Original operating manual
Mechanical pack top seed drill
Cataya 3000/4000 Super
SmartLearning
www.amazone.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cataya 3000 Super and is the answer not in the manual?

Questions and answers

Related Manuals for Amazone Cataya 3000 Super

Summary of Contents for Amazone Cataya 3000 Super

  • Page 1 Original operating manual Mechanical pack top seed drill Cataya 3000/4000 Super SmartLearning www.amazone.de...
  • Page 2 Please enter the identification data of the implement. The identification data can be found on the rating plate.

  • Page 3: Table Of Contents

    Permitted mounting categories Protective equipment Noise development data 4.4.1 Charging sieve Drivable slope inclination 4.4.2 Chain drive cover 4.4.3 Metering unit cover 4.4.4 Road safety bars Warning symbols 4.5.1 Positions of the warning symbols MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 4 Folding the tramline marker onto 10.2 Maintaining the implement the implement frame 10.2.1 Maintenance schedule 6.4.2 Folding the tramline marker on the exact following harrow 10.2.2 Checking the TwinTeC cutting disc distance MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 5 Lubricating the drive chain on the right metering drive 11 Loading the implement 11.1 Lifting the implement 11.2 Lashing the implement 12 Appendix 12.1 Bolt tightening torques 12.2 Other applicable documents 13 Directories 13.1 Glossary 13.2 Index MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 7: About This Operating Manual

    WARNING Indicates a possible threat with moderate risk for severe physical injury or death. CAUTION Indicates a threat with low risk for light or moderately severe physical injuries. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 8: Further Instructions

    Example: 1. Instruction 1 2. Instruction 2 1.2.3.1 Instructions and responses CMS-T-005678-B.1 Reactions to instructions are marked with an arrow. Example: 1. Instruction 1 Reaction to instruction 1 2. Instruction 2 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 9: Lists

    Instructions that do not require a specific sequence are shown as a list with arrows. Example: Instruction Instruction Instruction 1.2.4 Lists CMS-T-000024-A.1 Lists without an essential order are shown as a list with bullets. Example: Point 1 Point 2 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 10: Item Numbers In Figures

    Your suggestions for improvement help us Technische Redaktion to create ever more user-friendly operating manuals. Postfach 51 Please send us your suggestions by post, fax or D-49202 Hasbergen email. Fax: +49 (0) 5405 501-234 E-Mail: td@amazone.de MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 11: Safety And Responsibility

    2.1.2.1.1 Requirements for all persons working with the machine CMS-T-00011160-A.1 If the machine is used improperly, people can be injured or killed. To prevent accidents due to improper use, every person who works with MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 12 Farmers are basically familiar with working with agricultural implements and can instruct agricultural helpers in how to use the implements if necessary. They can perform odd tasks and simple maintenance and repair work on agricultural implements themselves. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 13 Passengers can fall, be run over and severely injured or killed due to machine movements. Ejected objects can hit and injure passengers. Do not let anybody ride on the machine. Do not let anybody climb onto the driving machine. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 14 Non-observance of the technical limits values of the machine can result in accidents and serious personal injury or even death. Moreover, the machine can be damaged. The technical limit values can be found in the Technical Data. Comply with the technical limit values. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 15 Missing warning symbols increase the risk of serious and lethal personal injury. Clean dirty warning symbols. Immediately replace any damaged and illegible warning symbols. Put the intended warning symbols on spare parts. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 16: Knowing And Preventing Dangers

    Never look for leaks with your bare hands. Keep your body and face away from leaks. If liquids penetrate the body, consult a doctor immediately. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 17: Safe Operation And Handling Of The Machine

    Use only suitable tractors for coupling and transporting the implement. When the implement is coupled onto the tractor, make sure that the tractor's connecting device meets the implement requirements. Couple the implement properly to the tractor. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 18 If the machine is not properly prepared for road travel, it can result in serious traffic accidents. Check the lighting and identification for road travel for proper function. Remove coarse dirt from the implement. Follow the instructions in the section "Preparing the implement for road travel". MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 19: Safe Maintenance And Modification

    To ensure that the operating permit remains valid in accordance with national and international regulations, ensure that the specialist workshop only uses conversion parts, spare parts and special equipment approved by AMAZONE. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 20 Remove the ignition key and carry it with you. Remove the key from the battery circuit breaker. Wait until all parts that are still running come to a stop and that hot parts cool down. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 21 Never linger under raised implement parts. If you have to work on or under raised machine parts, lower the implement parts or secure the raised implement parts with a mechanical support or hydraulic locking device. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 22 CMS-T-00011149-A.1 Special equipment, accessories, and spare parts Special equipment, accessories, and spare parts that do not meet AMAZONE requirements can impede the operational safety of the implement and cause accidents. Only use original parts or parts that meet AMAZONE requirements.

