Nikon EH-5b - AC Adapter Manual

DC cable

Figure 1:

Power cable

* Shape of cable depends on country.

Introduction

Thank you for your purchase of an EH-5b AC adapter.
Before using the product, thoroughly read both this document and the camera manual.

Notice for customers in Europe

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

This symbol indicates that this product is to be collected separately.

The following apply only to users in European countries:

• This product is designated for separate collection at an appropriate collection point. Do not dispose of as household waste.
• For more information, contact the retailer or the local authorities in charge of waste management.

Safety Precautions

To ensure proper op er a tion, read this man u al thor ough ly be fore us ing this prod uct. Af ter read ing, be sure to keep it where it can be seen by all those who use the prod uct.

Precautions for Use

• Do not use the product with non-compatible devices.
• Unplug the power cable from the power outlet when not in use.
• Do not short the DC plug.
• Do not apply excessive force to the DC plug or cable while the AC adapter and camera are con nect ed. Failure to ob serve this precaution may re sult in mal func tion.
• Do not use with travel converters or adapters designed to convert from one voltage to another or with DC-to-AC inverters. Failure to observe this precaution could damage the product or cause overheating or fire.

Connecting the AC Adapter

Before connecting the AC adapter, be sure the camera is off.
Follow these steps to connect the adapter (Figure 2; illustration shows D700):

Figure 2:

DC-IN connector cover

1. Plug the AC adapter plug into the AC adapter (Figure 2-a).
2. Open the camera DC-IN connector cover and ins ert the DC plug into the DC-IN connect or (Figure 2-b).
3. Plug the wall plug into a pow er outlet (Figure 2-c).
4. Turn the camera on.

When operating the camera with the AC adapter, take care that the camera does not acc id ent all y be come un plugged.

Before disconnecting the AC adapter, be sure the camera is off. Unplug the DC plug from the camera's DC-IN con nec tor, then unplug the pow er cable from the power source by pull ing on the plug, not the cable.

Specifications

Rated input: AC 100–240 V, 50/60 Hz
Rated output: DC 9.0 V, 4.5 A
Operating temperature: 0–40°C (32–104°F)
Dimensions (W × H × D): Approx. 50 × 31 × 110 mm (2.0 × 1.2 × 4.3 in.)
Length of DC cable: Approx. 1.5 m (5 ft.)
Weight: Approx. 255 g (9.0 oz), excluding power cable
Length of power cable: Approx. 1.5 m (5 ft.)

Improvements to this product may result in un an nounced changes to specifications and external appearance.
