Model No. INEX81420.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
Decal
USER'S MANUAL
iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NordicTrack u8.9b and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICON NordicTrack u8.9b

Summary of Contents for ICON NordicTrack u8.9b

  • Page 1 Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park OSSETT WF5 9TT UNITED KINGDOM AUSTRALIA Call: 1800 993 770 E-mail: australiacc@iconfitness.com...

  • Page 2: Table Of Contents

    NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks of Google LLC.

  • Page 3: Important Precautions

    To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK U8.9B exercise bike. The U8.9B manual. To help us assist you, note the product model ® exercise bike provides an impressive selection of fea- number and serial number before contacting us.

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 6: Assembly

    ASSEMBLY • Assembly requires two persons. • The following tools (not included) are required for assembly: • Place all parts in a cleared area and remove the one adjustable wrench packing materials. Do not dispose of the packing materials until you finish all assembly steps. one Phillips screwdriver •...
  • Page 7 2. Attach the Front Stabilizer (19) to the Frame (1) with two M8 x 25mm Patch Screws (44), two M8 Split Washers (45), and two M8 x 16mm Washers (110). 3. Have a second person hold the Upright (66) near the Frame (1).
  • Page 8 4. Hold the Left Front Shield (101) against the left side of the Frame (1). Insert the left side of the Wiring Plate (18) into the Left Front Shield. Attach the Left Front Shield (101) with two M4 x 12mm Self-tapping Screws (79); do not fully tighten the Self-tapping Screws yet.
  • Page 9 7. Attach the Front Shield Cover (103) to the Right and Left Front Shields (101, 102) with four M5 x 12mm Screws (111); start all the Screws, and then tighten them. See assembly steps 4 and 5. Tighten the M4 x 12mm Self-tapping Screws (79) and the 101, 102 M4 x 16mm Screws (56).
  • Page 10 9. While a second person holds the Console (106) near the Upright (66), connect the wires (D) on the Console to the matching wires (E) in the Upright. Note: The indicated wires (F) will not be used unless you purchase the optional digital TV (see HOW TO UPGRADE THE CONSOLE on page 15).
  • Page 11 If you purchased the optional MYE receiver to set up a wall of TVs, go to step 11 to install the receiver. If you did not purchase the optional MYE receiver, go to step 12. To order the optional MYE receiver, see the front cover of this manual.
  • Page 12 12. See the inset drawing. To avoid pinching the wires, make sure that the wires (C) from the Handlebar (70) are arranged as shown. Attach the Accessory Tray (99) to the Upright (66) with two M5 x 12mm Screws (111); start both Screws, and then tighten them.
  • Page 13 14. Tip: Avoid pinching the wires. Attach the Front Upright Cover (98) to the Upright (66) with six M5 x 12mm Screws (111); start all the Screws, and then tighten them. Avoid pinching the wires 15. Loosen the Adjustment Knob (35) and pull it outward.
  • Page 14 16. Identify the right Pedal (17). Using an adjustable wrench, firmly tighten the right Pedal clockwise into the Right Crank Arm (9). Firmly tighten the left Pedal (not shown) counterclockwise into the Left Crank Arm (not shown). IMPORTANT: You must turn the left Pedal counterclockwise to attach it.

  • Page 15: How To Upgrade The Console

    HOW TO UPGRADE THE CONSOLE Your console has been preconfigured to operate with an optional digital TV. To learn about the features of the basic console, see page 17. To learn about the features of the digital TV, see the user’s manual included with the digital TV. The basic console has no television capabilities. To upgrade your console to include a digital TV whenever you choose, please see the front cover of this manual.