  • Page 23: Safety Routines

    If you are not sure if the protective equipment is properly installed and functional, have the protective equipment checked by a qualified specialist workshop. Make sure that the protective devices are properly installed and functional before any work on the implement. Replace damaged protective equipment. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 24 When climbing up and down, never hold onto the control elements. Accidental actuation of control elements can unintentionally activate potentially dangerous functions. When climbing down, never jump off of the machine. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 25: Intended Use

    AMAZONE. Uses other than those specified under the intended use are considered as improper. The manufacturer is not liable for any damage resulting from improper use, solely the operator is responsible. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 26: Product Description

    Product description CMS-T-00007913-A.1 4.1 Implement overview CMS-T-00007914-A.1 CMS-I-00005518 Hopper Radar sensor Tramline marker Exact following harrow, optionally roller harrow TwinTeC double-disc coulters, optionally RoTeC Loading board single-disc coulters Metering unit Track marker MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 27: Function Of The Implement

    4 | Product description Function of the implement CMS-I-00005519 Cabinet for the supply lines SmartCenter 4.2 Function of the implement CMS-T-00007918-A.1 CMS-I-00005498 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 28: Special Equipment

    Connection unit for tramline marker without track marker Seed metering wheel for peas and beans Mechanical coulter pressure display Harrow set on the TwinTeC coulter Exact following harrow Mounting kit for exact following harrow MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 29: Protective Equipment

    Comfort hydraulic system incl. MinMax coulter pressure adjustment Preparation loading dimension 2.45 m 4.4 Protective equipment CMS-T-00007927-A.1 4.4.1 Charging sieve CMS-T-00007928-A.1 The charging sieve 1 in the hopper prevents contact with the running agitator shaft. CMS-I-00005523 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 30: Chain Drive Cover

    CMS-I-00005526 4.4.4 Road safety bars CMS-T-00007937-C.1 The road safety bars 1 cover the tines of the exact following harrow or seed harrow during road travel to protect against injury and damage. CMS-I-00005527 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 31: Warning Symbols

    4 | Product description Warning symbols 4.5 Warning symbols CMS-T-00007938-A.1 4.5.1 Positions of the warning symbols CMS-T-00007939-A.1 CMS-I-00005544 CMS-I-00005551 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 32 4 | Product description Warning symbols CMS-I-00005552 CMS-I-00005550 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 33: Layout Of The Warning Symbols

    Make sure that there is nobody standing in the danger area. MD 082 Risk of falling from tread surfaces and platforms Do not let anybody ride on the implement. Do not let anybody climb onto the driving implement. CMS-I-000081 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 34 Never look for leaks in hydraulic hose lines using your hand or fingers. Never attempt to plug leaks in hydraulic hose lines using your hand or fingers. If you are injured by hydraulic oil, consult a doctor immediately. CMS-I-000216 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 35 MD 154 Risk of injury or even death due to unprotected seeding harrow tines Before driving on public roads, put on the road safety bar as described in the operating manual. CMS-I-00003657 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 36 Wait until all moving parts are at a standstill before reaching into the danger area. CMS-I-00003694 Make sure that there is nobody standing in the danger area or close to the moving parts. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 37: Rating Plate On The Implement

    Make sure that there is nobody standing in the danger area or close to the moving parts. 4.6 Rating plate on the implement CMS-T-00004505-G.1 Implement number Vehicle ID number Product Permissible technical implement weight Model year Year of manufacture CMS-I-00004294 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 38: Threaded Cartridge

    The hand wash tank has a water tap 1 and a soap dispenser 2 . The hand wash tank has a capacity of 5 l and is fitted with a screw cap 3 . CMS-I-00005533 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 39: Metering System

    4.10 Universal operating tool CMS-T-00001735-C.1 Setting work on the implement is performed with the universal operating tool 1 . The universal operating tool is parked in a holder on the implement frame. CMS-I-00001082 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 40: Camera System

    4.12 Radar sensor CMS-T-00001778-C.1 On electric drives, the radar sensor records the working speed. The working speed is used to determine the worked area and the required speed for the metering drives. CMS-I-00002221 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 41: Lighting

    The coulter array lighting 1 enables better visibility of the seeding coulters in the dark. The coulter array lighting is switched together with the work floodlights via the control terminal or control computer. CMS-I-00005664 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 42: Mounting Frame

    1 limit the placement depth and clean the cutting discs. The coulter pressure and the placement depth can be adjusted. For soil tillage without seeding, the coulters can be lifted. CMS-I-00004578 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 43: Twintec Coulter

