Installation

For box contents, please refer to the printed contents sheet or setup manual provided in the box.
The accessories included depends on the location where the monitor was shipped.

Attach the base to the LCD monitor stand

1. Place the monitor face down on a non-abrasive surface (Figure 1).
2. Please rotate the monitor stand 90 degrees as shown in Figure 1.
CAUTIOON
Please refer to


3. Attach the base to the stand, then tighten the screw at the base's
bottom (Figure 2).
OOTEN
Reverse this procedure if you need to re-pack the monitor.



AROIONN
Please refer to

Connect the power cord and signal cables

Please connect the power cord and signal cables to the monitor (see

Adjustable Stand with Pivot Capability

Hold the monitor on each side and adjust the screen position as desired.
For screen rotation (pivot), hold the monitor on each side, lift to its maximum height and turn it from landscape to portrait.
Rotation, Raise and Lower
CAUTIOON: Please refer to


"CAUTION 6".
"WARNING 8".
Tilt and Swivel
"CAUTION 6" and "CAUTION
90°
Figure 1
page 14).
9".
English−16
Figure 2
CAUTIOON
Screw
