 4: Warning Statements for AC Systems Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance.
  • Page 34 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 35 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 36: Installation Instructions

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de...

  • Page 37: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 38: Power Disconnection Warning

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 39 Chapter 4: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 40: Equipment Installation

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 41: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 42: Battery Handling

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬...
  • Page 43 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 44: Redundant Power Supplies

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 45: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 46: Comply With Local And National Electrical Codes

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬...

  • Page 47: Product Disposal

    Chapter 4: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 48: Hot Swap Fan Warning

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 49 Chapter 4: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 50: Power Cable And Ac Adapter

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Power Cable and AC Adapter Warning! When installing the product, use the provided or designated connection cables, power cables and AC adaptors. Using any other cables and adaptors could cause a malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only.
  • Page 51 Chapter 4: Warning Statements for AC Systems Attention Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné. L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué...
  • Page 52 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Notes 4-20...

  • Page 53: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install the H8DGT-HIBQF/HF serverboard into the chassis, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference.

  • Page 54: Serverboard Installation

    Serverboard Installation This section explains the first step of physically mounting the H8DGT-HIBQF/HF into the SC217HQ-R1400BP chassis. The 2122TG-HIBQRF/HTRF is a highly complicated system. It is recommended that serverboard removal/installation be done by a Supermicro trained technician. Following the steps in the order given will eliminate the most common problems encountered in such an installation.

  • Page 55: I/O Port Connections

    Chapter 5: Advanced Serverboard Setup I/O Port Connections The I/O ports are color coded to make setting up your system easier. See Figure 5-1 below for the colors and locations of the various I/O ports. Figure 5-1. I/O Port Locations and Definitions Rear I/O Ports 1.

  • Page 56: Processor And Heatsink Installation

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Processor and Heatsink Installation Notes: • When handling the processor, avoid placing direct pressure on the label area of the fan. Also, do not place the serverboard on a conductive surface, which can damage the BIOS battery and prevent the system from booting up •...
  • Page 57 Chapter 5: Advanced Serverboard Setup 3. Use your thumb and your index finger to hold the CPU. Locate and align pin 1 of the CPU socket with pin 1 of the CPU. Both are marked with a triangle. Triangle 4. Align pin 1 of the CPU with pin 1 of the socket.

  • Page 58: Installing A Passive Cpu Heatsink

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the required amount has already been applied. 2. Place the heatsink directly on top of the CPU so that the heat sink screws are aligned with the mounting holes on the back plate.

  • Page 59: Installing Memory

    Chapter 5: Advanced Serverboard Setup Installing Memory Caution! Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Installing Memory 1. Insert each memory module vertically into its slot, paying attention to the notch along the bottom of the module to prevent inserting the module incorrectly (see Figure 2-1).
  • Page 60 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Figure 5-3. DIMM Installation Notch Notch To Install: Insert module vertically and press down until it snaps into place. Pay attention to the alignment notch at Front View the bottom. To Remove: Use your Note: Notch should...

  • Page 61: Dimm Module Population Configuration

    Chapter 5: Advanced Serverboard Setup DIMM Module Population Configuration For memory to work properly, follow the tables below for memory installation: Per Channel DIMM Populations Options DIMM Type DIMM A DIMM B Max. MHz, Max. MHz, Max. GB/ 1.5V DIMMs 1.35V DIMMs Channel SR or DR...

  • Page 62: Adding Pci Expansion Cards

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Adding PCI Expansion Cards The 2122TG-HIBQRF/HTRF includes a preinstalled riser card designed specifically for use in the SC217HQ-R1400BP 2U rackmount chassis for each H8DGT-HIBQF/HF serverboard. This riser card supports a low-profile PCI Express 2.0 x16 card up to 5.9”...