    The coulter pressure and the placement depth can be adjusted. For soil tillage without seeding, the coulters can be lifted. CMS-I-00003166 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 44: Exact Following Harrow

    4.18 Coulter harrow CMS-T-00006648-C.1 The harrow tines 1 of the coulter harrow cover the deposited metered material evenly with loose soil. The pitch and the height of the harrow tines can be adjusted. CMS-I-00004734 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 45: Roller Harrow

    Depending on the implement equipment, a different number of discs can be installed on the implement. The track width and the pitch of the track discs can be adjusted. CMS-I-00003167 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 46: Track Marker

    CMS-I-00005540 4.22 GreenDrill CMS-T-00005046-B.1 The GreenDrill pack top seed drill enables the seeding of fine seeds and catch crops during soil tillage or the seeding of nurse crops while seeding. CMS-I-00003609 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 47: Technical Data

    3,029 mm ± 3 mm 5.4 Optimal working speed CMS-T-00007377-B.1 Working speed (dependent on the soil tillage Seeding coulter implement) TwinTeC coulter 8 km/h to 12 km/h RoTeC coulter 6 km/h to 12 km/h MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 48: Soil Tillage Tools

    The emission sound pressure level is primarily dependent on the vehicle used. 5.8 Drivable slope inclination CMS-T-00004990-A.1 Across the slope On left in direction of travel On right in direction of travel MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 49: Performance Characteristics Of The Tractor

    At least 10 l/min at 150 bar HLP68 DIN51524 Implement hydraulic oil The hydraulic oil is suitable for the combined hydraulic oil circuits of all standard tractor manufacturers. Control units Depending on the implement equipment MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 50: Preparing The Implement

    Total weight of front-mounted implement or front ballast Permissible total weight of rear-mounted implement or rear ballast Distance between the centre of gravity of the front-mounted implement or the front ballast and the centre of the front axle MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 51 T b 0,2 T b Vmin Vmin Vmin CMS-I-00000513 2. Calculate the actual front axle load. × × - × G a b T b G c + d Vtat Vtat Vtat CMS-I-00000516 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 52 Tyre load according to according to capacity for two tractor operating calculation tractor tyres manual ≤ Minimum front ballasting ≤ Total weight ≤ ≤ Front axle load ≤ ≤ Rear axle load MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 53: Coupling The Implement

    CMS-I-00000121 Type of actuation Function Symbol Latching Permanent oil circulation Oil circulation until action is Momentary executed Free oil flow in the tractor control Floating unit MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 54 Only use DN16 lines for the pressureless hydraulic oil return flow. Select short return paths. Connect the pressureless hydraulic return flow correctly. Install the supplied coupling sleeve on the pressureless hydraulic oil return. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 55: Coupling The Power Supply

    1 or into an extension cable 2 at the rear of the tractor. 2. Route the camera system cable with sufficient freedom of movement and without chafing or pinching points. CMS-I-00007453 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 56: Coupling The 3-Point Mounting Frame

    2. Remove the safety clip 3 . 3. Slowly lift the soil tillage implement. The pack top seed drill 1 rests in the catching sockets 2 of the soil tillage implement. CMS-I-00003590 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 57 9. Adjust the top link to the desired length. 10. Lift the soil tillage implement with the coupled seed drill. 11. Take the parking supports 1 out of the implement 2 on both sides. CMS-I-00004938 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 58 1 . CMS-I-00003485 14. Connect the supply line 2 for the rear lighting and identification to the soil tillage implement 1 . CMS-I-00004527 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 59: Preparing The Implement For Operation

    CMS-I-00002608 completely lift and lower the implement. To configure the working position sensor, refer to the ISOBUS software operating manual, "Configuring the working position sensor" see "control computer" operating manual. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 60: Using The Hopper Cover

    At lower spread rates, the fill level sensor must be attached in the lower area of the hopper. At higher spread rates, the fill level sensor must be attached in the upper area of the hopper. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 61 The fill level sensor can be set vertically. 6. Tighten the wing nut. NOTE If the fill level sensor is no longer covered, a warning message appears on the control terminal or control computer. CMS-I-00005568 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 62: Installing The Seed Guide Elements

    1. Open the hopper cover. 2. Release the locking mechanism 1 with the universal operating tool 2 . CMS-I-00005769 3. Push the locking plate 1 to the side. The charging sieves can be opened. CMS-I-00005771 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 63: Filling The Hopper

    7. close the hopper cover. CMS-I-00006247 6.3.5 Filling the hopper CMS-T-00008053-A.1 1. lower the implement. 2. Open the hopper cover. 3. Fill the hopper via the charging sieve 1 . 4. close the hopper cover. CMS-I-00005572 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 64: Adjusting The Placement Depth On The Twintec Coulter

