- Page 1 N11 EVK User Guide Issue 1.0 Date 2018-06-05 Neoway Product Document...
- Page 2 THIS GUIDE PROVIDES INSTRUCTIONS FOR CUSTOMERS TO DESIGN THEIR APPLICATIONS. PLEASE FOLLOW THE RULES AND PARAMETERS IN THIS GUIDE TO DESIGN AND COMMISSION. NEOWAY WILL NOT TAKE ANY RESPONSIBILITY OF BODILY HURT OR ASSET LOSS CAUSED BY IMPROPER OPERATIONS. THE INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE DUE TO PRODUCT VERSION UPDATE OR OTHER REASONS.
-
Page 3: Table Of Contents
2 Functions and Interfaces ................2 2.1 Top View ............................2 2.2 Buttons and Interfaces ......................... 3 3 Power Supply ................... 4 3.1 5V/2A Adapter ..........................4 3.2 M5X0-PWR Board ........................5 4 Commissioning ..................6 Copyright © Neoway Technology Co., Ltd... - Page 4 N11 EVK User Guide About This Document Scope This document is applicable to N11 series. Audience This document is intended for system engineers (SEs), development engineers, and test engineers. Change History Issue Date Change Changed By 2018-06 Initial draft Chi Cheng...
- Page 5 N11 EVK User Guide Related Documents Neoway_N11_Datasheet Neoway_N11_Product_Specifications Neoway_N11_AT_Command_Manual Neoway_N11_EVK_User_Guide Copyright © Neoway Technology Co., Ltd...
-
Page 6: Overview
UART. N11 EVK is the suite contains the following parts: N11 EVB (including the module) M5X0-PWR power supply board Others (5V/2A adapter, GPRS antenna) Copyright © Neoway Technology Co., Ltd... -
Page 7: Functions And Interfaces
2.1 Top View Neoway Confidential The components marked in red are respectively: N11 module 5V DC input, adapter power supply Switch for main power supply UART1 UART2 UART1 pin jumper Copyright © Neoway Technology Co., Ltd... -
Page 8: Buttons And Interfaces
UART2 Commissioning, download, and power supply, and log capturing for N11 V2 modules Antenna GPRS antenna Power on button. Hold it for 1.2 second to power on the module after power is ON/OFF supplied Copyright © Neoway Technology Co., Ltd... -
Page 9: Power Supply
The EVB uses 5 V power supply. Plug the output end of the adapter to the DC connector on the EVB. Pull the power supply switch to the DC5V side and disconnect the jumper connection. The following figure shows an 5V/2A adapter. Copyright © Neoway Technology Co., Ltd... -
Page 10: M5X0-Pwr Board
Red: VBAT, 3.6 V to 4.5 V, 3.8 V is recommended To use the UART function, install the USB-to-UART driver (PL2303) first. If an MCU is used to control the module, connect the as shown in the following figure: 3.8V Copyright © Neoway Technology Co., Ltd... -
Page 11: Commissioning
Connect the M5X0-PWR board to UART1 of the N11 EVB and your computer. Push the power supply switch to the UART3.8V side, and put the jumper cap of UART1 Hold the ON/OFF button for 1.2 second. The module is started. Copyright © Neoway Technology Co., Ltd... - Page 12 Connect the adapter to the EVB and plug it into a power board. Push the switch to the DC5V side and remove the jumper cap of UART1. Hold the ON/OFF button for 1.2 second. The module is started. Copyright © Neoway Technology Co., Ltd...
- Page 13 N11 EVK User Guide Step 3: Start the commissioning tool and perform commissioning. Copyright © Neoway Technology Co., Ltd...
