- Page 1 MANUAL ENGLISH Spectral M800 Q4 Tour Ordercode: 43570 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
8.3. Calibration reset ...............................19 9. Safety Lock ................................19 10. Information................................19 DMX Channels ................................20 9 channels (TOUR) ..............................20 13 channels (TR16) ..............................22 4 channels (AR1.D) ..............................24 10 channels (8BIT) ..............................24 15 channels (16BI) ..............................26 7 channels (SSP) ...............................28 4 channels (ARC.2) ..............................29 Ordercode: 43570... - Page 3 Spectral M800 Q4 Tour 5 channels (AR2.D) ..............................29 6 channels (AR2.S) ..............................29 Maintenance ..................................30 Troubleshooting ................................30 No Light ..................................30 No Response to DMX..............................30 Product Specifications ..............................32 Dimensions ..................................33 Notes ....................................34 Ordercode: 43570...
-
Page 4: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Spectral M800 Q4 Tour ● Powercon power cable (1,5 m) ●... - Page 5 ● If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 6: Operating Determinations
The Spectral can be placed on a flat stage floor or mounted to any kind of truss with a clamp. Improper installation can cause serious injuries and/or damage of property! Ordercode: 43570... -
Page 7: Connection With The Mains
After this period complaints will not be handled anymore. Complaints will only then be considered if the client has so far complied with all parts of the agreement, regardless of the agreement from which the obligation is resulting. Ordercode: 43570... -
Page 8: Description Of The Device
● Cooling: Convection ● IP Rating: IP-20 ● Dimensions: 180 x 235 x 323 mm (LxWxH) ● Weight: 4,3 kg Front Fig. 01 01) 14 x 3W RGBW LED 02) Mounting brackets with inclination screw 03) Adjustment screw Ordercode: 43570... -
Page 9: Back
Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Connect the device to the main power supply. Ordercode: 43570... -
Page 10: Control Modes
You can use the same functions on the master device as described on pages 14-15 (Static colors or Built-in programs). This means that you can set your desired operation mode on the master device and all slave devices will react the same as the master device. Multiple Spectrals (Master/Slave control) Fig. 03 Ordercode: 43570... -
Page 11: Multiple Spectrals (Dmx Control)
Do not supply power before the whole system is set up and connected properly. Multiple Spectrals DMX Set Up Fig. 04 Note : Link all cables before connecting electric power Ordercode: 43570... -
Page 12: Fixture Linking
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m). The Spectral M800 Q4 Tour can be operated with a controller in control mode or without the controller in stand-alone mode. Ordercode: 43570... -
Page 13: Control Panel
The controller is switched off or defective, the cable or connector is detective, or the signal wires are swapped in the input connector. Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure proper transmission on the DMX data link. Ordercode: 43570... -
Page 14: Menu Overview
Spectral M800 Q4 Tour Menu Overview Ordercode: 43570... -
Page 15: Main Menu Options
, press the UP/DOWN buttons to increase/decrease the strobe frequency. The adjustment range is between 0-20Hz, from OFF to high strobe frequency. 06) You can combine RED, GREEN, BLUE and WHITE to create an infinite range of colors (0-255). Ordercode: 43570... -
Page 16: Built-In And Custom Programs
03) Press the UP/DOWN buttons to choose the desired DMX address. There are 512 available DMX addresses to choose from 5. DMX configuration With this menu you can set the desired DMX channel mode (personality). 01) Press the UP/DOWN buttons until the display shows 02) Press the ENTER button to open the menu. Ordercode: 43570... -
Page 17: Edit Mode
02) In this way you can add a maximum of 30 scenes. 03) After that, you can start with PR.02 and create a maximum of 30 scenes again. 04) You can repeat these steps, until you’ve reached PR.10, step 30. 05) It is possible to create 300 separate scenes. Ordercode: 43570... -
Page 18: Settings
OFF. 04) If you choose OFF, then RGBW and the master dimmer are linear. 05) The dimmer settings do not have any influence on the device’s performance in DMX TOUR mode. The DMX settings override the dimmer settings. Ordercode: 43570... -
Page 19: Dimming Curve Settings
03) Press the UP/DOWN buttons to toggle between the following 2 options: Special strobe Classic strobe 04) If you have chosen , strobe will be active only if you operate the device in one of the following DMX channel modes/personalities: TOUR, TR16, 8BIT, 16BI and SSP. Ordercode: 43570... -
Page 20: Calibration
With this menu you can view the currently installed software version. 01) Press the UP/DOWN buttons until the display shows 02) Press the ENTER button to open the menu. 03) You can now view the currently installed software version. Ordercode: 43570... -
Page 21: Dmx Channels
White 11: 10000K Channel 6 – Classic Strobe (mode is in settings menu (CH1 and CH2, CH3 or CH4 must be set between 1-255 and CH5 between 11-255 0-10 No function 11-255 Strobe flash frequency, from slow to fast (0-20Hz) Ordercode: 43570... - Page 22 Gradual speed adjustment, from slow to fast Channel 9 – Dimmer speed Preset dimmer speed from the device’s menu 10-29 Linear dimmer 30-69 Non-linear dimmer 1 (fastest) 70-129 Non-linear dimmer 2 130-189 Non-linear dimmer 3 190-255 Non-linear dimmer 4 (slowest) Ordercode: 43570...
