Summary of Contents for DCS BE Series
- Page 1 OUTDOOR GRILL 36 & 48" BE models GRIL EXTÉRIEUR Modèles 36 et 48" BE INSTALLATION GUIDE / USER GUIDE GUIDE D’INSTALLATION / GUIDE D’UTILISATION US CA...
- Page 2 DANGER IF YOU SMELL GAS • Shut off gas to the appliance. • Extinguish any open flame. • Open lid. • If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department. WARNING •...
-
Page 3: Table Of Contents
The models shown in this user guide may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, visit our website listed on the back cover or contact your DCS by Fisher & Paykel dealer. - Page 4 DO NOT discard any packing material (box, pallet, straps) until the unit has been inspected. Inspect the product to verify that there is no shipping damage. If any damage is detected, call the shipper and initiate a damage claim. DCS by Fisher & Paykel is not responsible for shipping damage.
-
Page 5: Safety And Warnings
SAFETY AND WARNINGS To reduce the risk of fire, electrical shock, injury to persons, or damage when using the appliance, follow the important safety instructions listed below: WARNING! Hot Surface Hazard Accessible parts may become hot during use. Do not touch surface units or areas near units of the grill. Hood must be opened before lighting the grill. - Page 6 SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! y After a period of storage or non-use (such as over the winter), the gas grill should be checked for gas leaks, deterioration, proper assembly, and burner obstructions before using. y Always use a covered hand when opening the grill hood and only do so slowly to allow heat and steam to escape.
- Page 7 SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS! y Do not obstruct the flow of combustion and ventilation to the grill. y Storage of an outdoor cooking gas appliance indoors is permissible only if the cylinder(s) is (are) disconnected and removed from the outdoor cooking gas appliance. y Cylinders must be stored outdoors out of the reach of children and must not be stored in a building, garage, or any other enclosed area.
-
Page 8: Grill Models
GRILL MODELS BE1-48R BE1-36R BE1-48RCI BE1-36RCI... -
Page 9: Product Dimensions
PRODUCT DIMENSIONS PLAN VIEW PROFILE VIEW FRONT VIEW BE1-36R and BE1-36RCI models PRODUCT DIMENSIONS Inches (mm) 27 1/4" (692) A Overall height of grill 35 15/16" (912) B Overall width of grill C Overall depth of grill 26 7/8" (682) (excluding handle and dials) D Depth of chassis 22"... - Page 10 PRODUCT DIMENSIONS PLAN VIEW FRONT VIEW PROFILE VIEW BE1-48R and BE1-48RCI models PRODUCT DIMENSIONS Inches (mm) 27 1/4" (692) A Overall height of grill 47 15/16" (1217) B Overall width of grill C Overall depth of grill 26 7/8" (682) (excluding handle and dials) D Depth of chassis 22"...
-
Page 11: Installation
INSTALLATION Locating Grill/Built-in Clearances IMPORTANT! Before installation, remove shipping brackets from the grill. Loosen the four screws. Slide the shipping bracket off and re-tighten the screws. Location When determining a suitable location, take into account concerns such as exposure to wind, proximity to traffic paths and keeping any gas or electrical supply lines as short as possible and away from heat sources. - Page 12 INSTALLATION Locating Built-in Clearances PREFERRED AIR FLOW IMPORTANT! Gas fittings, regulator, and installer supplied shut-off valves must be easily accessible. GRILL EXHAUST EXHAUST EXHAUST WIND DIRECTION FLAME LIFT PREFERRED AIR FLOW FIG. 01a FIG. 01b Wind hitting the grill while in use, (especially wind blowing into or across the hood gap) can cause poor performance and in some cases can cause the control panel to get dangerously hot.
- Page 13 INSTALLATION Locating Built-in Clearances Clearances to non-combustible construction* A minimum of 3” (76mm) clearance from the back of the grill to non-combustible construction is required for the purpose of allowing the hood to open fully. It is desirable to allow at least 6” (153mm) rear and side clearance to non-combustible construction above the cooking surface for counter space.
- Page 14 If the grill is to be placed into a combustible enclosure, an approved insulated jacket is necessary. Insulated jackets are available from your dealer. Use only the DCS insulated jacket which has specifically been designed and tested for this purpose. Review the detail drawing shown (Fig. 06) and take into account the provisions shown for gas line hook-up clearance in the right rear corner.
- Page 15 INSTALLATION Locating Built-in Clearances Clearances to protected combustible construction*** A minimum of 12" (305mm) clearance from the sides and rear of grill must be maintained to adjacent vertical protected combustible construction. Intense heat, and large volumes of smoke will exhaust from the rear of the grill.