    The optimum adjustment can only be determined during field operation. The greatest placement depth is achieved by removing the depth control discs or depth control wheels. CMS-I-00004587 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 65: Adjusting The Coulter Pressure Manually

    2. Put the universal operating tool on the adjustment spindle 1 . NOTE The adjustment of the coulter pressure must be adapted to the respective operating conditions. The optimum adjustment can only be determined during field operation. CMS-I-00004579 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 66 The current coulter pressure is shown on the mechanical coulter pressure display on the front side of the implement. NOTE The scale value only serves for orientation. The scale value does not correspond to a measurement. CMS-I-00005586 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 67 Actuate the "green 1" tractor control unit To reduce the coulter pressure: Actuate the "green 2" tractor control unit. To check the setting: Seed for 30 m at working speed and then check the work pattern. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 68: Adjusting The Coulter Harrow

    To move the harrow tine to the steep working position: Install the pin 4 in hole 2 . To check the setting: seed for 30 m at working speed and then check the work pattern. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 69 The optimum adjustment can only be determined during field operation. 3. Move the harrow bracket 2 to the desired position. CMS-I-00003182 4. Install the bolt 3 . MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 70: Adjusting The Exact Following Harrow

    3. Tighten the bolt 2 with the universal operating tool. 4. Make the same setting for the other side of the implement. To check the setting: Seed for 30 m at working speed and then check the work pattern. CMS-I-00004674 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 71 6.3.11.3 Adjusting the exact following harrow pressure manually CMS-T-00006333-E.1 The exact following harrow pressure must be adjusted such that all seed rows are evenly covered with earth. On heavy soils, the pressure must be higher than on light soils. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 72 1 . 3. Relieve the lever and fasten it in the transport lock. To check the setting: seed for 30 m at working speed and then check the work pattern. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 73 With higher coulter pressure, higher exact following harrow pressure is also set at the same time. 1. Take the lever 1 out of the transport lock 2 and pull it up. CMS-I-00004673 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 74 For seed drills with exact following harrow lift, the exact following harrow can be lifted independently of the position of the coulters. A hydraulic cylinder 1 lifts the exact following harrow. CMS-I-00004703 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 75: Adjusting The Roller Harrow

    1. Raise the implement until the harrow tines no longer touch the ground. To change the working depth of the harrow tines: insert the linch pin 2 above the link 1 . CMS-I-00005162 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 76 4. Take off the universal operating tool and allow the catch 1 to engage in the groove. To check the setting: Seed for 30 m at working speed and then check the work pattern. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 77: Adjusting The Tramline Rhythm

    2 , the coulters are completely lifted. CMS-I-00005600 6.3.13 Adjusting the tramline rhythm CMS-T-00008084-A.1 6.3.13.1 Adjusting the tramline marker CMS-T-00008298-A.1 6.3.13.1.1 Adjusting the track width CMS-T-00004375-F.1 1. Determine the track width a of the cultivating implement. CMS-I-00003195 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 78 Insert the pin in position + . To secure the pin in the adjuster segment: Turn the pin down. To check the setting: Seed for 30 m at working speed and then check the work pattern. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 79 Depending on the track width, the tramline metering wheels created next to each other are positioned differently. 1. Put the universal operating tool 3 on the locking mechanism 2 . CMS-I-00005742 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 80 Move the universal operating tool 2 up. The metering unit cover 1 can be opened. CMS-I-00005740 3. Open the lay shaft bearings 1 . CMS-I-00005651 4. fold down the lay shaft 1 . CMS-I-00005652 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 81 5. Determine the wheelmark width c of the cultivating implement. CMS-I-00003196 6. Determine the track width a of the cultivating implement. CMS-I-00003195 7. Fold down the metering wheel cover 1 . CMS-I-00005653 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 82 CMS-I-00005654 9. Put the spur gear 3 on the seeding shaft 2 . 10. Tighten the bolts 1 . CMS-I-00005655 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 83 14. Loosen the hexagon socket screw 2 . 15. Position the spur gear 1 on the lay shaft under the spur gear 3 of the seeding shaft. 16. Tighten the hexagon socket screw 2 . CMS-I-00005659 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 84 6 | Preparing the implement Preparing the implement for operation 17. Fold up the lay shaft 1 . CMS-I-00005660 18. Close the lay shaft bearings 1 . CMS-I-00005661 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 85: Operating The One-Sided Switching

    On implements with 2 electric metering drives, each half of the seeding shaft is driven by one metering drive. 1. Pull the handles 1 for the couplings to the left side. CMS-I-00005662 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 86: Using The Loading Board Steps

    4. Climb onto the loading board 3 using the steps. 5. After use, swivel the steps up and put them in the parking position. The transport lock locks automatically. CMS-I-00004942 6. Check whether the transport lock is properly locked. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 87: Preparing The Metering Unit For Operation