  • Page 63: Serverboard Details

    Chapter 5: Advanced Serverboard Setup Serverboard Details Figure 5-4. H8DGT-HIBQF/HF Motherboard Layout (not drawn to scale) COM1 JIB1 Mellonox Connect-X JI2C1 JI2C2 SR5670 JBT1 SP5100 Battery CPU1 CPU2 Notes: Jumpers not indicated are for test purposes only. 5-11...
  • Page 64 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL H8DGT-HIBQF/HF Quick Reference Jumper Description Default Setting JBT1 CMOS Clear (See Section 5-9) JIB1 InfiniBand Enable/Disable (2022TG-HIBQRF) Pins 1-2 (Enabled) C1/JI C to PCI-E Slot Enable/Disable Both Closed (Enabled) BMC Enable/Disable Pins 1-2 (Enabled) JPG1...

  • Page 65: Connector Definitions

    Chapter 5: Advanced Serverboard Setup Connector Definitions LAN1/2 (Ethernet Ports) Two Gigabit Ethernet ports (designated LAN1 and LAN2) are located beside the VGA port. Additionally, there is a dedicated LAN port for IPMI beside the two rear USB ports. These Ethernet ports accept RJ45 type cables.
  • Page 66 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Chassis Intrusion Chassis Intrusion Pin Definitions A Chassis Intrusion header is located at JL1. (JL1) Attach the appropriate cable to inform you of Pin# Definition a chassis intrusion. Battery voltage Intrusion signal Overheat LED Overheat LED...
  • Page 67 Adapter card into this connector to use the functions indicated above. This connector is designed specifically for a Supermicro- proprietary adapter card. InfiniBand Connector (2122TG-HIBQRF) The H8DGT-HIBQF serverboard includes a single QDR (quad data rate) speed InfiniBand QSFP connector located at JB1 on the serverboard.

  • Page 68: Jumper Settings

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the motherboard, Jumper jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function Setting of the connector.
  • Page 69 Chapter 5: Advanced Serverboard Setup I2C to PCI-Express Slot C to PCI-Express Slot Jumper Settings C1/JI C2 allows you to enable the I C bus (JI2C1/JI2C2) to communicate with the PCI-Express slot. Jumper Setting Definition For the jumpers to work properly, please set Closed Enabled both jumpers to the same setting.

  • Page 70: 5-10 Onboard Indicators

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL 5-10 Onboard Indicators LAN LED (Connection Speed LAN LEDs Indicator) The Ethernet ports (located beside the VGA LED Color Definition port) have two LEDs. On each Gb LAN port, 10 MHz one LED blinks to indicate activity while the...

  • Page 71: 5-11 Sata Ports

    Chapter 5: Advanced Serverboard Setup InfiniBand LED Indicators InfiniBand LED (LE2) (2122TG-HIBQRF only) Activity LED Two InfiniBand LED indicators (LE2/LE3) Color Status Definition Green Solid InfiniBand Connected are located near the InfiniBand port of the No Connection H8DGT-HIBQF Serverboard. The green...

  • Page 72: 5-12 Enabling Sata Raid

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL 5-12 Enabling SATA RAID Now that the hardware is set up, you must install the operating system and the SATA RAID drivers, if you wish to use RAID with your SATA drives. The installation procedure differs depending on whether you wish to have the operating system installed on a RAID array or on a separate non-RAID drive.

  • Page 73: Enabling Sata Raid In The Bios

    Chapter 5: Advanced Serverboard Setup Enabling SATA RAID in the BIOS Before installing the Windows operating system, you must change some settings in the BIOS. Boot up the system and hit the <Delete> key to enter the BIOS Setup Utlility. After the setup utility loads, 1.
  • Page 74 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Figure 5-6. DotHill RAID Utility Program Screen Figure 5-7. Adaptec RAID Utility Program Screen Using the DotHill and Adaptec RAID Utility The RAID Utility program allows you to define the drives you want to include in the RAID array and the mode and type of RAID.