  • Page 16: How To Use The Exercise Bike

    HOW TO USE THE EXERCISE BIKE HOW TO PLUG IN THE INCLUDED POWER HOW TO CONNECT A COAXIAL CABLE TO THE ADAPTER EXERCISE BIKE If the exercise bike has an optional digital TV, a The exercise bike can be used with or without the included power adapter.
  • Page 17 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can also use the charging port on the console to charge your USB-compatible device while you The console offers an impressive array of features exercise. designed to make your workouts more effective and To activate the console, see page 18.
  • Page 18 HOW TO ACTIVATE THE CONSOLE HOW TO TURN OFF THE CONSOLE If the exercise bike has a basic console, it can be If the pedals are not moved and no buttons are used with or without the power adapter. pressed for a short while, the console will turn off automatically.
  • Page 19 HOW TO USE THE QUICK START MODE To select either the time display or the pace display for continuous display (priority mode), press the left 1. Turn on the console. Mode button repeatedly until a solid light appears next to the desired display. To return to the scan See HOW TO ACTIVATE THE CONSOLE on mode, press the left Mode button until a flashing page 18.
  • Page 20 5. Measure your heart rate if desired. If the display does not show your heart rate, make sure that your hands are positioned as described. You can use the handgrip heart rate monitor or you Be careful not to move your hands excessively or can wear a Polar-compatible chest heart rate moni- to squeeze the contacts tightly.
  • Page 21 HOW TO USE AN ONBOARD PROGRAM Note: The target heart rates are percentages of your maximum heart rate. Your maximum heart 1. Turn on the console. rate is estimated by subtracting your age from 220. For example, if you are 30 years old, your See HOW TO ACTIVATE THE CONSOLE on estimated maximum heart rate is 190 beats per page 18.
  • Page 22 IMPORTANT: The target speed is intended only Race Training Program—Each program is divided to provide motivation. Make sure to exercise at into segments. During the program, the profile an intensity level that is comfortable for you. in the matrix will show your progress. The flash- ing segment of the profile represents the current If the resistance level is too high or too low, you segment of the program.
  • Page 23 HOW TO CONNECT YOUR TABLET TO THE 4. Disconnect your tablet from the console if CONSOLE desired. The console supports Bluetooth connections to tablets To disconnect your tablet from the console, first via the iFit–Smart Cardio Equipment app. Note: Other select the disconnect option in the iFit–Smart Bluetooth connections are not supported.
  • Page 24 Software Version Number—The software version Left Mode button—Press this button to select number will appear in the message banner. a TV source. Total Time and Total Distance—The total number Start button—Press this button to select the of hours that the exercise bike has been used and digit 0.

  • Page 25: Compliance Information

    COMPLIANCE INFORMATION UNITED STATES FCC Statement. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harm- ful interference in a residential installation.

  • Page 26: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE CONSOLE TROUBLESHOOTING Inspect and tighten all parts of the exercise bike If the console does not display your heart rate when regularly. Replace any worn parts immediately. you hold the handgrip heart rate monitor, or if the dis- played heart rate appears to be too high or too low, see To clean the exercise bike, use a damp cloth and a step 5 on page 20.

  • Page 27: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 28: Part List

    PART LIST Model No. INEX81420.0 R0220B Key No. Qty. Description Key No. Qty. Description Frame M5 x 10mm Flat Head Screw Drive Belt Wear Cover Generator M5 x 10mm Nickel Screw M6 x 15mm Flange Screw Left Rear Cover Control Board Right Rear Shield M5 x 10mm Screw M4 x 16mm Screw...
  • Page 29 Key No. Qty. Description Key No. Qty. Description Left Front Shield Rear Stabilizer Right Front Shield C-SAFE Board Front Shield Cover C-SAFE/USB Host Board Screw Shield Clip Console Shelf Front Upright Cover Cap Tablet Shelf Console Pulse Board M8 x 20mm Cap Screw Pulse Board Screw M8 x 12mm Washer USB Host Board...

  • Page 30: Exploded Drawing

    EXPLODED DRAWING A Model No. INEX81420.0 R0220B...
  • Page 31 EXPLODED DRAWING B Model No. INEX81420.0 R0220B...

  • Page 32: Ordering Replacement Parts

    European standards of environmental protection. If you require more information about safe and correct disposal methods, please contact your local city office or the establishment where you purchased this product. Part No. 420100 R0220B Printed in Taiwan © 2020 ICON Health & Fitness, Inc.