    Coarse 3/4 open Driven Millet Coarse 3/4 open Driven Lupines Coarse 3/4 open Driven Lucerne Coarse/fine 3/4 open Driven Oilseed (moist Coarse/fine 3/4 open Standstill dressing) Red clover Fine 3/4 open Standstill MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 88 6.3.16.2.1 Removing the seeding shaft halves CMS-T-00011816-A.1 6.3.16.2.1.1 Removing the seeding shaft half that is driven by the coupling CMS-T-00008538-A.1 1. Use the lever 2 to set the bottom flap to scale value 8. CMS-I-00005745 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 89 2 . CMS-I-00005742 To open the locking mechanism: Move the universal operating tool 2 up. The metering unit cover 1 can be opened. CMS-I-00005740 4. Open the lay shaft bearings 1 . CMS-I-00005651 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 90 6 | Preparing the implement Preparing the implement for operation 5. fold down the lay shaft 1 . CMS-I-00005652 6. Loosen the bolt 2 on the gear wheels on the seeding shaft 1 . CMS-I-00005744 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 91 CMS-I-00005741 10. Take off the tension spring 1 . 11. Fold down the chain sprocket 3 . 12. Remove the drive chain 2 . CMS-I-00005724 13. Remove the bolt 1 . CMS-I-00005749 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 92 NOTE When pulling out the seeding shaft halves, make sure that the adjusting rings or coupling parts do not fall into the implement. 16. Pull out the seeding shaft 1 . CMS-I-00005743 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 93 2. Put the universal operating tool 3 on the locking mechanism 2 . CMS-I-00005742 To open the locking mechanism: Move the universal operating tool 2 up. The metering unit cover 1 can be opened. CMS-I-00005740 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 94 6 | Preparing the implement Preparing the implement for operation 4. Open the lay shaft bearings 1 . CMS-I-00005651 5. fold down the lay shaft 1 . CMS-I-00005652 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 95 6. Loosen the bolt 2 on the gear wheels on the seeding shaft 1 . CMS-I-00005744 7. Loosen the bolt 1 on the seeding shaft coupling. 8. Loosen the bolt 1 on the adjusting ring. CMS-I-00005794 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 96 10. Put the universal operating tool 3 on the locking mechanism 2 . To unlock the cover for the chain drive: Turn the universal operating tool clockwise. The cover for the chain drive can be opened. CMS-I-00005793 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 97 CMS-I-00005809 13. Take off the tension spring 1 . 14. Fold down the chain sprocket 3 . 15. Remove the drive chain 2 . CMS-I-00005810 16. Remove the bolt 1 . CMS-I-00005812 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 98 NOTE When pulling out the seeding shaft halves, make sure that the adjusting rings or coupling parts do not fall into the implement. 19. Pull out the seeding shaft 1 . CMS-I-00005814 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 99 To open the metering wheel cover Slightly press in the metering wheel cover on the sides. CMS-I-00005800 2. Take the fine metering wheel 2 and coarse metering wheel 1 out of the metering unit. CMS-I-00005801 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 100 4. Install the bean metering wheel 1 and metering wheel bearing 2 . CMS-I-00005804 5. Insert the bean metering wheel 2 and fine metering wheel 1 into the seed housing. 6. Close the metering wheel cover 3 . CMS-I-00005805 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 101 1. Install the seeding shaft 1 . CMS-I-00005815 2. Put the gear wheel 1 on the seeding shaft 2 . CMS-I-00005813 3. Install the bolt 2 and nut 1 . CMS-I-00005748 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 102 6. Fold up the chain sprocket 3 . 7. Install the tension spring 1 . 8. Close the cover for the chain drive. CMS-I-00006263 9. Tighten the bolts on the adjusting rings. CMS-I-00005746 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 103 Preparing the implement for operation 10. Tighten the bolt 2 . 11. Tighten the bolt 1 . 2 Nm 3 Nm CMS-I-00005863 12. Tighten the bolt 1 on the adjusting ring behind the SmartCenter. CMS-I-00005795 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 104 6 | Preparing the implement Preparing the implement for operation 13. Tighten the bolt 2 on the gear wheels on the seeding shaft 1 . CMS-I-00005744 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 105 6 | Preparing the implement Preparing the implement for operation 14. Fold up the lay shaft 1 . CMS-I-00005660 15. Close the lay shaft bearings 1 . CMS-I-00005661 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 106 The bottom flap lever must always be engaged. 1. Read the required bottom flap position from the "Selecting the setting values" section. 2. Set the bottom flap lever 1 to the desired position. CMS-I-00005783 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 107 1. Put the universal operating tool 1 on the locking mechanism 2 . To unlock the cover for the chain drive: Turn the universal operating tool clockwise. The cover for the chain drive can be opened. CMS-I-00005741 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 108 To select the correct bottom flap position for the calibration: Read the bottom flap position from the table 1 and move the lever 2 to the desired position. CMS-I-00005714 2. Pull out the calibration trough 1 . CMS-I-00005707 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 109 To guide the seed into the calibration trough: Move the calibration lever 1 beyond the latch to the end position. 6. Push the calibration lever back and let it engage in the calibration position. CMS-I-00005715 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 110 "Calibration menu" refer to the "Control computer" operating manual. 10. Fold down the bracket 1 on the ascent. CMS-I-00005700 11. Take the scale 2 and collapsible bucket 1 from the SmartCenter. CMS-I-00005697 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 111: Preparing The Implement For Road Travel

