- Page 1 Installation and Maintenance Manual MRPW-E Performa Winch 20 STP ™...
- Page 2 Installation Installation procedure Positioning the self-tailing arm Maintenance Washing Maintenance table Disassembly procedure Exploded view with maintenance products Assembly Harken limited worldwide warranty ® Ordering spare parts Exploded view Parts list 20 STP Installation and Maintenance Manual - Mod.E Performa Winch ™...
-
Page 3: Technical Characteristics
® In case of doubt the Harken Tech Service is at your disposal at techservice@harken.it This Manual is available only in English. If you do not fully understand the English language, do not carry out the operations described in this Manual. -
Page 4: Installation
It is the installer's responsibility to carry out all structural tests needed to ensure that the deck can bear the load. ® Harken does not supply the screws needed to install the winch since these may vary depending on the deck on which it is to be installed. - Page 5 Procedure To install the winch, remove the drum and use Socket Head (SH) bolts. Tools needed One medium flat-bladed screwdriver To identify the various parts, refer to the exploded view at the end of this Manual. Torque to apply when assembling 2.
- Page 6 B. Remove the winch and drill the five 6.2 mm diameter holes. ® C. Bolt the base of the winch to the deck using five M6 bolts (not supplied by Harken ), correctly chosen for the thickness and type of the boat deck. Consult the yard that built the boat in case of doubt.
-
Page 7: Maintenance
Installation and maintenance of winches must be carried out exclusively by specialized personnel. ® In the case of doubt contact Harken Tech Service at techservice@harken.it Disassembly procedure Tools needed... - Page 8 Carry out procedure as shown in the paragraph on winch installation and then do the following: 6. Completely unscrew the three screws n°16 7. Remove the stripper arm support n°12 and slide out the bushing 8. Slide out the central shaft n°7 9.
- Page 9 If it is necessary to replace any jaws of the winch, proceed as follows: I. Unscrew the 3 screws n°14 II. Remove the jaws n°19 ( 4Nm/35 in-lb) If it is necessary to remove any pawls in the central shaft, proceed as follows: Unscrew the screw n°10 and remove the washer n°9 ( 4Nm/35 in-lb) Once the winch is completely disassembled, clean the parts with a degreasing that does not leave...
- Page 10 Apply Harken grease: 1. on assy socket screw - 2. on drum gear ® NOTICE On every gear and every component that must be greased, apply Harken grease with a brush in a proper ® quantity as shown below: NOTICE...
- Page 11 Once in position, check that the pawls can be easily opened and closed with a finger. ® In case of doubt concerning the assembly procedure contact Harken Tech Service: techservice@harken.it 20 STP Installation and Maintenance Manual - Mod.E...
-
Page 12: Ordering Spare Parts
Limited Worldwide Warranty in the Harken Catalogue and on the website www.harken.com Ordering spare parts ® Spare parts can be requested from Harken ® described in the Harken Limited Worldwide Warranty, indicating the part number in the Parts List and including the serial number of W XXXXX the winch for which the parts are required. -
Page 13: Exploded View
Exploded view 1/2 20 STP Installation and Maintenance Manual - Mod.E Performa Winch ™... - Page 14 Exploded view 2/2 20 STP Installation and Maintenance Manual - Mod.E Performa Winch ™...
-
Page 15: Parts List
Screw M8x20 UNI 6109 A96620900 Performa W20 Jaws Assembly Lower Jaw W20 Performa Upper Jaw W20 S663760080 Performa Peeler W20 S385970001 Spring *Available with service kit; see website www.harken.com **Winch product sticker 20 STP Installation and Maintenance Manual - Mod.E Performa Winch ™...