-
Page 16: Built-In Construction Details
INSTALLATION Built-in Construction Details Standard layout for non-combustible cavity IMPORTANT! If installing the grill into a non-combustible enclosure, all combustible construction must still be outside the 18" (457mm) clearance zone. If your island is made of stucco over the top of wooden studs, the wood can not be inside the 18 inch clearance zone to combustible, even though the stucco is what is touching the grill area. - Page 17 INSTALLATION Built-in Construction Details Standard layout for cavity including insulated jacket Note: 4x4” (102mm x 102mm) opening for gas supply line Note: the cut-out of each corner should be a 90°angle in order for the access doors/ drawers to fit properly. Note: the enclosure should have ventilation holes to prevent gas build-up in the event of a leak.
-
Page 18: Gas Hook-Up
INSTALLATION Gas Hook-up Gas requirements Verify the type of gas supply to be used, either Natural or combustible, and make sure the marking on the appliance rating plate agrees with that of the supply. The rating plate is located on the underside of the drip tray. - Page 19 INSTALLATION Gas Hook-up LP cart hook-up Grills orificed for use with combustible gas come equipped with a high capacity hose/regulator assem bly for connection to a standard 20 lb. combustible gas cylinder (Type 1). The combustible gas tank is not included. The grill system is leak tested, do not remove the Regulator/Hose assembly from the grill during cart installation.
- Page 20 INSTALLATION Gas Hook-up LP built-in hook-up using a 20lb tank If the grill is to be installed in a built-in application, then the grill must be installed in accordance with the built–in installation guidelines and the LP regulator/hose assembly must be removed from the product.
-
Page 21: Leak Testing
INSTALLATION Leak Testing IMPORTANT! Gas leak testing must be carried out by a qualified technician. General Regularly check the whole system for leaks, or immediately check if the smell of gas is detected. Before Testing Do not smoke while leak testing. Extinguish all open flames. Never leak test with an open flame. Make a soap solution of one part liquid detergent and one part water. -
Page 22: Electrical Connection
An approved DCS retro-fit kit and the interconnectivity kit are required to enable this functionality. The DCS retro-fit kit, interconnectivity kit and power splitter can be purchased separately from your local DCS dealer. The retro-fit kit must be installed by a Fisher & Paykel trained and supported service technician. -
Page 23: Burner Adjustment
INSTALLATION Burner Adjustment IMPORTANT! Before lighting, inspect the gas supply piping or hose prior to turning the gas “on”. If there is evidence of cuts, wear, or abrasion, it must be replaced prior to use. U-burner burner air adjustment Each grill burner is tested and adjusted at the factory prior to shipment;... -
Page 24: Radiant Assembly
INSTALLATION Radiant Assembly IMPORTANT! Before assembling the radiant, check that the radiant trays have not moved during transit. They should sit securely on their locating pins in the base of the grill. 1 Locate the radiant in 2 Unpack ceramic rods 3 Unlock radiant end cap the unit. -
Page 25: Installer Checklist
Contact DCS at www.dcsappliances.com if any of the listed items are missing. Please be prepared with your Model #, Serial # and description of item(s) that are missing. Tag location of... -
Page 26: Using The Grill
USING THE GRILL Lighting Instructions Grill lighting instructions IMPORTANT! • Open the grill hood before lighting. Turn all knobs to “OFF”. Turn the main gas supply on. If you smell gas, shut-off gas supply and call for customer care. Only light one burner at a time. Pushing in on the burner knob will activate the Grill Igniter, and then turning the knob from the “OFF”... -
Page 27: Grilling
USING THE GRILL Grilling Each grill section consists of a large stainless steel burner, a series of ceramic rods encased in a stainless steel radiant and a stainless steel heat retaining grate. Below the burners there is a stainless steel heat shield which reflects usable heat upward into the cooking area and reduces temperatures of the drip pan below. - Page 28 USING THE GRILL Grilling Secondary cooking Two racks and one tray have been provided for secondary cooking. These can be utilized for warming, short time smoking (no more than 3 hours), roasting or slow-cooking food. Before using the secondary cooking surfaces with the grill hood down, ensure that the height and width of food or cooking pans is not excessive.
