5
User interface

5.2 Main toolbar

1. Temperature scale
2. Image mode
3. Measurement
4. Color
5. Settings

5.2.1 Navigation

To navigate the user interface, you can use the touch screen and/or the navigation pad
and Back button.
• To display the main toolbar, do one of the following:
◦ Tap the menu button at the bottom of the screen.
◦ Push the center of the navigation pad.
• To navigate the toolbars, menus, and dialog boxes, and to change values in dialog
boxes, push the navigation pad up/down or left/right.
• To confirm changes and settings in menus and dialog boxes, push the center of the
navigation pad.
• To leave dialog boxes and to go back in the menu system, push the Back button.
