  • Page 1 User manual for art. 1108 Manuale d’uso per art. 1108...
  • Page 2 IMPORTANTE WARNING HQGRZHG ZLWK WKH ¿[WXUH  LQFOXVR QHOO¶DSSDUHFFKLR ,I \RX ZDQW WR FRQQHFW WKH ¿[WXUHV IRU 6H YROHWH XWLOL]]DUH JOL DSSDUHFFKL DUW $03+(12/&211 0) 287'225 XVH \RX FDQ PDNH D QHZ DOO¶(67(512 SRWHWH UHDOL]]DUH GHL FDEOH XWLOL]LQJ WKH RSWLRQDO QXRYL FDYL FRQ DUW $03+(12/&211 0) DUW $03+(12/&211 0)
  • Page 3 INDEX / INDICE Page 5 - Safety informations / Informazioni di sicurezza Page 6 - Introduction / Introduzione Page 7 - Technical features / Caratteristiche tecniche Page 8 - Main supply connection / Collegamento fonte di alimentazione Page 9 - DMX signal connection / Collegamento segnale DMX Page 10 - Example connection DMX controller-spots / Esempio di collegamento centralina DMX-fari Page 11 - Fixture setup by DRS / Settaggio dell’apparecchio tramite DRS Page 12 - DRS functioning / Funzionamento del DRS...
  • Page 4 PHISICAL / MISURE Rel. 01/2013...
  • Page 5 WARNING SAFETY INFORMATION (service personnel) READ ALL CAUTIONS AND WARNINGS PRIOR TO OPERATE THIS EQUIPMENT. INSTRUCTION TO PREVENT INJURY OR DAMAGE DUE TO ELECTRIC SHOCK, FIRE, MECHANICAL HAZARDS, DANGEROUS MATTERS. •PROTECTION AGAINST DANGEROUS MATTERS At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local authority differentiate waste collection centre or to a dealer providing this service.
  • Page 6 BASIC KIT • Projector • 2 AMPHENOL connectors 4 pin male and female (without cable) • User’s manual • Studio Due warranty On request: art. FFB/C: aluminium fast fixing bracket to easy and quick installation WARNING art. 0902/A: barn door to define the illuminated surface art.
  • Page 7 TECHNICAL FEATURES / CARATTERISTICHE TECNICHE SOURCE: 64 (1W) LEDs 16 groups four LEDs (2 warm white, 2 cool white) 4000 total lumen OPTIC: 25mm quad lenses standard beam angle (23°) / ottica quad standard da 23° (25mm diam.) On request: to be confirmed at order / A richiesta: da confermare al momento dell’ordine narrow beam lenses 10°...
  • Page 8 CONNECTION TO THE MAIN POWER / CONNESSIONE ALLA RETE ELETTRICA This equipment must be earthed. Class I equipment. The power supply cord includes a protective earthing conductor as part of the cord. IMPORTANT: to ensure the IP66 protection rating, in case of replacement of the conductor cable, refer to the CONDUCTOR SIZE TABLE Questo apparecchio necessita di messa a terra.
  • Page 9 DMX CONNECTION / CONNESSIONE DMX DMX TERMINAL LINE The wrong connection of the terminal line or its non-connection are probably the most frequent reasons for the defective functioning of the DMX line. The terminator is a terminal resistor fitted at the end of the cable furthest from the transmitter. The terminal resistor should have the same value as the impedance of the connection cable.
  • Page 10 EXAMPLE OF CONNECTION DMX CONTROLLER-SPOT / ESEMPIO DI COLLEGAMENTO CENTRALINA - FARI ([DPSOH  (VHPSLR  '0; RXW /DVW VSRW 8OWLPR VSRW 7HUPLQDWLRQ UHVLVWRU 7HUPLQDOH GL OLQHD ([DPSOH   (VHPSLR  '0;  RXW '0;  RXW /DVW VSRW 8OWLPR VSRW 7HUPLQDWLRQ UHVLVWRU OLQH   OLQHD ...

  • Page 11: Main Power

    SETUP and CONFIGURATION by DRS - DMX REMOTE SETUP SETTAGGIO e CONFIGURAZIONE tramite DRS - DMX REMOTE SETUP The DRS it’s a new concept of professional LED Lighting fixtures suitable for outdoor permanent installations. The LED Lighting fixtures can be driven via DMX through a specific electronic device, the DRS DMX Remote Setup, that grant the possibility to set up the scenarios and the games remotely.
  • Page 12 DRS (DMX Remote Setup) FUNCTIONING To make the set-up of the various fixture parameter, proceed as follow: •Disconnect the fixture to set-up from the other DMX/RDM devices • Connect the DMX cable of the fixture to the DRS commander • Switch on the DRS commander and wait for the 8888 sign •...
  • Page 13 ARCHILED 150 DRS WB MENU’ LIST ELENCO MENU’ ARCHILED 150 DRS WB Switching on the fixture you can see the model and the software version. For example: All’accensione, viene visualizzato il modello di apparecchio e la versione software. Per esempio: -->...
  • Page 14 DMX CHANNELS ARCHILED 150 DRS WB / CANALI DMX ARCHILED 150 DRS WB • 4 Channels mode • 4 Channels mode with Halogen simulation • Modalità 4 Canali • Modalità 4 Canali con simulazione Alogena CH1: White temperature CH1: Halogen Dimmer CH2: Dimmer CH2:...
  • Page 15 DMX Channels list 2Ch / Lista dei canali DMX 2Ch   &K :KLWH WHPSHUDWXUH QRUPDO &K 'LPPHU DMX Channels list 1Ch / Lista dei canali DMX 1Ch   :KLWH &K WHPSHUDWXUH QRUPDO Rel. 01/2013...
  • Page 16 StudioDue 'RF  5(9    light s.r.l. $5&+,/('  '56 :%  'LFKLDUD]LRQH GL FRQIRUPLWj 'HFODUDWLRQ RI FRQIRUPLW\ /D GLWWD 678',2 '8( OLJKW VUO 7KH ILUP 6WUDGD 3RJJLQR   9,7(5%2 ,7$/< GLFKLDUD VRWWR OD SURSULD UHVSRQVDELOLWj FKH LO SURGRWWR GHFODUH XQGHU RXU VROH UHVSRQVDELOLW\ WKDW WKH SURGXFW $5&+,/('  '56 :% ,3 FRGLFH ...

  • Page 17: Warranty Card

    WARRANTY / GARANZIA Warranty CARD &RPSDQ\ QDPH  0U0UV0LVV  $GGUHVV  7HO RU (PDLO   'HDOHU  SALE CONDITIONS 1) Price quoted are not inclusive of lamp and package. Package charge is 2% on the net price for all the items, except for art. 0403 (CS4), that is 4%. These prices should be subject to possible variations for eventual rises of production costs or duties.
  • Page 18 this page is intentionally left blank Rel. 01/2013...
  • Page 19 this page is intentionally left blank Rel. 01/2013...
