- Page 1 INSTRUCTION MANUAL FOR WATCH CALIBRE 7T32...
- Page 2 THIS PRODUCT CONTAINS A BUTTON BATTERY If swallowed or placed inside any part of the body, the battery can cause severe or fatal injuries within 2 hours or less. Button batteries are hazardous whether new or used. Keep batteries out of reach of children. If you think the battery may have been swallowed or placed inside any part of the body, seek immediate medical attention.
- Page 3 CAL. Y182, 7T32 ALARM CHRONOGRAPH TIME/CALENDAR Hour & minute hands with small second hand Date displayed in numerals ALARM Can be set on a 12-hour basis with small alarm hands. STOPWATCH Measures up to 30 minutes in 1/5 second increments.
-
Page 4: Display And Crowns/Buttons
DISPLAY AND CROWNS/BUTTONS There are three buttons and two crowns. STOPWATCH STOPWATCH minute hand 1/5-second hand Minute hand (MAIN TIME) Hour hand a b c (MAIN TIME) CROWN 1 Second hand (MAIN TIME) CROWN 2 Date ALARM minute hand ALARM hour hand b: First click a: Normal position c: Second click... -
Page 5: Screw Down Crown
SCREW DOWN CROWN [for models with screw down crown] Unlocking the crown 1 Turn Crown counterclockwise until you no longer feel the threads turning. 2 Crown can be pulled out. Locking the crown 1 Push Crown back in to normal position. 2 Turn Crown clockwise while pressing it lightly until tight. -
Page 6: Date Setting
DATE SETTING CROWN 1 Date 1 Pull out to first click. 2 Turn clockwise until the date for the previous day appears. 3 Pull out to second click and turn until the desired date appears. CROWN 1 4 Push back in to normal position. -
Page 7: Time Setting
TIME SETTING CROWN 1 Hour Minute 1 Pull out to second click when hand hand Second hand is at the 12 o’clock position. 2 Turn to set Hour and Minute hands. 3 Push back in to normal position in accordance with a time signal. CROWN 1 Second hand... -
Page 8: Alarm Setting
ALARM Alarm time is set on a 12-hour basis and indicated by ALARM hour and minute hands that move independently of MAIN TIME hands. ALARM SETTING 1 Adjustment of ALARM hands After the main time is adjusted, follow the procedure below, and then set the alarm. * The following procedure is necessary only after the main time is adjusted. -
Page 9: Alarm Time Setting
2 Alarm time setting * Once ALARM hands are adjusted to the main time, alarm time setting can be made only by following the procedure below. CROWN 2 CROWN 2 Pull out to first click. Press repeatedly to set ALARM hands to the desired alarm time. - Page 10 ALARM ENGAGEMENT/DISENGAGEMENT 1 Alarm engagement 2 Alarm disengagement Push back in to normal CROWN 2 CROWN 2 Pull out to first click. position. Designated Current time alarm time Alarm rings at the designated time for 20 seconds. * To stop it manually, press Button A, B or C, or push CROWN 2 back in to normal position.
-
Page 11: Stopwatch Operation
STOPWATCH Stopwatch measures up to 30 minutes in 1/5 second increments. After 30 minutes, it will start counting again from “0” repeatedly up to 6 hours. STOPWATCH OPERATION Before using the stopwatch: Check that CROWNS 1 and 2 are set at normal position. Press Button B to reset STOPWATCH hands to “0”... - Page 12 TACHYMETER [for models with tachymeter scale on the dial] To measure the hourly average speed of a vehicle Ex. 1 1 Use the stopwatch to determine STOPWATCH how many seconds it takes to second go 1 km or 1 mile. hand: 40 seconds 2 Tachymeter scale indicated by...
- Page 13 “90” (tachymeter scale figure) x 2 (km or mile) = 180 km/h or mph “90” (tachymeter scale figure) x 0.5 (km or mile) = 45 km/h or mph To measure the hourly rate of operation Ex. 1 1 Use the stopwatch to measure STOPWATCH the time required to complete 1 second...
-
Page 14: Adjusting The Hand Position
ADJUSTING THE HAND POSITION If STOPWATCH hands will not return to the 12 o’clock position when the stopwatch is reset or when the battery is replaced with a new one, follow the procedure below. CROWN 1 Pull out to second click. Press repeatedly to reset STOPWATCH minute hand to the 12 o’clock position. -
Page 15: Resetting The Built-In Ic
RESETTING THE BUILT-IN IC In case any of the hands should move improperly, follow the procedure below to adjust the hand movement. CROWN 1 Pull out to second click. Press simultaneously. Push back in to normal CROWN 1 position. CROWN 1... -
Page 16: Notes On Operating The Watch
NOTES ON OPERATING THE WATCH DATE SETTING Do not set the date between 9:00 p.m. and 3:00 a.m. Otherwise, the date may not change properly. * If it is necessary to set the date during that time period, first change the time to any time outside this period, set the date and then reset the correct time. - Page 17 If CROWN 2 is pulled out to first click within 1 minute after being pushed back in to normal position, the alarm sounds. If CROWN 2 is pulled out to second click, the designated alarm time is canceled with a warning beep. * In that case, set ALARM hands to MAIN TIME again, push CROWN 2 back in to normal position, and then, pull it out to first click and set the desired alarm time again.
-
Page 18: Battery Change
When the battery expires, be sure to replace it as soon as possible to prevent any malfunction. We recommend that you contact an AUTHORIZED PULSAR DEALER for battery replacement. Battery life indicator When the battery nears its end, the small second hand moves at two-second intervals instead of normal one-second intervals to indicate that the battery needs to be replaced with a new one. - Page 19 WARNING Do not remove the battery from the watch. If it is necessary to take out the battery, keep it out of the reach of children. If a child swallows it, consult a doctor immediately. Never short-circuit, tamper with or heat the battery, and never expose it to fire.
-
Page 20: To Preserve The Quality Of Your Watch
WATER RESISTANCE Non-water resistant • If the watch becomes wet, have it checked by an AUTHORIZED PULSAR DEALER or SERVICE CENTER. Water resistant 5/10/15/20 bar • Before using in water, be sure the crowns are pushed in completely. • Do not operate the crowns and buttons when the watch is wet or in water. - Page 21 Care should also be taken on diving into water. ** We recommend that you wear a PULSAR Diver’s Watch for scuba diving. TEMPERATURES MAGNETISM...
-
Page 22: Periodic Check
2 to 3 years. Have Years watch or hit it against hard your watch checked by an surfaces, as this may AUTHORIZED PULSAR cause damage. DEALER or SERVICE CENTER to ensure that the case, crowns, buttons, gasket and crystal seal remain intact.
