- Page 1 INSTALLATION MANUAL Ceramic Bathroom Vessel Sinks KCV-120 / KCV-121 / KCV-122 / KCV-125 / KCV-126 / KCV-127 KCV-135 / KCV-140 / KCV-141 / KCV-142 / KCV-150 / KCV-341 www.kraususa.com Toll Free: 1.800.775.0703 © 2018 Kraus USA Inc. REV. January 8, 2021...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Toll-Free: 800-775-0703 or customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional. -
Page 4: Tools You Will Need
R 5/8" R 5/8" (15mm) (15mm) 1 5/8" Ø 2 3/4" 1 3/4" (40mm) Ø 2 3/4" (45mm) (70mm) (70mm) KCV-120 KCV-121 15 1/4 " x 15 1/4 " x 5 1/2" 19 1/4" x 15 1/4" x 5 3/8"... - Page 5 Dimensions Ø 1 3/4" 16 3/4" (427mm) (45mm) R2 3/8" 19 3/8" (493mm) Ø 1 3/4" (60mm) (45mm) 10" (255mm) 18 5/8" (473mm) 15 1/4" (387mm) 3/8" 3/4" R 5/8" (10mm) (20mm) (15mm) 11 3/8" Ø 2 3/4" (290mm) (70mm) KCV-122 KCV-125 19 3/8"...
- Page 6 Dimensions 15 3/4" (400mm) Ø 1 3/4" (45mm) Ø 17 3/4" (450mm) Ø 1 3/4" (45mm) R 30" R3 7/8" (100mm) (762mm) Ø 17 1/4" 14 5/8" (372mm) (438mm) 1/4" (6mm) R 3/8" (10mm) R 5/8" Ø 2 3/4" (15mm) (70mm) Ø...
- Page 7 Dimensions 18 5/8" (472mm) Ø 1 3/8" (35mm) Ø 1 3/4" (45mm) Ø 13" Ø 13 3/4" (330mm) (350mm) Ø 1 3/4" 17 3/8" (442mm) (45mm) Ø 1" R 5/8" (25mm) (15mm) Ø 5 1/2" Ø 2 3/4" (70mm) (140mm) KCV-150 KCV-341 Ø...
- Page 8 1. Mark Faucet and Drain Hole Location · Place sink in desired location on countertop and mark drain hole and faucet hole centerline with a pencil. NOTE: Make sure clearance is suitable for backsplash, faucet, and sink plumbing. NOTE: Please allow a minimum of 4.5” from wall to edge of sink for faucet placement clearance.
- Page 9 · · Allow sealant to set for 30 – 60 minutes NOTE: Please make sure Kraus logo is facing you when mounting sink NOTE: Use acetone or rubbing alcohol to remove any excess sealant immediately after application 4. Install Plumbing Fixtures ·...
- Page 10 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 11 Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
- Page 12 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
- Page 13 INSTALLATION MANUAL Ramus Single Lever Vessel Faucet FVS-1007 www.kraususa.com Toll Free: 1.800.775.0703 © 2018 Kraus USA Inc. REV. September 17, 2020...
- Page 14 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 15: Tools Required
Prior to Installation: · Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. · Turn off the hot and cold water supply at the angle stops and turn on the old faucet to release any built up pressure. - Page 16 Diagram and Parts List Faucet Body Aerator Faucet Base A. Base Trim Ring B. Rubber Washer Mounting Hardware A. Rubber Washer B. Metal Washer C. Mounting Nuts D. Mounting Screws Hex Wrench Aerator Key...
-
Page 17: Faucet Dimensions
Faucet Dimensions 6 5/8" (168mm) 3 3/4" (96mm) 20° 5 3/4" Ø 1 3/4" (146mm) (45mm) 1 3/8" (35mm) Ø 2" (50mm) 3/8" Compression Installer Tip: Shut off main water supply before installing new faucet. - Page 18 Faucet Installation Procedure Step 1. Remove rubber washer (4A), metal washer (4B), mounting nut (4C), and mounting screws (4D). Keep the base trim ring (3A) and rubber washer (3B) on the base of the faucet. Step 2. Install the faucet through the 1-3/8"...
- Page 19 Step 3. Install flex water supply lines on the angle stops and tighten with an adjustable wrench. Turn on both the cold and hot main valves Apply pipe tape (optional). Step 4. After installing the faucet, remove the aerator (2) with the included aerator key (6).
-
Page 20: Replacement Parts
Replacement Parts Replacement Parts List Finish/Color Part # 1. Metal Handle CH, SN, ORB, MB, SFS* KP44069 2. Cartridge Cover CH, SN, ORB, MB, SFS* KP44070 3. Locking Nut KP44071 4. Cartridge KP44072 5. Aerator KP44073 CH, SN, ORB, MB, SFS* KP44074 6. -
Page 21: Troubleshooting
Trouble-Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: PROBLEM CAUSE ACTION Adjusting locking nut has come loose. Remove handle index button. Loosen set Leakage under the faucet screw with hex wrench. - Page 22 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 23 This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. KRAUS USA has the right to change, modify, and/or update the warranty policy at any time. For the latest, most up to date comprehensive warranty, go to www.kraususa.com/warranty...
- Page 24 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
- Page 25 Proservice@kraususa.com delay, property damage, or other consequential "Bathroom Accessories" in their original you for your business with Kraus USA. It is our damages, and Kraus accepts no liability for such location. The warranty is non-transferable. sincere hope that you are completely satisfied If you are an Authorized Partner please contact damages.
- Page 26 DIMENSIONS STEP 2 STEP 4 PU-10 DIAGRAM AND PARTS LISTS Install drain body (a), with rubber washer (b) Connect tailpipe (g) to p-trap. PU-L10 Ø 2 5/8" attached, into the drain hole. From underneath, (66.5mm) attach concave washer (c) (narrow end up), plastic washer (d) and mounting nut (e) to drain Ø...