  • Page 75: Installing The Raid Driver During Os Installation

    Chapter 5: Advanced Serverboard Setup Installing the RAID Driver During OS Installation You may also use the procedure below to install the RAID driver during the Windows OS installation: 1. With the Windows OS installation CD-ROM in the CD drive, restart the system.
  • Page 76 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Figure 5-8. Driver/Tool Installation Display Screen Note: Click the icons showing a hand writing on paper to view the readme files for each item. Click the computer icons to the right of these items to install each item (from top to the bottom) one at a time.
  • Page 77 Chapter 5: Advanced Serverboard Setup Figure 5-9. SuperDoctor III Interface Display Screen (Health Information) Figure 5-10. SuperDoctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm.

  • Page 78: 5-14 Serverboard Battery

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL 5-14 Serverboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 5-11). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer (CR2032).

  • Page 79: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC217HQ-R1400BP chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

  • Page 80: Control Panel

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Figure 6-1. Front and Rear Chassis Views Control Panel Control Panel Control Panel Control Panel SATA Drives (24) IPMI LAN Port Ethernet Ports COM1 Port VGA Port USB Ports Infiniband Port Control Panel The control panel (located on the front of the chassis) must be connected to the chassis backplane connector on the serverboard to provide you with system status indications.

  • Page 81: Chassis Cover

    Chapter 6: Advanced Chassis Setup Chassis Cover Before operating the SC217 chassis for the first time, it is important to remove the protective film covering the top of the chassis, in order to allow for proper ventilation and cooling. Removing the Chassis Cover and Protective Film (Figure 6-2) 1.

  • Page 82: Air Shrouds

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. The SC217 chassis requires air shrouds for each motherboard node. Air shrouds vary depending upon the motherboard used. See the illustrations below. Installing an Air Shroud (Figure 6-3) 1.

  • Page 83: Checking The Airflow

    Chapter 6: Advanced Chassis Setup Checking the Airflow • Make sure there are no objects obstructing the airflow in and out of the chassis. In addition, if you are using a front bezel, make sure the bezel's filter is replaced periodically.
  • Page 84 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Changing a System Fan 1. If necessary, open the chassis while the power is running to determine which fan has failed. (Never run the server for an extended period of time with the chassis cover open.) 2.
  • Page 85 Chapter 6: Advanced Chassis Setup Figure 6-5. Replacing a System Fan in the Fan Housing 5. Place the replacement fan into the vacant space in the housing while making sure the arrows on the top of the fan (indicating air direction) point in the same direction as the arrows on the other fans.

  • Page 86: Removing And Installing The Backplane

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Removing and Installing the Backplane The SC217 chassis backplane is located behind the hard drives and in front of the front system fans. Although backplane failure rarely occurs, in the event of a backplane failure, follow the instructions below.
  • Page 87 Chapter 6: Advanced Chassis Setup 6. Loosen the three screws in the spring bar, located on the floor of the chassis, indicated by the arrows below (Figure 6-7). 7. Remove the side screw from the side of the chassis. Figure 6-7. Loosening the Spring Bar Screws in the Floor of the Chassis 8.

  • Page 88: Installing The Backplane

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Installing the Backplane Installing the Backplane into the Chassis (Figure 6-9) 1. Ensure that all of the hard drive carriers have been removed from the bays in the front of the chassis and that the spring bar has been loosened as directed in the previous section.

  • Page 89: Installing The Motherboard

    Chapter 6: Advanced Chassis Setup Installing the Motherboard I/O Shield The I/O shield (Figure 6-10) holds the motherboard ports in place. The I/O shield does not require installation. Figure 6-10. I/O Shield Placement I/O Shields Permanent and Optional Standoffs Standoffs prevent short circuits by creating space between the motherboard and the chassis surface.
  • Page 90 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL 5. Make sure that the I/O ports on the serverboard align properly with their respective holes in the I/O shield at the back of the chassis. 6. Lay the motherboard in the node drawer aligning the standoffs with the motherboard.

  • Page 91: Adapter Card Replacement

    Chapter 6: Advanced Chassis Setup Adapter Card Replacement Each motherboard drawer comes equipped with an adapter card which plugs into the backplane. In the unlikely event that the adapter card needs to be replaced, installation requires only a Phillips head screwdriver. Removing the Adapter Card (Figure 6-12) 1.

