EVK User Guide
Issue 1.1 Date 2020-01-08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N51 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Neoway N51 Series

  • Page 1 EVK User Guide Issue 1.1 Date 2020-01-08...
  • Page 2 THIS GUIDE PROVIDES INSTRUCTIONS FOR CUSTOMERS TO DESIGN THEIR APPLICATIONS. PLEASE FOLLOW THE RULES AND PARAMETERS IN THIS GUIDE TO DESIGN AND COMMISSION. NEOWAY WILL NOT TAKE ANY RESPONSIBILITY OF BODILY HURT OR ASSET LOSS CAUSED BY IMPROPER OPERATIONS. THE INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE DUE TO PRODUCT VERSION UPDATE OR OTHER REASONS.
  • Page 3: Table Of Contents

    3.1.2 Soldering Power Cable ......................4 3.2 Communication Connection ......................5 3.2.1 M5X0-PWR Board ....................... 5 3.2.2 Micro-USB Cable ......................... 6 4 Commissioning ..................7 4.1 Through Serial Port ........................7 4.2 Through USB Port ........................8 Copyright © Neoway Technology Co., Ltd...
  • Page 4 N51 EVK User Guide About This Document About This Document Scope This document is applicable to the N51 series. Audience This document is intended for system engineers (SEs), development engineers, and test engineers. Change History Issue Date Change Changed By...
  • Page 5 N51 EVK User Guide About This Document Related Documents Neoway_N51_Datasheet Neoway_N51_Product_Specifications Neoway_N51_HW_User_Guide Neoway_N51_AT_Command_Mannual Copyright © Neoway Technology Co., Ltd...
  • Page 6: Overview

    N51 EVK provides the following items: N51_EVB_V1.0 (including N51 module) ⚫ M5X0-PWR power cable ⚫ Micro-USB cable ⚫ Others (5V/2A power adapter, 2G/3G antennas) ⚫ Copyright © Neoway Technology Co., Ltd...
  • Page 7: About N51 Evb

    Table 2-1 lists each interface or button and their functions. Table 2-1 Interfaces and button of N51 EVB Interface/Button Description N51_EVB_V1.0 EVB model Cellular module 5V DC power port Main power supply, input 5V/2A Power switch ON/OFF Copyright © Neoway Technology Co., Ltd...
  • Page 8 It is in DNI state. SIM2 card connector. It does not support SIM detection. SIM2 connector Not supported. Not supported Not supported GPIO test interfaces Not supported USB port To download firmware 3*3 keypad Not supported Copyright © Neoway Technology Co., Ltd...
  • Page 9: Power And Connection

    3.1.2 Soldering Power Cable The N51 EVB provides solder pads for external power cables, as shown in Figure 3-2. The input voltage ranges from 3.4V to 4.2V and a 3.8V regulated power source is recommended. Copyright © Neoway Technology Co., Ltd...
  • Page 10: Communication Connection

    3.2 Communication Connection 3.2.1 M5X0-PWR Board M5X0-PWR board is developed on PL2303 chipset by Neoway and used to convert USB to UART. You can also choose another USB-to-UART cable/board based on FT2232, CP210X, and other chipsets. M5X0-PWR is connected to the N51 EVB through 4-pin cables, which have been soldered to the power board in a sequence of red, black, yellow, and green at one end and should be inserted into the plug of the EVB at the other end.
  • Page 11: Micro-Usb Cable

    3.8V 3.2.2 Micro-USB Cable A micro-USB cable is used to connect N51 to a computer for USB or serial communication. Figure 3-3 USB cable Copyright © Neoway Technology Co., Ltd...
  • Page 12: Commissioning

    Hold the PWRKEY_N button for 5 seconds, and the module starts up. Step 2: Install the PL2303 driver. Obtain the driver package from Neoway FAE or download it from the Internet if you use the serial-to-USB cable Neoway provided. Step 3: Start the Neo_ComTool and send AT commands.
  • Page 13: Through Usb Port

    Hold the PWRKEY_N button for 5 seconds, and the module starts up. Step 2: Install the N51 USB drivers on your computer. Decompress the N51 tool package that Neoway provides. Open the folder of the driver for your OS. Double-click DPInst.exe and install the drivers by following the installation Wizard.
  • Page 14 About This Document If any driver fails to be installed, update it in Device Manager. ⚫ If the driver still cannot be installed, contact Neoway FAE. ⚫ Step 3: Start the Neo_ComTool and send AT commands. Copyright © Neoway Technology Co., Ltd...
