LED indicators- CPL-B

1

RJ45 connections and status LEDs

99.829.07 1.2/06/23
2 3 4 5 6
AL COM 1
SD RT
English
LED 1 Radio communication
LED 2 CPU fault CPL-B (yellow)
LED 3 CPL-B OK (green)
LED 4 LST-VOC fault (yellow)
LED 5 Service timer (yellow)
LED 6 Mains (green)
COM 2 24 V
ADD M1
AIO Basic
7/40
