- Page 1 EVK User Guide Issue 1.0 Date 2022-04-18...
- Page 2 THIS GUIDE PROVIDES INSTRUCTIONS FOR CUSTOMERS TO DESIGN THEIR APPLICATIONS. PLEASE FOLLOW THE RULES AND PARAMETERS IN THIS GUIDE TO DESIGN AND COMMISSION. NEOWAY WILL NOT TAKE ANY RESPONSIBILITY OF BODILY HURT OR ASSET LOSS CAUSED BY IMPROPER OPERATIONS. THE INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE DUE TO PRODUCT VERSION UPDATE OR OTHER REASONS.
-
Page 3: Table Of Contents
3.1.2 Using Alligator Clips......................8 3.1.3 Soldering Cables ......................... 9 3.2 Power on the Module ......................... 10 3.3 Communication Connection ....................... 10 3.4 Antenna Connection ........................10 4 Commissioning ..................12 Copyright © Neoway Technology Co., Ltd. All rights reserved. - Page 4 If these points are not followed, the module or user device may fail. Indicates instructions or tips. This symbol provides advices or suggestions that may be useful when using the module. Copyright © Neoway Technology Co., Ltd. All rights reserved.
-
Page 5: Overview
USB interface to perform module commissioning. N51x EVK provides the following accessories. N510M_EVB_V2.0 (with an N510M or an N511 module) ⚫ Antenna ⚫ USB cable ⚫ Others (power supply adapter, antenna connector, and so on.) ⚫ Copyright © Neoway Technology Co., Ltd. All rights reserved. -
Page 6: Evb Functions
The table below lists the interfaces and the corresponding description of N510M_EVB_V2.0: Button/Interface Function description ANT3 RF SMA interface ANT4 RF SMA interface ANT5 RF SMA interface ANT2 RF SMA interface ANT6 RF SMA interface ANT1 RF SMA interface Copyright © Neoway Technology Co., Ltd. All rights reserved. - Page 7 POWER: power indicator, it is lighted when the module is powered. Indicators SYSTEM: system indicator, it is lighted after the module starts. NET: network status indicator RING: status indicator. Support RC mode PCIe interface EP mode is under development. Copyright © Neoway Technology Co., Ltd. All rights reserved.
-
Page 8: Power Supply And Connection
If the DC power supply is used for the test, use alligator clips to connect the module and supply power to the EVB. The current and the voltage of the external power supply should be consistent with the typical values of the power supply adapter. Copyright © Neoway Technology Co., Ltd. All rights reserved. -
Page 9: Soldering Cables
The specific location is shown in the figure below. In this power supply mode, the voltage range is 3.3 - 4.3 V. It is recommended to use the 3.8 V stabilized power supply. Copyright © Neoway Technology Co., Ltd. All rights reserved. -
Page 10: Power On The Module
The Type-C cable is connected to the Type-C interface on the EVB for USB communications. The USB interface complies with both the USB2.0 and USB3.0 standards. If you want to use the Micro USB interface instead, modify the EVB. For specific modification methods, contact Neoway FAEs. 3.4 Antenna Connection To connect to the wireless network, connect the module with the EVB as shown in the figure below. - Page 11 N51x EVK User Guide Chapter 3 Power Supply and Connection Figure 3-1 N510M module Table 3-1 N511 module Copyright © Neoway Technology Co., Ltd. All rights reserved.
-
Page 12: Commissioning
Step 4: Connect an antenna to the module. Step 5: Power on the module. For details, see Chapter 3.2 . Step 6: Install the USB drivers. For details, see Neoway_N51x_USB_Driver_Installation_Guide_V1.0. Step 7: Perform commissioning using a serial tool. Copyright © Neoway Technology Co., Ltd. All rights reserved.
