Summary of Contents for SHOWTEC Colour Star Sky II DMX V4
- Page 1 Colour Star Sky II DMX ORDERCODE 40343...
- Page 2 For more information: iwant@showtec.info You can get some of the best quality, best priced products on the market from Showtec. So next time, turn to Showtec for more great lighting equipment. Always get the best -- with Showtec ! Thank you!
-
Page 3: Table Of Contents
Showtec Showtec Star Sky 2 Product Guide ™ Warning.................…...……………..…………………………….…………. Safety-instructions………………………………………………………………………………………………………. Operating Determinations.…………………………………………………………………………………………… Rigging.…………………………………………………………………………………………………………………… Return Procedure……………………………………………………………………………........Claims……………………………………………………………………………............Description................…...………………………………………….………… Features……………………….………………………………………………………….………………………………… Set Up and Operation..............……..…………………………………….………… DMX Channels..............….........…………………….……………… Controller................…………………….………………………………………… DMX Dip Switch Value Guide............…………………….…………..…………….….. Maintenance...................………..………….…….………………………..Replacing the Fuse..............…………………….……………………………… Troubleshooting................………………….………………….………………... No Light..........………………….…………………………………………………………………. No Response to DMX…………............………………….………………………………... -
Page 4: Showtec Star Sky
Your shipment includes: • Showtec Star Sky 2 with IEC powercable 1,5m • special 5 pin to 3-pin XLR cable 0,9m •... - Page 5 If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 6: Operating Determinations
CAUTION ! EYEDAMAGES !. Avoid looking directly into the light source. (meant especially for epileptics) ! OPERATING DETERMINATIONS This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. The minimum distance between light-output and the illuminated surface must be more than 1 meter. -
Page 7: Return Procedure
Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 8: Description Of The Device
Description of the device Features The Showtec Star Sky 2 is a light effect with great effects. • Total width 6m, total length 3m. • DMX controller, carrying bag included • 7 DMX Channels • 2 Versions available: White LEDs (40342) or Coloured LEDs (40343) •... -
Page 9: Dmx Channels
DMX Protocol 7 Channels Channel 1 – Built-in Programs 0-60 Dimmer (only works for CH4-7. If CH1 is 61-255 then CH4, 5, 6, 7 do not function 61-120 Flash 121-180 Auto Shift 181-240 Fade 241-255 Sound-controlled Channel 2 – Program Speed (when CH1 is set between 61-240 0-20 Stop 21-255... -
Page 10: Dmx Dip Switch Value Guide
Addresses on the controller are set by flipping the appropriate DMX Dip switches. You need to know that DMX address settings are the sum of the dip switch values. A standard DMX address for a Showtec Star Sky, which has 5 channels is as follow: Example... -
Page 11: Troubleshooting
Response: Suspect two potential problem areas: the power supply, the LEDs. 1. Power supply. Check that the unit is plugged into an appropriate power supply. 2. The LED. Return the device to your Showtec dealer. No Response to DMX Response: Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction.
