Placement and Maintenance

Sigma ™ Office furniture is designed for indoor use on level floors.
Clean glass with glass cleaner, and other surfaces with a moist cloth.
Your Sigma ™ Office furniture is engineered for easy assembly.
Carefully follow this procedure to prevent any damage.
Do not use power tools for assembly of this product.

Step 1

Unpack and identify the parts listed below. The assembly workspace
should be a non-marring surface such as carpet. For missing hardware
pieces, please contact BDI Customer Service at:
customerservice@bdiusa.com.
For all other concerns, please contact your BDI retailer.
Designed by BDI Studio.
These distinctive product configurations are protected by US and international patents, trade dress, and/or
copyright laws. Sigma & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2019, BDI
Made in Turkey. 02.18.2019
SIGMA
6902
TM
RETURN
bdiusa.com
customerservice@bdiusa.com
Hardware:
C1
C2
C3
T1
4mm Hex Wrench x1
H1
M6 x 15mm Screw
x 11
Glass Panel x 1
Frame x 1
Leg x 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIGMA 6902 RETURN and is the answer not in the manual?

Questions and answers

Related Manuals for BDI SIGMA 6902 RETURN

Summary of Contents for BDI SIGMA 6902 RETURN

  • Page 1 Leg x 1 Designed by BDI Studio. These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. Sigma & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2019, BDI Made in Turkey. 02.18.2019...
  • Page 2 Step 2 - Position the frame C2 upside down (end plate facing up). Position the top of the leg C3 over the matching 4 threaded inserts on the cross bar. Attach the leg to the cross bar using screws H1 and hex wrench T1.
  • Page 3 Step 3 - Determine of you want the return on the left or right side of the desk. Find the 3 threaded insert below the front edge (left or right). Thread a screw H1 in half way into the middle insert. With help from another person, position the return so that the notch in the end plate goes around the middle screw.
  • Page 4 Step 4 - Insert screws H1 into the outer holes of the end plate and tighten all screws with hex wrench T1. H1 x 2 bdiusa.com SIGMA 6902 customerservice@bdiusa.com RETURN...
  • Page 5 Step 5 - With the help of another person, position the glass panel C1 over the frame C2 with the larger glass overhang in the front. Align all edges (with glass inset 1/16” or 1.5mm). Attach the glass panel C1 using screws H1 going though the 4 corner plates and tighten with hex wrench.
