8.0 SPECIFICATIONS

8.1 Base Unit Specifications

Measurement Range:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0-100%
Resolution:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.1%
Accuracy and Linearity: . . . . . . . . . . . . . . . . . . 1% of full scale at constant temperature, R.H. and
Total Accuracy: . . . . . . . . . . . . . . . . . . . . .±3% actual oxygen level over full operating temp range
Response Time: . . . . . . . . . . . . . . . . . . . .90% of final value in approximately 15 seconds at 23˚C
Warm-up Time: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . None required
Operating Temperature: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15˚C - 40˚C (59˚F - 104˚F)
Storage Temperature:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -15˚C - 50˚C (5˚F - 122˚F)
Atmospheric Pressure: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800-1013 mBars
Humidity:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0-95% (non-condensing)
Power Requirements:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2, AA Alkaline batteries (2 x 1.5 Volts)
Battery Life: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . approximately 5000 hours with continuous use
Low Battery Indication:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ."BAT" icon displayed on LCD
Sensor Type: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Maxtec MAX-250 series galvanic fuel cell
Expected Sensor Life:. . . . . . . . . . . . . . . . . . . . . . . . . . . > 1,500,000 O
Dimensions:
A Model Dimensions: . . . . . . . . . . . . . . . . 3.0"(W) x 4.0"(H) x 1.5"(D) [76mm x 102mm x 38mm]
A Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.4 lbs. (170g)
AE Model Dimensions: . . . . . . . . . . . . . .3.0"(W) x 36.0"(H) x 1.5"(D) [76mm x 914mm x38mm]
AE Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.6 lbs. (285g)
Drift of Measurement: . . . . . . . . . . . . . . . . . . . . . . . < +/-1% of full scale at constant temperature,

8.2 Sensor Specifications

Type: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Galvanic fuel sensor (0-100%)
Life: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-years in typical applications
9.0 MAXO
2

9.1 Included With Your Unit

Part Number
R217M40
RP76P06
R207P17
R110P10-001
RP16P02
R217P35
10
+ SPARE PARTS AND ACCESSORIES
Item
User's Guide and Operating Instructions
Lanyard
Threaded Adapter with Tygon Tubing
Flow Diverter
Blue Tee Adapter
Dovetail Bracket
866.4.Maxtec
pressure when calibrated at full scale
(2-year in typical medical applications)
Height includes external cable length (retracted)
A Model
www.maxtec.com
percent hours minimum
2
pressure and humidity
AE Model
x x
x x
x
x x
x x
x
