Connection Diagram

Before initial setup, follow the steps below to connect your camera.
1. Connect the camera to a LAN port on your router with an Ethernet cable.
2. Use the power adapter provided to power on the camera.
Router
Network Cable
NOTE:
For PoE PTZ Camera, you may also connect the camera to a PoE
Switch/Injector or Reolink PoE NVR. (The PoE Switch/Injector and
Reolink PoE NVR are not included in the package)
5 English
PTZ Camera
Power Adapter
Power Cable

Set up the Camera

Download and launch the Reolink App or Client software and follow the
onscreen instructions to finish initial setup.
• On Smartphone
Scan to download the Reolink App.
NOTE:
• If you are connecting the PoE camera to a Reolink PoE NVR, please set
up the camera via the NVR interface.
• If you are setting up a WiFi PTZ camera, you need to follow the
onscreen instructions to finish the WiFi configuration first.
English 6
