- Page 1 Assembly and Operating Instructions max. 150 kg ~ 30 - 60 Min. Transporation Wheel 128 kg L 172 | W 81 | H 157 CVTM2551.02.07 SKU: CVTM2551 Treadmill...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display Button Functions Battery Compartment First Steps Pause programme - Pause mode End programme - stop mode Programmes 3.7.1 Quick Start 3.7.2 Interval 10/20 and Interval 20/10 3.7.3 Interval Custom 3.7.4 Target Time, Target Distance and Target Calories... - Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Technical Data LCD - display of: Time Speed Distance Calories Heart rate (when using a chest strap) Watt Pace Training programmes overall: Quick Start: Interval programmes: 3 (1 customized) Target programmes: Heart rate controlled programmes: Weight and dimensions: Article weight (gross, incl. -
Page 8: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION The training room should be well ventilated during training and not be exposed to any draughts. Choose the place in which to set up the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. -
Page 10: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 11: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... - Page 12 Philips Pan head full thread screw M4*16...
-
Page 13: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. If you have difficulty recognising the graphics, we recommend that you open and/or download the PDF instructions stored in the webshop on your end device (e.g. - Page 14 Step 3: Assembly of the handrails Attach one handrail (6 & 105) to each of the two upright posts (2 & 3) with two M8*45 bolts (101) and one M8*15 bolt (66) each. Step 4: Mounting the Console Unit Connect the two cables of the right upright post (2) to their corresponding counterparts of the console frame.
- Page 15 Step 6: Assembly of the bottle holder Attach the bottle holder (110) to the left upright post (2) with two M4*16 screws (111). Step 7: Alignment of the feet If the floor is uneven, you can stabilize the treadmill by turning the setting screws under the main frame.
-
Page 16: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Bitte bedenken Sie, dass die Geräuschemission unter Belastung höher ist als ohne Last. Console Display... -
Page 17: Button Functions
Display Description Display of the training time TIME Display range: 00:00-1:59:00 Setting range: 1:00-1:59:00 Display of the training distance DISTANCE Display range: 0.5-100 Setting range: 0,5-100 Display of calories burned CALROIES Display range: 0-2000 Setting range: 1-2000 Heart rate display (when using a chest strap) PULSE Display range: 30-230 Setting range: 30-230... -
Page 18: Battery Compartment
Battery Compartment The console is powered by two AA 1.5V batteries. In case the console is not working properly, the batteries might be running low. Follow the instructions to exchange the batteries. Open the battery compartment cover and remove the batteries. Insert two new AA 1.5V batteries and close the cover again. -
Page 19: Pause Programme - Pause Mode
Pause programme - Pause mode To pause the programme, press the START/PAUSE button once during the workout. During the pause mode, the workout data is shown with a “P” on the display (Fig. 6) and a beep sounds for 0.5 seconds every 30 seconds. NOTICE If the console does not receive any input within 5 minutes while in pause mode, the console goes into standby mode. -
Page 20: Programmes
Programmes A total of seven programmes are available: Quick Start: Interval programmes: Target programmes: Heart rate controlled programme: 3.7.1 Quick Start The quick-start function is ideal if you want to start training immediately. WARNING ⚠ Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. -
Page 21: Interval Custom
3.7.3 Interval Custom WARNING ⚠ Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can affect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. NOTICE Heart rate measurement is only possible with a compatible chest strap. -
Page 22: Target Hr
3.7.5 Target HR WARNING ⚠ Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can affect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. NOTICE Heart rate measurement is only possible with a compatible chest strap. -
Page 23: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 24: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 25: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Display console Plastic covers Screws and cable connections... -
Page 26: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. For treadmills this could for example be a floor mat, which makes your fitness equipment stand more securely and also protects the floor from sweat or silicone spray to keep moving parts in good shape and lubricate the running mat. -
Page 27: Ordering Spare Parts
It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / treadmill Model Name: Run X SKU: CVTM2551... -
Page 28: Parts List
Parts List Name Qty. No. Name Qty. Main frame Driving wheel plate -Aluminum Upright post - right side Aluminum slat fixing belt Upright post - left side EVA mat - t2.0×50×3600 Console frame Front plastic side cover - right side Rear main frame lifting handle Front plastic side cover - left side Handrail - right side... - Page 29 Screw fixing buckle Hex head locknut M10 Screw fixing plate Flat washer Φ10 T shape siderail guider Allen countersunk head full thread screw M6×15 Allen head C.K.S full thread bolt - M8*15 Hexagon head full thread bolt M8×30 Allen head C.K.S full thread bolt - M8*20 Hexagon nut M8 Hexagon head half thread bolt -...
-
Page 30: Exploded Drawing
Exploded Drawing... -
Page 31: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 32 Warranty Service Within the warranty period, equipment which develops faults as a result of material or manufacturing defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty.
-
Page 33: Contact
CONTACT TECHNIK TEKNIK OG SERVICE TECHNIQUE & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 189 530984 +49 4621 4210-945 +49 4621 42 10 933 �� +49 4621 4210-698 �� �� info@fitshop.dk info@fitshop.fr �� technik@sport-tiedje.de ��... - Page 34 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA The Sport-Tiedje Group is Europe’s largest http://www.powerhouse-fitness.co.uk/ specialist for home fitness equipment with www.powerhouse-fitness.co.uk/blog/ currently 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. https://www.facebook.com/powerhousefitness.co.uk Powerhouse Fitness is part of the Sport-Tiedje Group.
- Page 36 Treadmill...
