- Page 1 Nio 5.8MP Gray 5.8MP high-bright display User Guide MDNG-6221 (option SNEF) MDNG-6221 (option SPEF) MDNG-6221 (option NC EM) ENABLING BRIGHT OUTCOMES...
- Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...
-
Page 3: Table Of Contents
Power lock function..................................25 DPMS mode.......................................25 Hibernate ......................................26 Dry mode ......................................26 Quick Dry mode ....................................27 4.10 Luminance target ....................................27 4.11 Viewing modes ....................................27 4.12 Display functions .....................................28 4.13 Color presets .....................................28 4.14 Ambient Light Compensation (ALC).............................29 K5902142 /07 Nio 5.8MP Gray... - Page 4 Display info ......................................35 4.24 Display status....................................35 5 Cleaning the display ...................................37 Cleaning instructions..................................38 6 Important information..................................39 Safety information...................................40 Cybersecurity ....................................41 Environmental information.................................42 Regulatory compliance information ............................43 EMC notice ......................................45 Explanation of symbols................................47 Legal disclaimer....................................51 Technical specifications................................51 K5902142 /07 Nio 5.8MP Gray...
-
Page 5: Welcome
Welcome! K5902142 /07 Nio 5.8MP Gray... -
Page 6: What's In The Box
• USB cable If you ordered a Barco display controller, it's also in the box together with its accessories. A dedicated user guide is available on the documentation disc. Keep your original packaging. It is designed for this display and is the ideal protection during transport and storage. - Page 7 12. Foot lock clip Always connect the display(s) to a USB 3.0 hub, or if unavailable, to a USB 2.0 hub but then no more than two displays can be connected to the same hub. K5902142 /07 Nio 5.8MP Gray...
- Page 8 Welcome! K5902142 /07 Nio 5.8MP Gray...
-
Page 9: Installation
Installation K5902142 /07 Nio 5.8MP Gray... -
Page 10: Display Controller Installation
The Nio 5.8MP Gray display operates at its full specifications when driven by a Barco MXRT display controller and MXRT driver (which also includes the Barco Intuitive Workflow Tools). If you ordered a MXRT display controller, it is included in the box of your display. -
Page 11: Cable Connections
2.3 Cable connections To connect the cables 1. Open the connector compartment. Do this by gently pushing the two lips on top of the cover, after which it can be removed from the display. K5902142 /07 Nio 5.8MP Gray... - Page 12 5. Route all cables through the cable duct in the stand of your display. For better strain-relief and shielding of the cables, fix the cables with the cable straps at the inside of the connector compartment. K5902142 /07 Nio 5.8MP Gray...
-
Page 13: Mxrt Driver And Intuitive Workflow Tools Installation
About When you are using a Barco MXRT display controller, you can start up your Nio 5.8MP Gray display system and install the MXRT driver and Intuitive Workflow Tools . Barco’s Intuitive Workflow Tools are designed to increase visibility of subtle details, improve focus during reading sessions, and accelerate workflow. -
Page 14: Qaweb Registration
Learn more at www.barco.com/qaweb. To register your display system to your QAWeb Enterprise organization, the QAWeb Enterprise Agent must be installed and running on your workstation and it must be able to communicate with the QAWeb Enterprise cloud service. - Page 15 4. Slide the plastic cover over the neck of the foot. Image 2–12 5. Remove the four screws fixing the foot while supporting the foot. Image 2–13 6. Attach the arm stand firmly to the panel using 4 screws M4 x 8 mm. K5902142 /07 Nio 5.8MP Gray...
- Page 16 Installation K5902142 /07 Nio 5.8MP Gray...
-
Page 17: Daily Operation
Daily operation K5902142 /07 Nio 5.8MP Gray... -
Page 18: Recommendations For Daily Operation
LCD displays use technology based on pixels. As a normal tolerance in the manufacturing of the LCD, a limited number of these pixels may remain either dark or permanently lit, without affecting the diagnostic performance of the product. To ensure optimal product quality, Barco applies strict selection criteria for its LCD panels. -
Page 19: Standby Switching
3.4 OSD menu access About the OSD menu The OSD menu allows you to configure different settings to make your Nio 5.8MP Gray fit your needs within your working environment. Also, you can retrieve general information about your display and its current configuration settings through the OSD menu. -
Page 20: I-Luminate
Please note that text mode is not persistent. Once powered off, the display will restart in diagnostic mode. The diagnostic mode should always be selected when the Nio 5.8MP Gray is intended to be used for screening and diagnosis. - Page 21 Daily operation To quickly change the viewing mode Press the Left / I-Luminate and Right key simultaneously during normal operation (while the OSD menu is not active) to change the viewing mode. K5902142 /07 Nio 5.8MP Gray...
