Error codes

TROUBLE:
When a fault occurs, the LED of the joystick will start to flash. A long delay is followed
by a number of flashes with a short delay. Count the number of flases and look up
the according error message in the table below.
We have two categories:
• Warnings: LED will flash in orange. A warning can be resolved quite easily (see table
below).
• Errors: LED will flash in red. An error might indicate a more serious issue and/or the
device will have to come back to mo-vis.
FLASH COUNT
1
2
7
28
LED
Orange
Orange
Red
REASON
There is an issue
with a safety switch
connected to the
device. This can only
occur when Switch
type is set to Safety
switch.
This parameter is
only relevant when
Tilt is set to On.
When the joystick
is tilted in an angle
greater than the
configured Angle,
this warning will be
given and you will
not be able to drive.
Miscellaneous
Foot Control Installation manual
REQUIRED ACTION
You have pro-
grammed a safety
switch, but the sys-
tem cannot detect
one. Check if you
have connected a
safety switch and if
you have set it up
like that (e.g. dip
switch positions in
the Twister Pro).
Check if the safety
switch is still func-
tional (no broken
cable or in short-cir-
cuit).
This is normal
behaviour. The
warning will go
away when the joy-
stick is brough back
to an angle that is
less than the config-
ured Angle for Tilt
and you will be able
to drive again.
Contact mo-vis
