R-net parameters

Some R-net parameters need to be set for correct usage of the mo-vis R-net joysticks. For
this we refer to the Curtiss-Wright manual SK77981-14 | R-net Technical Manual | Chapter
3 - Progamming
R-net (Ch. 3 - 4.4):Profile Management > Input Device Type:
• In most cases, this parameter needs to be set to Universal for all mo-vis joysticks.
• In combination with certain other devices (e.g. Scoot Control), it is advised to set this
parameter to JSM. Please refer to the Installation manual of the other devices for
more information.
NOTE:
If you have several input devices of the same type, please refer to the
Curtiss-Wright manual SK77981-14 | R-net Technical Manual | Chapter 3 -
Programming to install as Input Device Subtype.
R-net (Ch. 3 - 7.5): Controls > Global > Profile Button: the default setting of this parameter
is Profiles. If you want access to the modes for control of other wheelchair functionalities,
such as seating positions, etc., then you have to select Profiles/Modes.

R-net trip codes

TROUBLE:
When a fault is detected by the device, an R-net trip code will be generated. The
trip code will be shown on the joystick (if it is present and equipped with a graphic
display). The trip code will also be logged in the R-net system and can be investigated
using the R-net PC Programmer.
If you want to learn more about trip codes, see the Curtiss-Wright manual |
SK77981-14 R-net Technical Manual.

Supported R-net parameters

The following R-net parameters of the wheelchair electronics may or may not be supported
by the mo-vis joysticks.
PARAMETER
Momentary screens enabled
Change profile while driving
Change speed while driving
32
SUPPORTED
Global parameter
N
N
N
FIRMWARE
VERSION
