Electrical Data

Table 2. Electrical data
Size Rated Voltage
200-230/60/3
20 460/60/3
575/60/3
200-230/60/3
30 460/60/3
575/60/3
200-230/60/3
45 460/60/3
575/60/3
200-230/60/3
55 460/60/3
575/60/3
200-230/60/3
65 460/60/3
575/60/3
200-230/60/3
75 460/60/3
575/60/3
200-230/60/3
85 460/60/3
575/60/3
Notes:
1. Use copper conductors only.
2. Local codes may take precedence.
3. Voltage Utilization Range: ± 10% of rated voltage. Rated voltage (use range): 200-230/60/3 (180-253), 460/60/3 (414-506), 575/60/3 (517-632).
10
Compressor
# of
Refrigerant Nominal
Qty Circuits Tons
2 1 or 2 10/10
2 1 or 2 15/15
2 1 or 2 20/20
2 1 or 2 25/25
2 1 or 2 30/30
2 1 or 2 30/40
2 1 or 2 40/40
Minimum
RLA LRA Circuit
(each) (each) Ampacity
39 267 88
19 142 42
15 103 35
48 351 108
25 197 56
22 135 50
67 485 151
33 215 74
26 175 59
82 560 185
40 260 89
29 210 65
109 717 245
51 320 114
38 235 87
109/122 717/1010 261
51/68 320/344 136
38/46 235/327 95
122 1010 274
68 344 153
46 327 102
Wiring
Max Fuse Recommended Dual
Size Element Fuse Size
125 100
60 50
50 40
150 125
80 60
70 60
200 175
100 80
80 70
250 225
125 100
90 70
350 250
150 125
125 100
300 300
200 150
125 110
350 300
200 175
125 125
