8 T
ECHNICAL DATA
Before and during the heating season, the EU-800 PID controller should be checked for condition of its cables. The user should
also check if the controller is properly mounted and clean it if dusty or dirty. It is advisable to measure earthing parameters for
the motors (CH pump, DHW pump and fan).
No. Specification
1 Power supply
2 Max. power consumption
3 Ambient working temperature
4 Pump max. output load
5 Mixing valve max. output load
6 Fan max. output load
7 KTY sensor thermal resistance
8 Flue gas sensor thermal resistance
9 Fuse
30
230V ±10% /50Hz
11 W
5÷50°C
0,5A
0,5A
0,6A
-30÷99°C
-30÷480°C
3,15A
