  • Page 1 series Li ion battery wireless DMX User manual for art. 1920 Manuale d’uso per art. 1920...
  • Page 2 / questa pagina è stata lasciata intenzionalmente bianca rel. 3_9/19 - Studio Due...
  • Page 3 Page 11 DMX channels list / Lista canali DMX Page 13 Setup configuration / Configurazione e sattaggio Page 16 Physical / Dimensioni Page 17 CE standards / Certificazioni CE Page 19 Warranty / Garanzia EASYCOLOR 12.P rel.3_9/19 - Studio Due...
  • Page 4 3) Gli schermi di protezione e le lenti devono essere sostituiti sempre con ricambi originali se sono visibilmente danneggiati e se la loro efficacia è stata ridotta, per esempio, da fessure o incisioni profonde........................ rel. 3_9/19 - Studio Due...
  • Page 5 • Fixture • IP65 POWERCON Male connector (without cable) • IP65 XLR 5pins Male and Female connectors (without cable) • User manual • Studio Due warranty • CE standards ........................ITA INTRODUZIONE CONTROLLATE CHE L’APPARECCHIO NON ABBIA SUBITO ALCUN DANNO DURANTE IL TRASPORTO. SE AVESSE SUBITO DEI DANNI O SE NON DOVESSE FUNZIONARE, RIVOLGETEVI AL VOSTRO RIVENDITORE.
  • Page 6 51.8V 5.2Ahr - n. 14x2 Samsung cells 26JM - Battery life: 15 hrs (colour changing) DMX channels 4, 5 or 9 Physical 310x135x295 mm Weight 7 Kg example of label on the rear of the fixture rel. 3_9/19 - Studio Due...
  • Page 7 2) Allentare i due nottolini (N) e far scorrere tramite le asole la piastra (P) fino ad incastrarla nella fessura (F-s) superiore della testa dell’apparecchio. 3) Posizionare centralmente il FILTRO e serrare i nottolini (N). optional ANTIGLARE / ANTIABBAGLIAMENTO optional FROST FILTER or HOLOGRAPHIC FILTER / FILTRO FROST o OLOGRAFICO (F-i) (F-s) rel.3_9/19 - Studio Due...
  • Page 8 100-240V.~ / 50-60Hz SIGNAL Line MAIN IN Neutral ON/OFF BUTTON Ingresso rete Pulsante ON/OFF Ground MAIN IN POWERCONN MAIN OUT POWERCONN IP65 connector IP65 connector (endower) (optional) CLOSE THE CAPS WHEN THESE CONNECTIONS ARE NOT USED rel. 3_9/19 - Studio Due...
  • Page 9 CLOSE THE CAPS WHEN THESE CONNECTIONS ARE NOT USED XLR 5pin DMX OUT DMX CONNECTION IP65 connector SIGNAL (endower) XLR 5pin DMX IN GROUND IP65 connector DATA COMPLEMENT (-, inverted) (endower) DATA COMPLEMENT (+, not inverted) rel.3_9/19 - Studio Due...
  • Page 10 fixture / fixture / fixture / fixture / fixture / fixture / apparecchio apparecchio apparecchio apparecchio apparecchio apparecchio apparecchio fixture 1 fixture 1 fixture 2 fixture 3 fixture 4 fixture 2 fixture 3 fixture 4 rel. 3_9/19 - Studio Due...
  • Page 11 0 = CUT TIME LINEAR 25,5 sec. RAINBOW BALANCED 16 - 255 0 - 15 NORMAL WHITE ........................ENG / ITA DMX CHANNELS LIST 5CH / LISTA CANALI DMX 5CH 8 BIT FUNCTION GREEN BLUE WHITE DIMMER rel.3_9/19 - Studio Due...
  • Page 12 DMX CHANNELS LIST 4CH / LISTA CANALI DMX 4CH 8 BIT FUNCTION GREEN BLUE WHITE ........................ENG / ITA TOUCH CONTROL PANEL / PANNELLO DI CONTROLLO TOUCH The touch control panel with buttons / Il pannello di controllo touch con i pulsanti rel. 3_9/19 - Studio Due...
  • Page 13 ESC >> DOWN >> UP >> ENTER DMX led UNLOCK sequence DOWN ENTER 1° 2° 3° 4° 1--- / -2-- / --3- / ---4 To enter the menu Per entrare nel menù ESC / DOWN / UP / ENTER rel.3_9/19 - Studio Due...
  • Page 14 The battery is discharged, the fixture may turn off. Connect as soon as possible the fixture to the Main Power. / La batteria è scarica, l’apparecchio potrebbe spegnersi. Collegare al più presto l’apparecchio alla rete elettrica. rel. 3_9/19 - Studio Due...
  • Page 15 (LdMM) Power LEDS dimmer (with active menu) / Dimmer potenza dei LEDS (con menu attivo) > Select the value off .. on with the UP/DOWN buttons. Press ENTER. > Selezionate il valore desidarato off .. on con i tasti UP/DOWN. Premere ENTER. rel.3_9/19 - Studio Due...
  • Page 16 > Selezionate il colore con i tasti UP/DOWN. Premere ENTER. white > Select the value 0 .. 255 with the UP/DOWN buttons. Don’t press ENTER. > Selezionate il valore desiderato 0 .. 255 con i tasti UP/DOWN. Non premere ENTER. white balance rel. 3_9/19 - Studio Due...
  • Page 17 > Selezionate il valore desiderato hIGh .. MId .. LoW con i tasti UP/DOWN. Premere ENTER. Use this function to optimize the autonomy of the battery. / Usare questa funzione per ottimizzare la durata della batteria. rel.3_9/19 - Studio Due...
  • Page 18 > Selezionate il valore desidarato, per esempio .. 9 .. 4 etc. con i tasti UP/DOWN. Premere ENTER. (vedere pag. canali DMX) Studio Due service parameters (service personnel only) / Parametri di servizio Studio Due (solo personale di servizio) (FLcr) Flicker free function / Funzione flicker free >...
  • Page 19 PHYSICAL / DIMENSIONI 95° 310,00 0° 45° 286,00 135,71 rel.3_9/19 - Studio Due...
  • Page 20 Direttive: and therefore according to essential requirement of Directives: 2004/108/EC – Electromagnetic compatibility 2006/95/EC – Low Voltage directive Data di apposizione PAOLO SENSI Date of marking General Manager VITERBO, 06/05/19 rel. 3_9/19 - Studio Due...
  • Page 21: Warranty Card

    Tutte le apparecchiature godono della garanzia di un anno contro difetti di fabbricazione o di materiali, sono esclusi dalla garanzia danni derivanti da un cattivo uso o installazione delle apparecchiature. Le lampade restano comunque escluse dalla garanzia. Per ogni controversia è competente il Foro di Viterbo. rel.3_9/19 - Studio Due...
  • Page 22 / questa pagina è stata lasciata intenzionalmente bianca rel. 3_9/19 - Studio Due...
  • Page 23 / questa pagina è stata lasciata intenzionalmente bianca rel.3_9/19 - Studio Due...
  • Page 24 Head Office: STUDIO DUE s.r.l. (I) Str. Poggino, 100 - 01100 Viterbo (Italy) tel. +39.0761.352520 fax +39.0761.352653 info@studiodue.com STUDIO DUE (UK) 3 Encon Court Owl Close Moulton Park Industrial Estate Northampton England UK - NN3 6 HZ tel. +44.1933.650.820 info@studiodue.co.uk www.studiodue.com...