-
Page 23: Channels (Tr16)
Red 100% / Green 100% / Blue 100% / White 100% 201-205 White 1: 3200K 206-210 White 2: 3400K 211-215 White 3: 4200K 216-220 White 4: 4900K 221-225 White 5: 5600K 226-230 White 6: 5900K 231-235 White 7: 6500K 236-240 White 8: 7200K 241-245 White 9: 8000K Ordercode: 43570... - Page 24 Speed adjustment, from slow to fast Channel 13 – Dimmer speed Preset dimmer speed from the device’s menu 10-29 Linear dimmer 30-69 Non-linear dimmer 1 (fastest) 70-129 Non-linear dimmer 2 130-189 Non-linear dimmer 3 190-255 Non-linear dimmer 4 (slowest) Ordercode: 43570...
-
Page 25: Channels (Ar1.D)
Red 100% / Green Up / Blue Up 151-170 Red Down / Green Down / Blue 100% 171-200 Red 100% / Green 100% / Blue 100% / White 100% 201-205 White 1: 3200K 206-210 White 2: 3400K 211-215 White 3: 4200K Ordercode: 43570... - Page 26 PR.02 141-150 PR.03 151-160 PR.04 161-170 PR.05 171-180 PR.06 181-190 PR.07 191-200 PR.08 201-210 PR.09 211-220 PR.10 221-255 No function Channel 9 – Program speed (CH8 must be set between 21-120 0-255 Speed adjustment, from slow to fast Ordercode: 43570...
-
Page 27: Channels (16Bi)
Fine adjustment Blue from 0-100% Channel 9 – White (CH1 must be set between 1-255 0-255 Gradual adjustment White from 0-100% Channel 10 – Fine White (CH2 must be set between 1-255 0-255 Fine adjustment White from 0-100% Ordercode: 43570... - Page 28 Channel 13 – Built-in programs/Custom programs (CH1 must be set between 1-255 0-20 No function 21-30 AUTO01 31-40 AUTO02 41-50 AUTO03 51-60 AUTO04 61-70 AUTO05 71-80 AUTO06 81-90 AUTO07 91-100 AUTO08 101-110 AUTO09 111-120 AUTO10 121-130 PR.01 131-140 PR.02 141-150 PR.03 Ordercode: 43570...
-
Page 29: Channels (Ssp)
(CH1 and CH2, CH3, CH4 or CH5 must be set between 1-255 No function 10-99 Strobe flash frequency, from slow to fast (0-20Hz) 100-109 No function 110-179 Pulse strobe, from slow to fast 180-189 No function 190-255 Random strobe, from slow to fast Ordercode: 43570... -
Page 30: Channels (Arc.2)
Gradual adjustment, from dark to brightest 0-100% Channel 2 – Red (CH1 must be set between 1-255 0-255 Gradual adjustment Red from 0-100% Channel 3 – Green (CH1 must be set between 1-255 0-255 Gradual adjustment Green from 0-100% Ordercode: 43570... -
Page 31: Maintenance
Suspect two potential problem areas as: the power supply and the LEDs. 01) Power supply. Check that the unit is plugged into an appropriate power supply. 02) The LEDs. Return the Spectral to your Showtec dealer. 03) If both of the above appears to be O.K., plug the unit in again. - Page 32 Turn up the air conditioning. No light or lamp Lamp damaged. ● Disconnect fixture and replace the cuts out lamp. intermittently. The power supply settings do not ● Disconnect fixture. Check settings and match local AC voltage and correct if necessary. frequency. Ordercode: 43570...
-
Page 33: Product Specifications
Spectral M800 Q4 Tour Product Specifications Model: Showtec Spectral M800 Q4 Tour Input voltage: 100-240V AC, 50/60Hz Power consumption: 65W (full output) DMX linking: 30pcs Power linking @120V: 12 units Power linking @230V: 24 units Dimensions: 180 x 235 x 323 mm (LxWxH) -
Page 34: Dimensions
Spectral M800 Q4 Tour Dimensions Ordercode: 43570... -
Page 35: Notes
Spectral M800 Q4 Tour Notes Ordercode: 43570... - Page 36 ©2019 Showtec...