    3. Put the swivel arm 4 into transport position. 4. Peg the swivel arm in transport position 2 . To secure the pin in the adjuster segment, turn the pin down. CMS-I-00003216 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 112: Folding The Tramline Marker On The Exact Following Harrow

    The outer harrow elements can exceed the permissible transport width during transport. To avoid exceeding the permitted transport width, the exact following harrow or seed harrow must be moved into transport position before road transport. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 113: Putting The Road Safety Bars On The Exact Following Harrow

    If the payload is exceeded, the implement can be damaged or/and it can result in uncontrolled driving behaviour of the tractor. Carefully determine the payload of the implement. Never exceed the payload of the implement. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 114 - tare weight 1. Read the permissible technical implement weight from the rating plate. To determine the tare weight, Weigh the implement when the hopper is empty. 3. Calculate the payload. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 115: Using The Implement

    1. Remove the road safety bars 1 from the exact following harrow. CMS-I-00007544 2. Turn the road safety bars 2 by 180°, place on top of each other on the holders 1 . CMS-I-00007545 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 116: Moving The Exact Following Harrow Or Seed Harrow Into Working Position

    3. Tighten the bolt 2 with the universal operating tool. 4. Make the same setting for the other side of the implement. To check the setting: Seed for 30 m at working speed and then check the work pattern. CMS-I-00004674 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 117: Unfolding The Tramline Marker

    5. Put the "yellow" tractor control unit in float position. The tramline marker folds into working position. CMS-I-00005174 7.4 Using the implement CMS-T-00008414-A.1 1. Align the implement parallel to the ground. 2. Lower the implement on the field. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 118: Checking The Placement Depth

    7.6 Turning on the headlands CMS-T-00008416-A.1 NOTE When the implement is lifted, the metering unit is switched off. To prevent lateral loads when driving in curves on the headlands: Lift the implement. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 119 Turning on the headlands To avoid damage to the implement: Pay attention to obstacles when turning. When the direction of the implement matches that of the direction of travel: lower the implement. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 120: Eliminating Faults

    The height of the coulter harrow is See "Adjusting the TwinTeC incorrectly set. coulter" > "Adjusting the harrow height" The harrow tines of the coulter see page 118 harrow are worn. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 121 "Configuring the working position sensor". The lighting for road travel has a Lamp or lighting supply line is Replace the lamp. malfunction. damaged. Replace the lighting supply line. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 122 6. Install the bolt 2 . CMS-I-00003242 To install the TwinTeC seed outlet: place the guides 4 in the coulter bodies 5 . 8. Install the bolt 7 . 9. Install the hose. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 123 4. Replace the inner scraper 2 . 5. Install the bolt. To install the TwinTeC seed outlet: CMS-I-00003245 place the guides 3 in the coulter bodies 4 . 7. Install the bolt. 8. Install the hose. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 124 5. Move the harrow bracket to the desired position. 6. Install the bolt. CMS-I-00004632 7. Install the nut and tighten it. To check the setting: seed for 30 m at working speed and then check the work pattern. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 125 2. Remove the bolts 5 and plates 2 . 3. Replace the harrow tines 3 and 4 . 4. Install the plates and bolts. 5. Install the nuts and tighten them. CMS-I-00004677 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 126 2. Remove the bolt 1 . 3. Remove the plates 4 . 4. Replace the roller 2 . 5. Install the plates. 6. Install the bolt. CMS-I-00005332 7. Install the nut and tighten it. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 127: Parking The Implement

