- Page 1 Installation and Maintenance Manual MRPW-D Performa Winch 70.3 STP ™...
- Page 2 Installation Installation procedure Positioning the self-tailing arm Maintenance Washing Maintenance table Disassembly procedure Exploded view with maintenance products Assembly Harken limited worldwide warranty ® Ordering spare parts Exploded view Parts list 70.3 STP Installation and Maintenance Manual - Mod.D Performa Winch ™...
-
Page 3: Technical Characteristics
® In case of doubt the Harken Tech Service is at your disposal at techservice@harken.it ® This Manual is available only in English. If you do not fully understand the English language, do not carry out the operations described in this Manual. -
Page 4: Installation Procedure
It is the installer's responsibility to carry out all structural tests needed to ensure that the deck can bear the load. Harken does not supply the screws needed to install the winch since these may vary depending ®... - Page 5 Follow steps below only to install the winch using Socket Head (SH) bolts 2. Slide off the assy socket n°28 and the cover 1. Unscrew the central screw ( 2Nm/18 in-lb) n°27 3. Unscrew the three screws n°26 4. Remove the stripper arm n°25 by rotating ( 4Nm/35 in-lb) and lifting it.
- Page 6 Follow steps below only to install the winch using hexagonal headed bolts 6. Remove the stripper arm support n°21 7 . Slide out the assy clutch n°36 8. Slide out the central shaft n°19 9. Unscrew the 6 hex screws n°17 ( 20Nm/177 in-lb) Install the winch on the deck in the position you have chosen, keeping in...
- Page 7 ¯205 B. Remove the winch and drill the six 9 mm diameter holes. C. Bolt the base of the winch to the deck using six M8 bolts (not supplied by Harken ), correctly ® chosen for the thickness and type of the boat deck. Consult the yard that built the boat in case of doubt.
-
Page 8: Maintenance Table
Periodic maintenance must be carried out regularly. Lack of adequate maintenance shortens the life of the winch, can cause serious injury and also invalidate the winch warranty. Installation and maintenance of winches must be carried out exclusively by specialized personnel. In the case of doubt contact Harken Tech Service at techservice@harken.it ®... - Page 9 7 . Slide out the assy clutch n°36 8. Slide out the central shaft n°19 9. Unscrew the 6 hex screws n°17 10. Slide out the drum housing n°16. ( 20Nm/177 in-lb) Attention! The gear assembly n°29 remains inside the drum housing 11.
- Page 10 13. Remove the idler and pinion n°14 14. Remove the pawl carrier n°11 15. Remove gear n°10 16. Remove gear n°2 17 . Remove roller bearing n°12 18. Remove roller bearings n°15 70.3 STP Installation and Maintenance Manual - Mod.D Performa Winch ™...
- Page 11 I. Unscrew the 4 screws n°24 II. Remove the jaws n°22 ( 4Nm/35 in-lb) If it is necessary to replace any jaws of the winch, proceed as follows: Inspect balls inside the drum and carefully check the correct position; if it is necessary to put back any balls, push balls in the race (as shown below): Once the winch is completely disassembled, clean the parts with a degreasing that does not leave residues, proper to clean metal components;...
- Page 12 Apply Harken grease: 1. on assy socket screw - 2. on drum gear ® NOTICE On every gear and every component that must be greased, apply Harken grease with a brush in a proper ® quantity as shown below: NOTICE...
- Page 13 In case of doubt concerning the assembly procedure contact Harken® Tech Service: techservice@harken.it 70.3 STP Installation and Maintenance Manual - Mod.D...
-
Page 14: Ordering Spare Parts
Refer to the Harken Limited Worldwide Warranty in the Harken Catalogue and on the website ® ® www.harken.com Ordering spare parts Spare parts can be requested from Harken ® W XXXXX XXXXXXXXX described in the Harken Limited Worldwide ® Warranty, indicating the part number in the Parts List and including the serial number of the winch for which the parts are required. -
Page 15: Exploded View
Exploded view 1/2 70.3 STP Installation and Maintenance Manual - Mod.D Performa Winch ™... - Page 16 Exploded view 2/2 70.3 STP Installation and Maintenance Manual - Mod.D Performa Winch ™...
-
Page 17: Parts Lists
Dog Clutch 3 speed S415420004 Washer Ø17.2xØ32x1.5 S413880002 Spring loaded ball plunger Ø6 M6009463 Winch Serial Number Sticker Stripper arm support S4155700A0 *Available with service kit; see website www.harken.com **Winch product sticker 70.3 STP Installation and Maintenance Manual - Mod.D Performa Winch ™...