-
Page 29: Using The U-Burners
USING THE GRILL Using the U-burners 1 Ensure that the drip pan and grease tray are in place. 2 Set your grates to preferred position for cooking (referring to flat or angle position plus W side or radius side up) 3 Light the grill burners following the “LIGHTING INSTRUCTIONS”. -
Page 30: Using The Sear Burner (Some Models Only)
USING THE GRILL Using the Sear burner (some models only) 1 Ensure that the drip pan and grease tray are in place. The sear burner should be visually checked before each use. 2 Light the sear burner & the adjacent U Burner following the "LIGHTING INSTRUCTIONS" 3 Once you have verified the sear burner is lit, set to "MAX"... -
Page 31: Grate Positions
USING THE GRILL Grate positions As well as moving the grates to be positioned to your preference along the grill, the dual-sided grates can also be placed flat or in an angled position. If the grates are hot, please use the multi- tool to move the grates or re-position them. -
Page 32: Using The Multi-Tool
USING THE GRILL Using the multi-tool The multi-tool is an accessory that comes included with the grill. This can be used to lift and move grates, lift the charcoal burner lid and adjust the charcoal burner venting filters. It can be used to scrape grease and fat residues into the hole which directs grease down into the drip pan. -
Page 33: Charcoal Insert
USING THE GRILL Charcoal insert IMPORTANT! Do not use lighter-fluid in the charcoal insert or on the grill. The solid fuel will ignite from the burners, it does not need to be lit by a match or butane lighter. 1 Place charcoal, woodchips or briquettes into the insert. Be careful not to overload with solid fuel (one layer of briquettes is recommended). -
Page 34: Using The Rotisserie
USING THE ROTISSERIE IMPORTANT! When connecting your rotisserie motor, first connect the motor to the grill and then plug the grill into the outlet. General The grill rotisserie system is designed to cook items from the back using infrared heat. The location of the burner allows the placement of the secondary cooking tray beneath the food to collect juices and drippings for basting and gravy. - Page 35 USING THE ROTISSERIE IMPORTANT! Do not use the rotisserie burner when the secondary cooking racks or trays are in place. Before using the rotisserie burner, ensure that these racks and trays are removed. Preparation Recommended: dental floss or butcher string, scissors, secondary cooking tray, pliers, meat probe, foil, and hot pads.
- Page 36 USING THE ROTISSERIE To light the rotisserie burner before cooking The location of the rotisserie burner makes it more susceptible to strong wind conditions, more so than the protected grill burners. For this reason you should avoid operating the rotisserie during windy conditions.
- Page 37 USING THE ROTISSERIE Grilling 1 Place prepared rod into motor, lay across 2 Once placement has been verified, ignite and into the rollers on other side. burner and start rotisserie motor. Turn the control knob to the desired setting. 3 To check temperature of the meat, turn off 4 Once finished, turn the motor and rotisserie motor and turn temperature to low while knob to “OFF”.
- Page 38 USING THE ROTISSERIE Rotisserie rod storage The rotisserie rod can be stored in the tray located under the grill head. When storing the rotisserie rods, please use two hands to store it correctly and ensure it is locked into place. Please use two hands to remove the rod from its storage compartment, taking care to ensure it does not drop.
-
Page 39: Accessories
Insulated jacket We recommend purchasing a DCS insulated jacket if installing your grill into a combustible enclosure, as it will reduce the risk of fire, property damage and personal injury. Please see the... -
Page 40: Care And Maintenance
CARE AND MAINTENANCE IMPORTANT! Before each use, inspect the gas supply piping or hose prior to turning the gas “on”. If there is evidence of cuts, wear, or abrasion, on the piping or hose it must be replaced prior to use. Regulator and hose replacement The pressure regulator and hose assembly supplied with the unit must be used. - Page 41 CARE AND MAINTENANCE 304 Stainless steel The grill is made from non-rusting and non-magnetic stainless steel. After initial usage, areas of the grill may discolor from the intense heat given off by the burners, this is normal. There are many different stainless steel cleaners available. Always use the mildest cleaning procedure first, scrubbing in the direction of the grain.
- Page 42 CARE AND MAINTENANCE Removing the sear burner for cleaning 1 Ensure gas supply has been turned off and any 2 Grip the sear burner at the sides and lift up grill grates have been removed. at the rear so the burner is removed from its mount.
- Page 43 CARE AND MAINTENANCE Burner alignment IMPORTANT! Center the burner onto the orifice properly before lighting the grill to prevent fire hazard or explosion. ⁄ ” KNOB VALVE CONTROL BURNER PANEL VALVE VENTURI REMOVE DRIP PAN TO VIEW CONNECTION Fig. 36 Fig.
- Page 44 CARE AND MAINTENANCE Care of the multi-tool y Wash the multi-tool with hot soapy water after each use. y To protect the condition of the natural wood handle, do not store while wet or in direct sunlight. IMPORTANT! Take care when handling and cleaning the multi-tool, as it has sharp edges that could cause injury. Cleaning the charcoal insert: 1 Once cooled, remove the charcoal insert from inside the grill and dispose of the ash safely.
-
Page 45: Troubleshooting
You may save the cost of a service call. Troubleshooting is for general purposes only. If the problem persists and you feel you require service, contact your dealer or the nearest authorized agency to perform service. Only authorized agencies can perform warranty service. Contact DCS at www.dcsappliances.com... -
Page 46: Warranty And Service
WARRANTY AND SERVICE Before you call for service or assistance Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: 1 Your product is correctly installed. 2 You are familiar with its normal operation. 3 Model Number (can be found on the inside, right side panel behind the drip pan handle. - Page 47 WWW.DCSAPPLIANCES.COM © Fisher & Paykel Appliances 2022. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time.
