7 Image modes

7.2 Align the thermal and visual images

In Thermal MSX and Picture in picture modes, the camera displays a combination of
thermal and visual images. When looking at an object close up or far away, you may
need to adjust the distance setting in the camera to align the thermal and visual images.
To align the thermal and visual images, do the following:
1. Tap the screen. This displays a box with a distance in the upper right corner.
2. Tap the distance box. This displays a slider.
3. Tap the slider or push the navigation pad up/down to adjust the distance.

7.3 Move and resize the infrared image frame

If Picture in picture mode is selected, you can move and resize the infrared image frame.
1. Tap a corner of the infrared image frame. The frame is now displayed with handles in
the center and in the corners.
2. To move the frame, tap and hold the center handle and drag the frame.
3. To resize the frame, tap and hold one of the corner handles and drag the corner of
the frame.