    9.1 Emptying the hopper and metering unit CMS-T-00008484-A.1 1. Pull out the calibration trough 1 . CMS-I-00005707 To collect the seed in the calibration trough Turn the calibration trough with the opening facing CMS-I-00005708 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 128 To guide the seed into the calibration trough: Move the calibration lever 1 beyond the latch to the end position. 6. Push the calibration lever back and let it engage in the calibration position. CMS-I-00007686 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 129 Move the bottom flap lever to the position from the last seeding operation. CMS-I-00005745 To empty the metering wheels via the calibration button or the TwinTerminal: Refer to the ISOBUS software operating manual, "Emptying menu". MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 130 "Checking the basic setting of the bottom flaps". CMS-I-00007493 13. Pull out the calibration trough 1 . 14. Empty the calibration trough. CMS-I-00005760 15. Retract the calibration trough 1 . CMS-I-00005709 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 131: Parking The Twintec Coulter

    3. Disconnect the hydraulic hose lines 1 . 4. Put the dust caps on the hydraulic sockets. CMS-I-00001065 5. Hang the hydraulic hose lines 1 in the hose cabinet. CMS-I-00001250 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 132: Uncoupling The Isobus Or Control Computer

    3. Hang the plug in the hose cabinet. CMS-I-00006891 9.5 Uncoupling the power supply CMS-T-00001402-G.1 1. Pull out the plug 1 for the power supply. CMS-I-00001048 2. Hang the plugs 1 in the hose cabinet. CMS-I-00001248 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 133: Uncoupling The Seeding Combination

    6. Drive the tractor forward. 9.7 Parking the pack top seed drill CMS-T-00008491-A.1 Parking support 1 for implements with RoTeC coulters. Parking support 2 for implements with TwinTeC coulters. CMS-I-00004939 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 134 3. Disconnect the supply line 1 from the soil tillage implement 2 . CMS-I-00004528 4. Disconnect the supply line 2 for the rear lighting and identification from the soil tillage implement CMS-I-00004527 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 135 Remove the parking supports. 7. Install the parking supports 1 on the implement 2 on both sides. CMS-I-00004938 8. Park the soil tillage implement with the coupled pack top seed drill. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 136 The pack top seed drill 1 is standing on the parking supports. 17. Install the safety clips 3 on the soil tillage implement. CMS-I-00003590 18. Slowly drive the tractor with the coupled soil tillage implement 1 forward. CMS-I-00005764 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 137: Repairing The Implement

    Always maintain a minimum distance of 30 cm between the high-pressure nozzle and the implement. Do not exceed a water pressure of 120 bar. Clean the machine with a high-pressure cleaner or a hot water high-pressure cleaner. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 138: Maintaining The Implement

    Checking the TwinTeC depth control wheel see page 136 Checking the cutting discs see page 140 Checking the hydraulic hose lines see page 142 Checking the RoTeC furrow former see page 143 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 139 5. Remove the sealing ring 5 . 6. Remove the central bolts 6 . 17 Nm NOTE The central bolts have different threads: The right central bolt has right-hand thread CMS-I-00003234 The left central bolt has left-hand thread MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 140: Checking The Twintec Cutting Discs

    TwinTeC cutting disc. 4. Remove the bolts 2 . 5. Remove worn TwinTeC cutting discs 1 . 17 Nm 6. Pay attention to the orientation of the sealing ring CMS-I-00003233 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 141: Checking The Twintec Depth Control Wheel Scraper

    Rotate the wheel again. If the TwinTeC depth control wheel scraper cannot be readjusted any further, replace the press roller scraper. 8. Remove the nut and washer. 9. Replace the TwinTeC depth control wheel scraper. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 142: Checking The Twintec Depth Control

    If a RoTeC depth control disc or RoTeC depth control wheel is damaged, replace the RoTeC depth control disc or RoTeC depth control wheel. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 143 To adjust the placement depth: Pull on the lever for the RoTeC depth control disc or RoTeC depth control wheel, move it up and engage it in the desired hole 2 . CMS-I-00004836 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 144: Checking The Tightening Torque For The Radar Sensor Bolts

    1. Put the universal operating tool 1 on the locking mechanism 2 . To unlock the cover for the chain drive: Turn the universal operating tool clockwise. The cover for the chain drive can be opened. CMS-I-00005741 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 145: Lubricating The Drive Chain On The Right Metering Drive

    To unlock the cover for the chain drive: Turn the universal operating tool clockwise. The cover for the chain drive can be opened. CMS-I-00005793 3. Fold up the cover 1 for the chain drive. CMS-I-00005809 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 146: Checking The Cutting Discs

    To replace the cutting disc: remove the bolts 2 on the front side of the cutting disc. 4. Replace the worn cutting disc 1 . 5. Install the bolts. CMS-I-00005324 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 147: Cleaning The Hopper

    3. Push the locking plate 1 to the side. The charging sieves can be opened. CMS-I-00005771 4. Fold up the charging sieve 1 . CMS-I-00005770 5. Clean the hopper. 6. close the hopper cover. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 148: Checking The Lower Link Pins And Top Link Pins

