8 Measuring temperatures

8.4.3 Manual adjustment by touching the screen

When manual mode is active, an adjustment wheel is displayed to the right of the tem-
perature scale.
Figure 8.1 Manual adjustment mode active
To manually adjust the image, do the following:
1. To enter manual adjustment mode, select Temperature scale > Manual on the main
toolbar.
2. To simultaneously change the maximum and minimum limits of the temperature scale,
place your finger on the screen and move it up/down.
3. To change the maximum or minimum limit, do the following:
3.1. Tap the maximum or minimum temperature.
3.2. Place your finger on the screen and move it up/down to change the value of
the highlighted temperature.
8.4.3.1 1-Touch auto-adjustment
In manual mode, you can auto-adjust the image by touching the screen. The image will
be auto-adjusted based on the thermal content of the area around the touched point.
The top and bottom levels in the temperature scale will be set to the maximum and mini-
mum temperatures in that area.
By using the color information only for the relevant temperatures, you will get more de-
tails in your area of interest.
