Testing

After installation of the device, execute the following tests before the wheelchair is
delivered or put into service, in according order:
1 Check the device for intactness on page 24
2 Operational test on page 24
3 Test drive on page 25
4 Stop test on page 25

Check the device for intactness

Check whether:
• The device is not bent or damaged.
• Housing, cabling and all connectors are not damaged.
• The device returns to its default position when moving and releasing the joystick
forward, backward, left and right.

Operational test

CAUTION: Execute this test only on a level surface, with at least one metre of free
space around the wheelchair.
CAUTION: The wheelchair may start to move during the test.
1 Activate the wheelchair operating system.
2 Check for any error message.
TROUBLE:
Connection on page 30
3 Move the joystick slowly forward until you hear the parking breaks switch off.
4 Immediately release the joystick. You should hear the parking break react within a few
seconds.
5 Repeat 3 and 4 three times, while slowly moving the joystick towards you, to the left
and to the right.
6 Check whether the power on/off (pwr) and mode (in) switch function properly.
24
for more information on the error messages, see
and R-net Joystick Connection on page 31
