- Page 1 OUTDOOR GRILL BE1-30AG models Insulated jacket BGB30-IJS INSTALLATION GUIDE US CA 592074B 06.25...
- Page 2 SAFETY AND WARNINGS To reduce the risk of fire, electrical shock, injury to persons, or damage when using the appliance, follow the important safety instructions listed below: WARNING! Hot Surface Hazard Failure to follow this advice may result in burns and scalds or serious injury. •...
- Page 3 SAFETY AND WARNINGS WARNING! WARNING! Hot Surface Hazard Cut Hazard Failure to follow this advice may result in Failure to use caution could result in injury. burns and scalds or serious injury. • Take care: some edges are sharp. • Use only dry pot-holders; moist or damp pot- holders on hot surfaces may cause burns from WARNING steam.
- Page 4 SAFETY AND WARNINGS To reduce the risk of fire, injury to persons or damage when using the appliance, follow WARNING! the important safety instructions listed below. Read all the guidance before using the appliance. Do not use an outdoor cooking gas appliance for purposes other than Fire Hazard intended.
- Page 5 SAFETY AND WARNINGS Fire Gas Requirements Have an ABC rated fire extinguisher accessible – never attempt to extinguish a grease Do not change the regulator/hose assembly from that supplied with the unit or attempt fire with water or other liquids. to use a Type 1 equipped regulator/hose assembly with a standard 510 POL cylinder/ Never leave the product unattended when in use.
- Page 6 HI - Input rates BTU/hr moving parts and hot surfaces. Where the gas piping passes through an opening in the enclosure, the piping must be protected for a distance of at least 2” (50 mm) either MODEL BE1-30AG side of the opening. MAXIMUM 50000 Connection: LP gas hose with a Type 1 quick disconnect and regulator is included.
- Page 7 PRODUCT DIMENSIONS FRONT PROFILE BE1-30AG MODELS PRODUCT DIMENSIONS INCHES A Overall height of grill 10 1/2 B Overall width of grill C Overall depth of grill (excluding dials) 26 7/8 D Depth of chassis 22 1/2 E Width of chassis (including support bracket)
- Page 8 The counter and supporting ledges or deck must be level and flat. Use only the DCS insulated jacket which has specifically been designed and tested for The enclosure should have ventilation holes to prevent gas build-up in the event of a this purpose.
- Page 9 A level should be used to ensure that the unit is level both front-to-back and side-to-side. If it is not level, burner combustion may be erratic or the unit may not function efficiently for grease flow. BE1-30AG MODELS CLEARANCE DIMENSIONS INCHES...
- Page 10 If the grill is to be placed into a combustible enclosure, an approved insulated jacket is necessary. Insulated jackets are available from your dealer. Use only the DCS insulated jacket which has specifically been designed and tested for this purpose.
- Page 11 If all dials are turned , all halos will dim. Multiple DCS Series 9 products may be linked together to allow for cross-product halo illumination. To allow for this functionality, an approved DCS kit is required and can be purchased separately TO OUTLET from your local DCS dealer.
- Page 12 1/2 PSIG (3.5 kPa.). place the installer-supplied gas valve in an accessible location. Total gas consumption of the grill with all burners on HI BE1-30AG: 50,000 Btu/h base of product open top manifold...
- Page 13 GAS CONNECTION CART LP CONNECTION BUILT-IN LP CONNECTION Units set for use with LP gas come equipped with a high capacity hose/regulator assem bly If the grill is to be installed in a built-in application, then the grill must be installed in for connection to a standard 20 lb.
- Page 14 LEAK TESTING CHANGING THE GAS CYLINDER A complete gas tightness check must be performed at the installation site. Periodically check Inspect the gas connection hose every time you change the gas cylinder. Replace hose if there the whole system for leaks, or immediately if the smell of gas is present. are any signs of damage.
- Page 15 BURNER ADJUSTMENT FLAME HEIGHT ADJUSTMENT LOW FLAME ADJUSTMENT Flames should be blue and stable with no yellow tips, excessive noise or lifting (Note: LP The valves on the grill feature an adjustable low setting. Due to fluctuations in gas pressure, units may have some yellow tipping).
- Page 16 RADIANT TRAYS Before assembling the radiant, check that the radiant trays have not moved during transit. They should sit securely on their locating pins in the base of the grill. Unpack ceramic rods and remove radiant from the unit. Unlock radiant end cap by pushing it up with two fingers.
- Page 17 Designed with flexibility in mind, the 30” grill can be either built-in or mounted on a Securing grill to cart freestanding cart. If the grill is to be placed onto a freestanding cart, an approved DCS cart is required and can be purchased separately from your local DCS dealer.
- Page 18 INSTALLER CHECKLIST Read all installation instructions in this manual to see if the unit has been correctly installed. Ensure that installation has been completed correctly before use. Ensure that: specified clearances are maintained to combustibles the low flame setting is satisfactory proper enclosure ventilation has been verified the drip pan is in place properly and sliding freely each burner lights satisfactorily - individually or with adjacent burner lit...
- Page 19 Under our policy of continuous product improvement, these specifications may change at any time. For current details about model and specification availability in your country, please go to our website or contact your local DCS dealer. 592074B 06.25...