- Page 22 Daily operation K5902142 /07 Nio 5.8MP Gray...
-
Page 23: Advanced Operation
Certain OSD menu settings affecting calibration can be managed by QAWeb. Manually changing these settings in the OSD menu is still possible but the changes will be overwritten at each sync with QAWeb. The OSD menu can also be locked/unlocked by QAWeb. K5902142 /07 Nio 5.8MP Gray... -
Page 24: Osd Menu Language
About the OSD menu language By default, the OSD menu comes up in English. However, there’s a wide range of other languages available for the OSD menu of your Nio 5.8MP Gray. To change the language of the OSD menu: Bring up the OSD main menu. -
Page 25: Key Indicator Lights
About the power lock function By enabling the power lock function, the Nio 5.8MP Gray is forced to remain switched on. This means that it can’t be switched to stand-by mode manually until the power lock function is disabled again. -
Page 26: Hibernate
Dry mode remains enabled until manually disabled. To enable/disable Dry mode on your display: Bring up the OSD main menu. Navigate to the Configuration > Power Management menu. Enter the Dry Mode submenu. Select Enabled/Disabled as desired and confirm. K5902142 /07 Nio 5.8MP Gray... -
Page 27: Quick Dry Mode
4.10 Luminance target About the luminance target The luminance target of your Nio 5.8MP Gray is adjustable over a predefined range. When you change the luminance target, the display will adjust its backlight to reach the target. To set the luminance target: Bring up the OSD main menu. -
Page 28: Display Functions
DICOM: DICOM (Digital Imaging and Communications in Medicine) is an international standard that was developed to improve the quality and communication of digital images in radiology. In short, the DICOM display function results in more visible grayscales in the images. Barco recommends selecting the DICOM display function for most medical viewing applications. -
Page 29: Ambient Light Compensation (Alc)
Please refer to “Ambient Light Compensation (ALC)”, page 29 to enable ALC. The available reading rooms for your Nio 5.8MP Gray are: • CR/DR/ MAMMO: Corresponds to light conditions in diagnostic reading rooms for computed radiology, digital radiology or mammography. This setting has the lowest maximum ambient light. -
Page 30: Embedded Qa
Embedded QA is not a replacement for the Barco QAWeb solution. Although Embedded QA is a reliable option to perform a simple calibration or compliance test, Barco still highly recommends QAWeb as the solution of choice for calibration and QA. QAWeb brings many benefits... -
Page 31: Dicom Compliance Check
OK. To set the DICOM error threshold: Bring up the OSD main menu. Navigate to the Configuration > Calibration > Embedded QA menu. Enter the DICOM Preferences submenu. K5902142 /07 Nio 5.8MP Gray... -
Page 32: Display Orientation
4.19 Image source selection About image source selection The Nio 5.8MP Gray has 4 video inputs: DisplayPort 1, DVI 1, DisplayPort 2 and DVI 2. The input to be displayed is dependent on the selected image source selection mode: •... - Page 33 Bring up the OSD main menu. Navigate to the Configuration > Image Sources menu. Enter the Image Source Selection submenu and select Expert. Enter the Input 1 or Input 2 Image Source submenu and select one of the image sources. K5902142 /07 Nio 5.8MP Gray...
-
Page 34: Grayscale Conversion Modes
Advanced operation 4.20 Grayscale conversion modes Your Nio 5.8MP Gray display automatically detects the connected video input signals and applies the correct grayscale conversion settings. Manually selecting a grayscale conversion mode is possible, but then your display’s image source selection mode should be set to allow this. Please refer to “Image source selection”, page 32... -
Page 35: Display Info
(display function, luminance, ALC, etc.). To retrieve the status of your display: Bring up the OSD main menu. Navigate to the Status menu. Enter the Display, Image Sources or Calibration submenu as desired. K5902142 /07 Nio 5.8MP Gray... - Page 36 Advanced operation K5902142 /07 Nio 5.8MP Gray...
