Product overview

1.2.3 Rear camera

Security LED
Indicates that the video is being recorded.
Depending on the laws and regulations of the country, the security LED specifications may be different.

1.2.4 IR camera

10
Adhesive mount
Used to fix the rear camera in the vehicle.
Rear camera lens
Records the rear view.
IR LED
Used to release IR lights in the night or dark places.
Adhesive mount
Used to fix the IR camera in the vehicle.
IR camera lens
Records IR view.
Connection port
Used to connect the rear
camera to the front camera
using a rear camera cable.
Connection port
Used to connect the IR camera
to the front camera using a IR
camera cable.
