TEMPERATURE SENSOR RESISTANCE CHARACTERISTICS

9. Temperature sensor resistance characteristics
Outdoor ambient temperature sensor, water side heat exchanger refrigerant inlet/outlet (liquid/gas pipe) temperature
sensor, air side heat exchanger refrigerant outlet temperature sensor and suction pipe temperature sensor resistance
characteristics
Temp. (°C) Res. (kΩ)
-25 144.266
-24 135.601
-23 127.507
-22 119.941
-21 112.867
-20 106.732
-19 100.552
-18 94.769
-17 89.353
-16 84.278
-15 79.521
-14 75.059
-13 70.873
-12 66.943
-11 63.252
-10 59.784
-9 56.524
-8 53.458
-7 50.575
-6 47.862
-5 45.308
-4 42.903
-3 40.638
-2 38.504
-1 36.492
0 34.596
1 32.807
2 31.12
3 29.528
4 28.026
5 26.608
6 25.268
Temp. (°C) Res. (kΩ)
15 16.079
16 15.313
17 14.588
18 13.902
19 13.251
20 12.635
21 12.05
22 11.496
23 10.971
24 10.473
25 10
26 9.551
27 9.125
28 8.721
29 8.337
30 7.972
31 7.625
32 7.296
33 6.982
34 6.684
35 6.401
36 6.131
37 5.874
38 5.63
39 5.397
40 5.175
41 4.964
42 4.763
43 4.571
44 4.387
45 4.213
46 4.046
Temp. (°C) Res. (kΩ)
55 2.841
56 2.734
57 2.632
58 2.534
59 2.44
60 2.35
61 2.264
62 2.181
63 2.102
64 2.026
65 1.953
66 1.883
67 1.816
68 1.752
69 1.69
70 1.631
71 1.574
72 1.519
73 1.466
74 1.416
75 1.367
76 1.321
77 1.276
78 1.233
79 1.191
80 1.151
81 1.113
82 1.076
83 1.041
84 1.007
85 0.974
86 0.942
114
Temp. (°C) Res. (kΩ)
95 0.708
96 0.686
97 0.666
98 0.646
99 0.627
100 0.609
101 0.591
102 0.574
103 0.558
104 0.542
105 0.527