-
Page 37: Cleaning The Display
Cleaning the display K5902142 /07 Nio 5.8MP Gray... -
Page 38: Cleaning Instructions
Do not use sharp objects such as paperclips or tweezers to avoid damage to the LCD. CAUTION: Do not apply or spray liquid directly to the display as excess liquid may cause damage to internal electronics. Instead, apply the liquid to a cleaning cloth. K5902142 /07 Nio 5.8MP Gray... -
Page 39: Important Information
Important information K5902142 /07 Nio 5.8MP Gray... -
Page 40: Safety Information
To fully disengage the power to the device, please disconnect the power cord from the AC inlet. High magnetic environment • The device shall not be used in the high magnetic environment of an MRI scanner. K5902142 /07 Nio 5.8MP Gray... -
Page 41: Cybersecurity
6.2 Cybersecurity Hospital IT security To prevent unauthorized access to the device, the organization incorporating the Nio 5.8MP Gray in their IT network shall have the necessary state-of-the-art policies, processes, standards and other security measures in place to incorporate, support and protect the device into the IT network. This shall include the application of risk management (e.g. -
Page 42: Environmental Information
Electronic Products ” (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”. -
Page 43: Regulatory Compliance Information
Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of environment-friendly use period of electronic information products” of Chinese Mainland. - Page 44 The manufacturing country of the product is indicated on the product label (“Made in …”). Importers contact information To find your local importer, contact one of Barco’s regional offices via the contact information provided on our website (www.barco.com). FCC class B This device complies with Part 15 of the FCC Rules.
-
Page 45: Emc Notice
Electromagnetic emissions The Nio 5.8MP Gray is intended for use in the electromagnetic environment specified below. The customer or the user of the Nio 5.8MP Gray should assure that it is used in such an environment. - Page 46 Important information Electromagnetic immunity The Nio 5.8MP Gray is intended for use in the electromagnetic environment specified below. The customer or the user of the Nio 5.8MP Gray should assure that it is used in such an environment. Electromagnetic Immunity test IEC 60601-1-2 test levels Compliance level environment –...
-
Page 47: Explanation Of Symbols
Indicates compliance with Part 15 of the FCC rules (Class A or Class B). Indicates the device is approved according to the UL regulations Indicates the device is approved according to the UL regulations for Canada and US K5902142 /07 Nio 5.8MP Gray... - Page 48 Indicates the device is approved according to the BIS regulations. IS 13252 (Part 1) IEC 60950-1 R-xxxxxxxx www.bis.gov.in Indicates the device is approved according to the INMETRO regulations. Indicates the USB connectors on the device. Indicates the DisplayPort connectors on the device. K5902142 /07 Nio 5.8MP Gray...
- Page 49 Indicates this device must not be thrown in the trash but must be recycled, according to the European WEEE (Waste Electrical and Electronic Equipment) directive. Indicates Direct Current (DC). Values for xx and yy can be found in the technical specifications paragraph. K5902142 /07 Nio 5.8MP Gray...
- Page 50 Indicates the range of atmospheric pressure to which the device can be safely 106 kPa exposed when being stored. 50 kPa Values for xx and yy can be found in the technical specifications paragraph. K5902142 /07 Nio 5.8MP Gray...
-
Page 51: Legal Disclaimer
Barco software products are the property of Barco. They are distributed under copyright by Barco NV or Barco Inc., for use only under the specific terms of a software license agreement between Barco NV or Barco Inc. and the licensee. No other use, duplication, or disclosure of a Barco software product, in any form, is authorized. - Page 52 Net weight w/o stand MDNG-6221 option SPEF: 6.6 kg MDNG-6221 option SNEF: 5.2 kg Net weight packaged MDNG-6221 option SPEF: 17.0 kg (without optional accessories) MDNG-6221 option SNEF: 15.7 kg (without optional accessories) Tilt -10° to +30° K5902142 /07 Nio 5.8MP Gray...
- Page 53 5 years, including 40000 hrs backlight warranty Operating temperature 0 °C to 40 °C (15 °C to 30 °C within specs) Storage temperature -20 °C to 60 °C Operating humidity 8% to 80% (non-condensing) Storage humidity 5% to 85% (non-condensing) K5902142 /07 Nio 5.8MP Gray...
- Page 54 Output rating: 24 VDC, 6.3 A; 5 VDC, 0.5 A Power consumption 60 W (nominal) < 0.5 W (standby) Dimensions with stand (W x Portrait: 378 x 528~628 x 235 mm H x D) Landscape: 491 x 472~572 x 235 mm K5902142 /07 Nio 5.8MP Gray...
- Page 55 Optional accessories Display controller QA software QAWeb Warranty 3 years, including 20000 hrs backlight warranty Operating temperature 0 °C to 40 °C (15 °C to 30 °C within specs) Storage temperature -20 °C to 60 °C K5902142 /07 Nio 5.8MP Gray...
- Page 56 Important information Operating humidity 8% to 80% (non-condensing) Storage humidity 5% to 85% (non-condensing) Operating pressure 70 kPa minimum Storage pressure 50 to 106 kPa K5902142 /07 Nio 5.8MP Gray...
- Page 58 Barco NV President Kennedypark 35 8500 Kortrijk Belgium K5902142 /07 | 2022-12-13 www.barco.com...
