System components description

1. Ventilation flap (SHEV)
• Cutting back on energy losses thanks to closure of the opening in the lift shaft.
• Ventilates and extracts smoke when necessary.
• For vertical or horizontal installation.
• Depending on the building type, with or without weather protection
JK-180 - Ventilation flap with spring return motor with mounting frame for integrated installation
JK-190 - Ventilation flap with spring return motor for surface mounting
2. Weather protection
HVC - Weather protection roof cover for horizontal installation
HVL - Louvre cover for horizontal installation
ALAS - Weather protection grille for vertical installation
3. Smoke detection
• Smoke detection throughout the lift shaft height and signal transmission to the central unit.
• Two options: Point-type smoke detectors or infrared detectors (SD-L-F1).
• Choice dependent on shaft dimensions and building requirements.
PD-RJ-AIO-P&G - Optical smoke detector (up to 36 m shaft height)
PD-RJ-AIO-End - Optical smoke detector with integrated terminal resistor
SD-L-F1 - Infrared smoke detector (up to 100 m shaft height)
4. Central unit
• Receiving and transmitting the trigger signal to open the ventilation flap.
• Central unit with integrated temperature sensor and extended connection options.
CPL-B - Central unit with integrated radio receiver
5. Lift Status Transmitter
• Checking the CO level directly at the lift car.
• Additional monitoring of movements or emergency situations in the lift.
• If needed, ventilation signal to the central unit.
• Integrated temperature sensor, humidity sensor, CO sensor and acceleration sensor.
• Time-controlled and use-dependent ventilation functions.
• Wireless radio link to the central unit.
LST-CO2 - Lift Status Transmitter
LSR - Lift Status Repeater
6. Smoke vent button with status indicators
• Manual triggering of a ventilation or smoke extraction command and system status display.
• LED Status display depending on model option: ventilation, alarm and fault
RT 45/O-L-RJ - Smoke vent button
RT 45/O-RJ - moke vent button with integrated ventilation button
PD-RJ-AIO-End - optical fire detector for the main evacuation level
7. Additional components
TS-RJ - Timer
SLT 42-U-SD-RJ - Key-operated vent switch
RTR 231-RJ - Room temperature control
CWSO-RR-S1-RJ - Acoustical signal transmitter
