CAL. NX01
DUO-DISPLAY QUARTZ
Analogue time display
Digital time and calendar
24-hour stopwatch
Countdown timer
Regular alarm
Single-time alarm
Illuminating light (Electroluminescent panel)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NX01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pulsar NX01

  • Page 1 CAL. NX01 DUO-DISPLAY QUARTZ Analogue time display Digital time and calendar 24-hour stopwatch Countdown timer Regular alarm Single-time alarm Illuminating light (Electroluminescent panel)
  • Page 2: Mode Change

    MODE CHANGE With each press, the mode in the digital display changes in the following order: TIME/ REGULAR STOPWATCH TIMER CALENDAR ALARM Press in TIME/CALENDAR mode to show SINGLE-TIME ALARM mode.
  • Page 3: Screw Down Crown

    SCREW DOWN CROWN [for models with screw down crown] Unlocking the crown 1 Turn Crown counterclockwise until you no longer feel the threads turning. 2 Crown can be pulled out. Locking the crown 1 Push Crown back in to normal position. 2 Turn Crown clockwise while pressing it lightly until tight.
  • Page 4: Time/Calendar Mode

    TIME/CALENDAR MODE Before setting the analogue time, be sure to set the digital time. DIGITAL TIME/CALENDAR SETTING Press to show TIME/ Date CALENDAR mode. Press for 2 to 3 seconds. Select the digits to be adjusted. Set the flashing digits. Return to TIME/CALENDAR mode.
  • Page 5 Selection of the digits Seconds Minutes Hour Year Month Date 12-/24-hour indication ANALOGUE TIME SETTING Second hand CROWN Hour hand 1 Pull out when the second hand is Minute hand at the 12 o’clock position. 2 Turn to set the hour and minute hands.
  • Page 6: Demonstration Function

    CHANGEOVER OF DISPLAYS With each press in TIME/CALENDAR mode, the display changes in the following order: Time/calendar Calendar Blank display display display DEMONSTRATION FUNCTION The watch shows the modes and displays in order. Press for 2 to 3 seconds in TIME/CALENDAR mode to start the demonstration.
  • Page 7: Stopwatch Mode

    STOPWATCH MODE The stopwatch measures up to 24 hours in 1/100 second increments for the first hour and in 1 second increments thereafter. Press to show STOPWATCH mode. Start / Stop / Restart Reset...
  • Page 8: Timer Mode

    TIMER MODE The timer can be set up to 9 hours and 59 minutes in minute increments. The remaining time is displayed in seconds. Press to show TIMER mode. TIMER SETTING Press for 2 to 3 seconds. Select the digits to be adjusted (hour/minutes).
  • Page 9: Timer Operation

    TIMER OPERATION Start / Stop / Restart Reset * When the set time is up, a warning sound beeps for 10 seconds. To stop it manually, press any of the buttons.
  • Page 10 REGULAR ALARM MODE The regular alarm can be set to ring on a 24-hour basis. Press to show REGULAR ALARM mode. REGULAR ALARM SETTING Press for 2 to 3 seconds. Select the digits to be adjusted (hour/minutes). Set the flashing digits. Return to REGULAR ALARM mode.
  • Page 11 * The regular alarm mark is automatically displayed and the regular alarm is engaged. ENGAGEMENT/DISENGAGEMENT OF REGULAR ALARM AND HOURLY TIME SIGNAL With each press, the engagement/ disengagement of the regular alarm and hourly time signal are made as follows: Regular alarm engaged Hourly time signal engaged Both engaged...
  • Page 12 SINGLE-TIME ALARM MODE The single-time alarm can be set to ring only once at the designated time. As it rings, it is automatically disengaged. The single-time alarm can be set in minute increments starting from the current time. SINGLE-TIME ALARM SETTING Press to show TIME/ Single-time Designated...
  • Page 13: Illuminating Light (Electroluminescent Panel)

    * At the designated time, the single-time alarm rings for 20 seconds. To stop it manually, press any of the buttons. To cancel the single-time alarm you have set, press buttons C and D at the same time in the SINGLE-TIME ALARM mode, or press button C or D to set the alarm time to the current time.
  • Page 14: Notes On Using The Watch

    ViViDiGi is a new type of liquid crystal panel that makes possible various colors and high contrast. Excellent light reflection and transmission make the display bright and clear. Various color options are available. Either the whole panel or the displayed data only can be illuminated. * Features vary in different models.
  • Page 15 Setting the seconds: • With the second digits flashing, press button D in accordance with a time signal. The second digits are reset to “00”. • When the seconds count any number from “30” to “59” and button D is pressed, one minute is added and the seconds are reset to “00”.
  • Page 16 TIMER MODE [TIMER SETTING] Before setting the desired time for the timer, reset the digits to “0:00'oo” by pressing button D. The flashing digits move quickly if button D is kept pressed. If the watch is left untouched with the digits flashing, it will automatically return to the TIMER mode in 1 to 2 minutes.
  • Page 17 button C to engage/disengage the regular alarm/hourly time signal as desired. SINGLE-TIME ALARM MODE [SINGLE-TIME ALARM SETTING] When button C or D is pressed to set the single-time alarm, the single-time alarm mark “1-AL” is displayed and the single-time alarm is automatically engaged. With each press of button C or D, one minute is advanced or moved back, respectively.
  • Page 18: Battery Change

    When the batteries expire, be sure to replace them as soon as possible to prevent any malfunction. We recommend that you contact an AUTHORIZED PULSAR DEALER for battery replacement. Necessary procedure after battery change After the battery is replaced with a new one or if an abnormal display (broken digits, etc.)
  • Page 19 Press and hold buttons A, B, C and D at the same time for 2 to 3 seconds. When the buttons are released, “12:00'00" a.m., Jan. 1st, 2000, SAT” will be displayed. * Before using the watch, set the time/calendar and then, the alarm. WARNING Do not remove the battery from the watch.
  • Page 20: To Preserve The Quality Of Your Watch

    If the watch becomes wet, we suggest that you Water resistance (10 bar/15 bar/20 bar)* have it checked by an AUTHORIZED PULSAR If “WATER RESISTANT 10 BAR”, DEALER or SERVICE CENTER. “WATER RESISTANT 15 BAR”...
  • Page 21 * Before using the water resistance 5, 10, 15 or 20 bar watch in water, be sure the crown is pushed in completely. Do not operate the crown when the watch is wet or in water. If used in sea water, rinse the watch in fresh water and dry it completely.
  • Page 22: Periodic Check

    2 to 3 years. Have watch or hit it against hard your watch checked by an surfaces, as this may AUTHORIZED PULSAR cause damage. DEALER or SERVICE CENTER to ensure that the case, crown, buttons, gasket and crystal seal remain intact.
  • Page 23: Static Electricity

    CHEMICALS PRECAUTION REGARDING CASE BACK PROTECTIVE FILM Be careful not to expose the watch to solvents, I f y o u r w a t c h h a s a mercury, cosmetic spray, protective film and/or a detergents, adhesives or sticker on the case back, paints.
