R-net Joystick Connection
Purpose
An R-net joystick has a communication cable with an R-net connector. The cable can be
directly plugged into the R-net electronics of the wheelchair. The joystick then controls the
wheelchair in all its functions (driving, electric gears ...).
For more information about the R-net system, please refer to the Curtiss-Wright website
http://www.cw-industrialgroup.com
Connecting the R-net communication cable
To connect the communication cables, insert the connector into its mate and push firmly.
The connector is inserted correctly if the yellow pins are completely invisible. The
connectors are secured using a friction system.
A
not connected
B
correctly connected
C
incorrectly connected
To disconnect the communication cables, firmly hold the connector housing and pull the
connectors apart.
NOTE:
Pull the connector apart in a straight line to not damage the connection pins.
