CAL Err lo: Sensor voltage too low
Press and hold the Calibration Button
repeats this error more than three times, contact Maxtec Customer Service for possible replacement.
CAL Err hi: Sensor voltage too high
Press and hold the Calibration Button
repeats this error more than three times, contact Maxtec Customer Service for possible replacement.
CAL Err Bat: Battery voltage too low to recalibrate
Unit is at end of life, see page I for proper disposal.
5.0 CLEANING, MAINTENANCE, AND DISPOSAL
The HANDI+ analyzer requires little maintenance. For best performance and accuracy, the HANDI+
should be calibrated on a frequent basis. For general use, it is recommended the HANDI+ be cali-
brated once a month on a known source of oxygen such as clean dry (compressed) air. Reference the
calibration section in this manual for more details.
If the unit becomes wet, it should be dried off immediately with a soft dry towel. The display may indi-
cate low concentrations of oxygen if the sample port of the sensor becomes wet. In this case, remove
the barbed adapter and thoroughly dry inside and out with a soft dry towel or cotton applicator tip.
Additionally, dry the face of the sensor with a cotton applicator tip and allow to air dry for one half-
hour (or until the oxygen display returns to normal). Exposure of the HANDI+ to water or extremely
high RH may result in shortened life or cause the electronic circuit or battery to fail. Disposal: Please
note the materials of construction for proper disposal. The material of the HANDI+ housing is a poly-
carbonate and ABS blend. The sensing portion of the HANDI+ contains lead and acetic acid. The
HANDI+ contains a printed circuit board and a Lithium Battery.
6.0 SPECIFICATIONS
6.1 Analyzer Specifications
Sensor Type: ....................................................Maxtec MAX-250 galvanic cell w/ Temperature Compensation
Measurement Range: ............................................................................................................ 0.0 - 100.0% oxygen (gas)
Resolution/Display: ............................................................................................................................................................ 0.1%
Over range indicated by one decimal point on display located after the first digit.
Accuracy and Linearity: ................................................... ± 1% of full scale at constant temperature, R.H. and
Response Time: .................................................................................< 15 seconds for 90% step change. (at 25˚C)
866.4.MAXTEC
for three seconds to manually force a new calibration. If unit
for three seconds to manually force a new calibration. If unit
(Non-Replaceable). Extra-Life Oxygen Sensor, galvanic cell type.
The three digit LCD indicates values between 0.0 - 99.9% oxygen.
@ 15˚C - 40˚C pressure when calibrated at full scale.
± 3% actual oxygen level over full operating temperature.
3 WWW.MAXTEC.COM
