- Page 1 Viva Series Ceramic Vessel Bathroom Sink KCV-200 / KCV-201 / KCV-202 / KCV-203 / KCV-204 / KCV-205 ©...
- Page 2 Thank you for your purchase We would like to take this opportunity to thank you for choosing Kraus. We hope that you are completely satisfied with your purchase, and enjoy it for years to come. If you have any questions, or require technical assistance, please contact us at 800.775.0703 and one of our representatives will be happy to help.
- Page 3 Toll-Free: 800-775-0703 or customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional.
-
Page 4: Tools You Will Need
Tools you will need: Safety Goggles Drill Silicone Adhesive 4" Hole Saw Pencil Tape Measure Dimensions 1 3/4" 1 3/4" Ø 16 1/2" Ø 15 3/4" 5 1/2" 4 3/4" KCV-200 KCV-201 16 1/2" x 5 1/2" 15 3/4" x 4 3/4"... - Page 5 Dimensions 15 5/8" 1 3/4" 1 3/4" 15 5/8" Ø 16 1/2" 5 1/8" 4 3/8" KCV-202 KCV-203 15 5/8" x 15 5/8" x 5 1/8" 16 1/2" x 4 3/8" 1 3/4" 1 3/4" Ø 13" Ø 15 3/4" 4 3/8"...
- Page 6 1. Mark Faucet and Drain Hole Location · Place sink in desired location on countertop and mark drain hole and faucet hole centerline with a pencil. NOTE: Make sure clearance is suitable for backsplash, faucet and sink plumbing NOTE: Please allow a minimum of 3 1/2" from wall to edge of sink for faucet placement clearance 2"...
- Page 7 2. Drill Countertop · Cut the drain opening in the countertop by carefully placing the 4" hole saw on the area marked by pencil. 3. Apply Silicone · Check the alignment of the sink to the opening in the countertop. Use a bead of clear silicone (or preferred adhesive) around the underside of the sink.
- Page 8 4. Install Sink · Carefully place the sink on the countertop, align and press firmly · Allow sealant to set for 30 - 60 minutes NOTE: Use acetone or rubbing alcohol to remove any excess sealant immediately after application 5. Install Plumbing Fixtures ·...
- Page 9 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 10 Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
- Page 11 Please take a moment to share your experience. Visit http://www.kraususa.com/review to let us know what you think about your new Kraus product. Contact Us to Learn More 1.800.775.0703 / www.kraususa.com / customerservice@kraususa.com Like & Follow KrausUSA Download the Kraus Care & Maintenance Guide at: http://www.kraususa.com/maintenance...