    Hydraulic hose lines must not be more than 6 years old. 3. Check the manufacturing date 1 . CMS-I-00000532 4. Have any worn, damaged or aged hydraulic hose lines immediately replaced at a specialist workshop. 5. Retighten loose bolted connections. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 149: Checking The Rotec Furrow Former

    If the hopper is full, close all of the sliding shutters. 2. Empty the metering wheels, see section "Emptying the hopper and metering unit". 3. Set the bottom flap lever 1 at scale value 1. CMS-I-00005783 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 150: Cleaning The Hand Wash Tank

    To empty the hand wash tank: Open the water tap 1 . 2. Open the screw cap 2 . To remove soiling: Direct a jet of water into the hand wash tank. CMS-I-00005772 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 151: Lubricating The Implement

    Only grease the implement with the lubricants listed in the technical data. CMS-I-00002270 Press the dirty grease completely out of the bearings. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 152: Overview Of Lubrication Points

    10 | Repairing the implement Lubricating the implement 10.3.1 Overview of lubrication points CMS-T-00008506-A.1 CMS-I-00005774 Every 100 operating hours CMS-I-00005328 CMS-I-00003231 Cataya 3000 and Cataya 4000 Cataya 4000 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 153: Lubricating The Drive Chains

    1. Put the universal operating tool 1 on the locking mechanism 2 . To unlock the cover for the chain drive: Turn the universal operating tool clockwise. The cover for the chain drive can be opened. CMS-I-00005741 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 154: Lubricating The Drive Chain On The Right Metering Drive

    To unlock the cover for the chain drive: Turn the universal operating tool clockwise. The cover for the chain drive can be opened. CMS-I-00005793 3. Fold up the cover 1 for the chain drive. CMS-I-00005809 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 155 Lubricating the drive chains 4. Lubricate the drive chain 2 from the inside going out. 5. Check chain tensioner 1 for ease of movement. 6. Close the cover for the chain drive. CMS-I-00006269 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 156: Loading The Implement

    4,000 kg 1. Attach the slings for lifting on the intended lashing points. 2. Slowly lift the implement. 11.2 Lashing the implement CMS-T-00008510-A.1 The implement has 3 lashing points for lashing straps. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 157 1. Put the implement on the transport vehicle. 2. Attach the lashing straps at the marked points. 3. Lash down the implement in compliance with the national regulations for load securing. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 158: Appendix

    CMS-T-00008511-A.1 12.1 Bolt tightening torques CMS-T-00008512-A.1 CMS-I-000260 NOTE Unless specified otherwise, the bolt tightening torques listed in the table apply. 10.9 12.9 M8x1 16(17) M10x1 18(19) M12x1.5 M 14x1.5 M16x1.5 M18x1.5 M20x1.5 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 159: Other Applicable Documents

    1600 2250 2700 CMS-I-00000065 20.4 40.7 70.5 12.2 Other applicable documents CMS-T-00008513-A.1 Tractor operating manual Soil tillage implement operating manual ISOBUS software operating manual AmaDrill software operating manual Control terminal operating manual MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 160: Directories

    Tractor In this operating manual, the designation tractor is always used, even for other agricultural tractor units. Implements are mounted on the tractor or towed by the tractor. MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

  • Page 161: Index

    Track width of the tramline marker cleaning TwinTeC cutting disc distance Implement Agitator shaft support connecting adjustment Camera system Aids Contact data attachment Technical editing Seed guide elements Control computer Coupling the line Uncoupling the ladder MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 162 Coupling the line Uncoupling the ladder Exact following harrow tines adjustment lift-out Roller harrow Faults elimination Lighting and identification for road travel Description filling Hopper loading Fill level sensor Loading board adjustment Position MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 163 Furrow former Placement depth Position adjusting on the TwinTeC coulter adjustment on the RoTeC coulter RoTeC depth control discs checking checking replacing Power supply coupling RoTeC depth control wheels uncoupling checking replacing MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 164 Tramline marker on the implement frame Tramline marker on the seed harrow Total weight calculation Universal operating tool Description Track marker Description unloading Position Tractor Calculating the required tractor characteristics 44 MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 165 13 | Directories Index Warning symbols Description Layout Positions Working depth adjusting the harrow tines on the roller harrow 69 Working position sensor adjusting Work lights Description MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...
  • Page 168 AMAZONEN-WERKE H. DREYER SE & Co. KG Postfach 51 49202 Hasbergen-Gaste Germany +49 (0) 5405 501-0 amazone@amazone.de www.amazone.de MG7371-EN-GB | A.1 | 30.01.2023 | © AMAZONE...

This manual is also suitable for:

Cataya 4000 super

Table of Contents
