  • Page 1 WARRANTY OWNERS MANUAL PROFESSIONAL 2200W - 530MM BANDSAW BS-530C...

  • Page 2: Table Of Contents

    TABLE OF CONTENT SPECIFICATIONS ........................1 WARNINGS ..........................2 SAFETY INSTRUCTION FOR MACHINERY ..............3 IDENTIFICATION ........................4 FRONT SIDE OF BAND SAW ....................4 REAR OF BAND SAW ......................5 OPERATING INSTRUCTION ....................6 LIFTING AND PLACING ......................6 ASSEMBLING ..........................

  • Page 3: Specifications

    1. SPECIFICATIONS Horse Power Power Requirement 230V, 1PH, 50HZ CE and Emergency Stop Switch Switch Cutting Height 12"(300mm) Max. Cutting Width 20-1/4"(514mm) Max. Cutting (with Rip Fence) 18-5/8"(474mm) Saw Blade (L) 152"/3865mm Saw Blade (W) 3/8" to 1" (Standard 3/4") Saw Blade Speed 1220/580 M/min Table Size...

  • Page 4: Warnings

    2. WARNINGS Misuse of this machine can cause serious injury. Misuse of this machine can cause serious injury. Never leave machine runn unning while you are away from it. − − Always shut off the mach chine when not in use. For safety, machine must be set up, use ed and serviced −...

  • Page 5: Safety Instruction For Machinery

    GENERAL ELECTRICAL CAUTIONS Caution: This saw should be grounded in accordance with the National For circuits which are far away from the electrical Electrical Code and local codes and ordinances. This work should service box, the wire size must be increased in order to deliver be done by a qualified electrician.

  • Page 6: Identification

    4. IDENTIFICATION Throughout this document, we make reference to various systems Where detailed illustrations for various subsystems will be helpful, and components on the saw. The two illustrations on these pages will you will find these illustrations accompanying the specific teat for provide you with an overall frame of reference for the location and each subsystem and its components.

  • Page 7: Rear Of Band Saw

    REAR OF BAND SAW...

  • Page 8: Operating Instruction

    OPERATING INSTRUCTION OPERATING INSTRUCTION LIFTING AND PLACING Place lifting hook through eye bolt. (see Figure 1) Place lifting hook through eye bolt. (see Figure 1) Use a 2,000KGS wrecker to hang up the machine Use a 2,000KGS wrecker to hang up the machine Eye Bolt Eye Bolt to suitable place.

  • Page 9: Assembling Rip Fence

    ASSEMBLING RIP FENCE 1. Install the fence rail to the table. Use (1) two Fence Tube M6 spring washers (2) two M6 hex head bolts (3) two M6 flat washers.(see Figure 6) 2. Place fence base on fence rail. Slide the fence Fence Rail on its guides until it is the required distance from the blade.

  • Page 10: Adjusting Upper Blade Guide Assembly

    ADJUSTING UPPER BLADE GUIDE ASSEMBLY 1. Set the bearing of upper and lower blade guide within approx. 0.5mm of the blade. Make sure the bearing and the back of the blade approx. 0.5mm. Figure 10 (see Figure 10 and Figure 11) 2.

  • Page 11: Safety Device

    SAFETY DEVICE Limit switch (see Figure 14) inside the machine body for cutting off the power while door opening during operation. Figure 14 The emergency stop (see Figure 15) can help you stop the machine immediately once dangerous situation happens. Figure 15 REMINDER Once completing assembly, please test run the machine to ensure it is properly connected to power...

  • Page 12: Mechanical Brake Switch Operating Instruction

    MECHANICAL BRAKE SWITCH OPERATING INSTRUCTION 1. To start the machine: turn the switch to “2” position, press “ON” button to start the machine. 2. To change the saw blade: turn machine off, turn the switch to “1” position to change the blade.
  • Page 13 TABLE PARALLEL ADJUSTMENT Insert table pin into the table groove.(Figure 16) Figure 16 Use the ruler gauge to put it on the table. (Figure 17) Adjust the position of table pin (adjust the depth of the pin) and adjust the parallel of the table by using the feller gauge.

  • Page 14: Wiring Diagram

    6. WIRING DIAGRAM...

  • Page 15: Parts List

    7. PARTS LIST MODEL NO. BS-530C...
  • Page 23 Tools & Machinery Maxis Distribution Pty Ltd ABN 93 605 273 989 info@maxis.com.au Phone: 1300 767 366 International: +61 3292 0392 128 Ingleston Road, Wakerley Queensland Australia 4154 www.maxis.com.au...
