» The MAXO
2
disinfectants.
» The MAXO
2
radiation sterilization.
» Store the MAXO
environment of daily use.

7.0 SPECIFICATIONS

7.1 Base Unit Specifications

Measurement Range:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.0-100%
Resolution: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.1%
Accuracy and Linearity: . . . . . . . . . . . . . . . . ±1% of full scale at constant temperature, R.H.
Total Accuracy: . . . . . . . . . . ±3% Actual Oxygen Level over full operating temperature range
Response Time: . . . . . . . . . . . . . . . 90% of final value in approximately 15 seconds at 23°C
Warm-up Time: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . none required
Operating Temperature: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15°C - 40°C (59°F - 104°F)
Storage Temperature:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -15°C - 50°C (5°F - 122°F)
Atmospheric Pressure: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800-1013 mBars
Humidity: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0-95% (non-condensing)
Power Requirements:. . . . . . . . . . . . . . . . . . . . . . . . . 2, AA Alkaline batteries (2 X 1.5 Volts)
Battery Life: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . approximately 3000 hours in typical use
Low Battery Indication: . . . . . . . . . . . . . . . . . . . . . . . . . . "LOW BAT" icon displayed on LCD
Sensor Type: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Maxtec MAX-250 galvanic fuel cell
Expected Sensor Life: . . . . . . . >1,500,000% O
Dimensions: . . . . . . . . . . . . . . . . . . . . 3.5"(W) x 5.5"(H) x 1.5"(D) [89mm x 140mm x 38mm]
Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . approximately .92 lbs. (417g)

7.2 Sensor Specifications

Type: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . galvanic fuel sensor (0-100%)
Life: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 years in typical applications
Interferent
Nitrous Oxide
Carbon Dioxide
Halothane
Enflurane
Isoflurane
Helium
Sevoflurane
Desflurane
8
analyzer may be disinfected using standard topical
®
analyzer is not intended for steam, ethylene oxide or
®
analyzer in a temperature similar to its ambient
®
2
866.4.Maxtec
and pressure when calibrated at full scale
Hours, over 2 years in typical applications
2
Volume % Dry
75%
10%
5%
5%
5%
70%
6%
15%
www.maxtecinc.com
Interference in O2%
<2%
<2%
<2%
<2%
<2%
<2%
<2%
<2%
