Technical Data - CPL-B

Type
Power supply
Rated power
Stand-by operating
Output voltage
Ripple
Monitoring:
Output current
Mode of operation
Alarm / Ventilation:
Output current
Mode of operation
Number of lines / groups*
Fire detectors per line
SHEV buttons per line
Line voltage
Temperature range
Ingress protection
Protection class
Housing:
Material
Colour
Dimensions WxHxD
* D+H Highspeed (HS) drives will be supported.

Declaration of Conformity

We declare under our sole responsibility that the
product described under "Technical Data" is in
conformity with the following
2014/30/EU, 2014/35/EU, 2011/65/EU
S.I. 2016/1091, S.I. 2016/1011, S.I. 2012/3032
Technical file at:
D+H Mechatronic AG, D-22949 Ammersbek
Dirk Dingfelder
CEO
01.06.2023

Important regulations

Observe regulations for danger warning systems
VDE 0833, guidelines for electrical systems VdS
2221, VDE 0100, DIN 18232 for smoke and heat
vent systems, regulations of the local fire-brigade
and of EVU for connection to mains supply.
99.829.07 1.2/06/23
CPL-B
230 V AC, 50 Hz (195 ... 253 V AC)
55 VA
< 20 VA
24 V DC
<0,5 Vpp; < 1%, load-dependent
200 mA
Continuous duty
700 mA
Short-time duty, 30% ED
1/1
max. 14 pcs.
max. 8 pcs.
15 V DC (12 ... 17 V DC)
-5 ... +40°C
IP 30
II, with fuctional ground
Plastic (Polycarbonate)
white
172 x 151 x 95 mm
regulations :
Maik Schmees
CTO

Service timer

An overdue maintenance of the system will be
indicated by the control panel after about ca. 14 to
16 months.
The yellow LED in the smoke vent button (RT-45L-
RJ / RT-45-RJ) will start flashing.
A malfunction of the smoke vent system will be still
indicated by the extinction of the green LED in the
smoke vent button (RT-45L-RJ / RT-45-RJ).
The service timer is reset using DIP switch S1.8.
To carry out the reset, set the DIP switch to OFF
for at least 3 seconds, then set it to ON again.
If the service timer is not needed, set DIP switch
1.8 permanently to OFF.
This switches off the service timer.
