ISS 608 and ISS 612 • Setup Guide (Continued)
Configure and Recall a Logo Preset
NOTE: User images must first be uploaded via Extron Product Configuration Software (PCS) available at www.extron.com.
To configure a logo preset (see
1.
Press the MENU button (
2.
Press the NEXT button (
3.
[
Rotate the ADJUST
4.
If needed, rotate the ADJUST
5.
Press the NEXT button to adjust the position of the logo.
6.
[
Rotate the ADJUST
position.
7.
Press the NEXT button to select a Logo Key Effect, if desired.
8.
Rotate the left and right ADJUST knobs to select the Logo Key Effect (Transparency, RGB, Level, or Alpha).
To recall a logo preset:
1.
Press the LOGO button (if no logo preset was previously selected, Logo Error shows on the LCD screen for 2 seconds).
2.
[
Rotate the ADJUST
3.
Wait a second or press the NEXT button and the logo preset is recalled onto the preview output.
4.
Press the TAKE button to switch the preview output, with the included logo preset, to the program output using the selected
effect, displaying the logo preset on the program output.
• A different logo preset can be recalled or removed on the preview output by pressing the LOGO button again.
5.
Press the TAKE button again to switch the preview output to the program output.
• If a different logo preset was recalled on the preview output, the new logo preset is displayed on the program output.
• If no logo preset is on the preview output, the logo on the program output is removed.
NOTE: The LOGO button lights solid if there is a logo on preview output but not on program output. The LOGO button
blinks if there is a logo on program output whether there is a logo on preview output or not.
Recall Layout Presets
Layout presets are used to preconfigure a presentation prior to going live. This minimizes missed cues or incorrect video layout. A
layout preset captures transition effect settings, a logo preset, the input channel, and any picture control adjustments made to the
preview output. When recalled, layout presets apply the settings to the preview output to review the configuration before TAKE is
pressed to make it live on the program output.
1.
Press the RECALL/SAVE button (see figure 4,
2.
Rotate either ADJUST knobs to select a saved Layout Preset.
3.
Press the ENTER button to recall the selected preset to the preview output.
Adjust the Size and Position of the Program or Preview
The size and position of the program or preview can be adjusted using the ADJUST SIZE and POSITION buttons (
• Press SIZE or POSITION buttons to toggle between the PREVIEW image and the PROGRAM image adjustments.
) effect is selected, the SIZE and POSITION buttons cycle through the PIP window, PIP image, and
• When the PIP ( C
program image adjustments.

Configure Network Settings

To configure network settings using the front panel controls:
1.
Press MENU ( G ) repeatedly to access the View Comm Settings submenu.
2.
Press and hold NEXT for approximately 5 seconds until the submenu changes to Edit Comm Settings.
4
figure 4 on page 2):
) to go to the Background/Logo Configuration menu.
G
G ) to go to the Logo Select submenu.
knob ( G ) to select the logo preset to configure.
G
{ knob ( ) to change the assigned image file (the image file shows on the preview output).
knob to adjust the horizontal (H) position and rotate the ADJUST
knob to select the logo preset.
on page 2) to go to the Recall Layout menu.
D
knob to adjust the vertical (V)
{
E
).