  • Page 92: Add-On Card/Expansion Slot Setup

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Add-on Card/Expansion Slot Setup The SC217 chassis supports one low-profile expansion slot for each node (Figure 6-13), for a total of four slots in the chassis. Figure 6-13. I/O Shield Placement PCI Slot Shield Expansion Card Slot Clip...
  • Page 93 Chapter 6: Advanced Chassis Setup Installing Add-on Cards (Figure 6-14) 1. Disconnect the power supply, lay the chassis on a flat surface, and open the chassis cover. 2. Pull open the add-on card slot clip in the rear of the chassis. 3.
  • Page 94 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL 6-10 Hard Disk Drives The SC217 chassis features 24 drive bays that are accessable for drive replacement from the front of the chassis. The drives are mounted in drive carriers to simplify their installation and removal. These carriers also help promote proper airflow for the drive bays.
  • Page 95 Chapter 6: Advanced Chassis Setup Removing Hard Drive Carriers from the Chassis 1. Press the release button on the drive carrier. This extends the drive bay handle. 2. Use the handle to pull the drive out of the chassis (Figure 6-17). 3.
  • Page 96 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Figure 6-18. Removing a Dummy Drive from Carrier Dummy Drive Drive Carrier Installing a Drive into the Carrier 1. Install a new drive into the carrier with the printed circuit board side facing down so that the mounting holes in the drive align with those in the carrier.

  • Page 97: 6-11 Power Supply

    Chapter 6: Advanced Chassis Setup 6-11 Power Supply The SC217 chassis includes a 1400 Watts power supply. This power supply is auto- switching capable. This enables it to automatically sense and operate at a 100v to 240v input voltage. An amber light will be illuminated on the power supply when the power is off.
  • Page 98 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL 6-20...
  • Page 99 Chapter 6: Advanced Chassis Setup Notes 6-21...

  • Page 100: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS Setup Utility for the H8DGT-HIBQF/HF. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS Setup Utility setup screens. Starting BIOS Setup Utility To enter the AMI BIOS Setup Utility screens, press the <Delete>...

  • Page 101: Starting The Setup Utility

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Starting the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS Setup Utility. From the main menu, you can access the other setup screens.

