Hardware Installation and Reference Guide
Radio Specifications
Receive Sensitivity
1.4.3 Port Specifications
Table 1-6 Port Specifications
Port Specifications
Bluetooth
USB Port
Fixed Service Port
Fixed Management Port
Status LED
Button
RG-AP850-AR(V3)
IEEE 802.11b: –96 dBm (1 Mbps), –93 dBm (5 Mbps), –89 dBm (11 Mbps)
IEEE 802.11a/g: –91 dBm (6 Mbps), –85 dBm (24 Mbps), –80 dBm (36
Mbps), –74 dBm (54 Mbps)
IEEE 802.11n: –90 dBm (MCS0), –70 dBm (MCS7), –89 dBm (MCS8), –68
dBm (MCS15)
IEEE 802.11ac: HT20: –88 dBm (MCS0), –63 dBm (MCS9)
IEEE 802.11ac: HT40: –85 dBm (MCS0), –60 dBm (MCS9)
IEEE 802.11ac: HT80: –82 dBm (MCS0), –57 dBm (MCS9)
IEEE 802.11ax: HE80: –82 dBm (MCS0), –57 dBm (MCS9), –52 dBm
(MCS11)
IEEE 802.11ax: HE160: –79 dBm (MCS0), –53 dBm (MCS9), –50 dBm
(MCS11)
RG-AP850-AR(V3)
Bluetooth 5.1
USB 3.0
Uplink:
One 100/1000/2500/5000Base-T auto-sensing Ethernet port, supporting IEEE
802.3af/at/bt-compliant PoE
One 5G SFP port, compatible with 1 Gbps and 2.5 Gbps, a combo port
Downlink:
One 10/100/1000Base-T auto-sensing Ethernet port, supporting power supply to
the IoT module (48 V/12.95 W)
One RJ45 console port
One system status LED
One reset button
6
Product Introduction
