6

Basic operation

6.1 Safety information

Before operating the camera, you must read, understand, and follow the warnings and
cautions in section 1 Safety information.

6.2 Battery

6.2.1 Install the battery

Push the battery into the battery compartment.

6.2.2 Remove the battery

1. Power off the camera.
2. Remove the battery from the camera.

6.3 Battery charging

CAUTION
When you connect the power supply to a mains socket, select a socket that is easy to access. Should a
hazardous situation occur, you must be able to easily disconnect the power supply.
Note It is good practice to disconnect the power supply from the mains socket when
not in use.

6.3.1 Charge the battery using the battery charger

1. Put the battery in the battery charger.
2. Connect the power supply to the battery charger.
3. Connect the power supply to a mains socket.
6.3.1.1 Battery charger indicator
• During the charging, the light on the battery charger is flashing.
• When the battery is fully charged, the light is steady.
6.3.2 Charge the battery in the camera — using the power supply
1. Open the cover at the top of the camera.
2. Connect the power supply to the camera.
3. Connect the power supply to a mains socket.