  • Page 102: Advanced Setup Configurations

    Chapter 7: BIOS • Logical Count: This item displays the number of CPU Cores installed in your system as detected by the BIOS. • Micro_code Revision: This item displays the revision number of the BIOS Micro_code used in your system. System Memory This displays the size of memory available in the system: •...
  • Page 103 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Quiet Boot If Disabled, normal POST messages will be displayed on boot-up. If Enabled, this display the OEM logo instead of POST messages. Add On ROM Display Mode This option sets the display mode for Option ROM. The options are Force BIOS or Keep Current.
  • Page 104 Chapter 7: BIOS Processor & Clock Options Configuration  CPU Configuration This displays static information on the Module Version, AGESA Version, Physical Count and Logical Count for the system's processor(s) and clock. CPU Information This setting is used to select which physical CPU's information to display. Options include Processor 0 or Processor 1.
  • Page 105 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Clock Speed Spectrum This option enables or disables spread spectrum modulation. Advanced Chipset Control Configuration   NorthBridge Configuration  Memory Configuration Bank Interleaving Select Auto to automatically enable a bank-interleaving memory scheme when this function is supported by the processor. The options are Auto and Disabled.
  • Page 106 Chapter 7: BIOS DRAM ECC Enable This setting allows hardware to report and correct memory errors automatically, maintaining system integrity. Options are Enabled or Disabled.  DRAM Timing Configuration DRAM Timing Config This setting specifies the DRAM timing configuration. Options are Auto and Manual.
  • Page 107 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL  IDE Configuration OnChip SATA Channel This setting allows you to Enable or Disable the OnChip SATA channel. OnChip SATA Type Use this setting to set the OnChip SATA type. Options include Native IDE, RAID, AMD_AHCI and Legacy IDE.
  • Page 108 Chapter 7: BIOS PIO Mode PIO (Programmable I/O) mode programs timing cycles between the IDE drive and the programmable IDE controller. As the PIO mode increases, the cycle time decreases. The options are Auto, 0, 1, 2, 3, and 4. Select Auto to allow BIOS to auto detect the PIO mode.
  • Page 109 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL  PCI/PnP Configuration Clear NVRAM Select Yes to clear NVRAM during boot-up. The options are Yes and No. Plug & Play O/S Select Yes to allow the OS to configure Plug & Play devices. (This is not required for system boot if your system has an OS that supports Plug &...
  • Page 110 Chapter 7: BIOS Load Onboard LAN 2 Option ROM This option allows you to enable or disable the onboard LAN 2 option ROM. Primary Video Controller This option specifies the primary video controller for Onboard VGA or Other.  SuperIO Device Configuration Serial 1 Address This option specifies the base I/O port address and Interrupt Request address of serial port 1.
  • Page 111 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Serial Port Mode Selects the serial port settings to use. Options are (115200 8, n, 1), (57600 8, n, 1), (38400 8, n, 1), (19200 8, n, 1) and (09600 8, n, 1). Flow Control Selects the flow control to be used for console redirection.
  • Page 112 Chapter 7: BIOS Other items in the submenu are systems monitor displays for the following information: CPU 1 Temperature, CPU 2 Temperature, NB Temperature, VRD1 Temperature, VRD2 Temperature, System Temperature, Air Temperature, Fan 1 Reading, Fan 2 Reading, CPU1 Vcore, CPU2 Vcore, CPU1 Mem VTT, CPU2 Mem VTT, CPU1 Mem, CPU2 Mem, 1.1V, 1.8V, 5V +12V, 3.3 Vcc, 3.3 VSB, VBAT and HT Voltage.
  • Page 113 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL  Set LAN Configuration Use the "+" and "-" keys to choose the desired channel number. This displays Channel Number and Channel Number Status information. This menu contains options for inputing settings for the SET LAN Configuration Command.

  • Page 114: Security Menu

    Chapter 7: BIOS BMC Watch Dog Timer Action This setting is used to set the Watch Dog function, which allows the BMC to reset or powerdown the system if the OS crashes or hangs. Options include Disabled, Reset System, Power Down and Power Cycle. ...

  • Page 115: Boot Menu

    A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Boot Menu The Boot Menu is accessible only when the "Load Onboard LAN Option ROM" setting (in the PCI/PnP Configuration menu) is enabled.  Boot Device Priority This feature allows you to prioritize the boot sequence from the list of available devices.
  • Page 116 Chapter 7: BIOS Load Optimal Defaults To set this feature, select Load Optimal Defaults from the Exit menu and press <Enter>. Then Select "OK" to allow BIOS to automatically load the Optimal Defaults as the BIOS Settings. The Optimal settings are designed for maximum system performance, but may not work best for all computer applications.
  • Page 117 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Notes 7-18...

  • Page 118: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 119 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL Notes...

  • Page 120: Appendix B System Specifications

    On-chip (SP5100) SATA controller supports up to six (6) SATA HDD (RAID 0, 1 and 10 supported) for each serverboard Drive Bays The 2122TG-HIBQRF/HTRF server has twenty-four (24) hot-swap drive bays to house up to twenty-four SATA drives (6 for each node) Expansion Slots...
  • Page 121 Dimensions: (WxHxD) 17.25 x 3.47 x 28.5 in. (438 x 88 x 724 mm) Weight Gross (Bare Bone): 85 lbs. (38.6 kg.) System Cooling The A+ Server 2122TG-HIBQRF/HTRF has four (4) 8-cm PWM system cooling fans System Input Requirements AC Input Voltage: 100-240V AC auto-range...
  • Page 122 Appendix B: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/- 3-3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
  • Page 123 A+ SERVER 2122TG-HIBQRF/HTRF USER'S MANUAL (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.

This manual is also suitable for:

2122tg-htrf

Table of Contents
