Neoway M590E V1 Software Upgrade Manual

Hide thumbs

Advertisement

Quick Links

Neo_M590E V1 GPRS Module
Software Upgrade Guide
Version 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the M590E V1 and is the answer not in the manual?

Questions and answers

Related Manuals for Neoway M590E V1

Summary of Contents for Neoway M590E V1

  • Page 1 Neo_M590E V1 GPRS Module Software Upgrade Guide Version 1.0...
  • Page 2 Neoway provides customers complete technical support. If you have any question, please contact your account manager or email to the following email addresses: Sales@neoway.com...
  • Page 3 Neo_M590E V1 GPRS Module Software Upgrade Guide Revision Record Issue Changes Date V1.0 Initial draft 2016-02-29 Copyright © Neoway Technology Co., Ltd...

  • Page 4: Table Of Contents

    Neo_M590E V1 GPRS Module Software Upgrade Guide Contents 1 Upgrade Interfaces ......................1 2 Upgrade Tools ........................2 3 Cable Connection ......................3 4 Tool Installation ........................ 5 5 Upgrading the Module ..................... 6 Copyright © Neoway Technology Co., Ltd...

  • Page 5: Upgrade Interfaces

    Neo_M590E V1 GPRS Module Software Upgrade Guide About This Document This document describes how to upgrade the M590E V1 module and lists required hardware and software. It provides upgrade instruction for users to commission the module. 1 Upgrade Interfaces M590E V1 support software upgrade through the HOST interfaces.

  • Page 6: Upgrade Tools

     A set of demo board  USB-to-UART cable  Four cable threads of different colors  Pin connector Software tool:  Software upgrade tool  USB-to-UART driver  Software package of the module Copyright © Neoway Technology Co., Ltd...

  • Page 7: Cable Connection

    From the top to the bottom, the threads are respectively: VBAT (red), GND (Black), HOST-RXD (yellow), and HOST-TXD (green). Fix the four cable threads of different colors as shown in the following figure. The following figure shows a pin connector. Copyright © Neoway Technology Co., Ltd...
  • Page 8 Neo_M590E V1 GPRS Module Software Upgrade Guide The following figure shows the cable connection between the demo board and a computer. Copyright © Neoway Technology Co., Ltd...

  • Page 9: Tool Installation

    Decompress the package to any disk or folder. No character of any other languages expect English is allowed in the directory to the tool. Step 2 Open the folder and send the download.exe icon to the desktop. Copyright © Neoway Technology Co., Ltd...

  • Page 10: Upgrading The Module

    Neo_M590E V1 GPRS Module Software Upgrade Guide 5 Upgrading the Module Step 1 Double-click download_english.exe to start the upgrade tool. Copyright © Neoway Technology Co., Ltd...
  • Page 11 Neo_M590E V1 GPRS Module Software Upgrade Guide Step 2 Click Setup. Copyright © Neoway Technology Co., Ltd...
  • Page 12 In the dialog box that is displayed, click the Download tab, select the LOD file for upgrade, and click OK. No character of any other languages expect English is allowed in the directory to the LOD file. Copyright © Neoway Technology Co., Ltd...
  • Page 13 Neo_M590E V1 GPRS Module Software Upgrade Guide Step 4 Connect the demo board to the computer properly, and then click Start all. The upgrade starts. ——End Copyright © Neoway Technology Co., Ltd...
