CP 442-1 RNA
SIMATIC NET
S7-400 - Industrial Ethernet
CP 442-1 RNA
Equipment Manual
Manual Part B
03/2022
C79000-G8976-C318-05
Preface
Application and functions
Performance data
Requirements for use
LEDs
Installation, wiring,
commissioning, removal
Configuration and
operation
Diagnostics and
maintenance
Technical specifications
Approvals
PRP-compatible devices
Documentation references
1
2
3
4
5
6
7
8
9
A
B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIMATIC NET CP 442-1 RNA and is the answer not in the manual?

Questions and answers

Related Manuals for Siemens SIMATIC NET CP 442-1 RNA

Summary of Contents for Siemens SIMATIC NET CP 442-1 RNA

  • Page 1 CP 442-1 RNA Preface Application and functions SIMATIC NET Performance data Requirements for use S7-400 - Industrial Ethernet CP 442-1 RNA LEDs Installation, wiring, commissioning, removal Equipment Manual Configuration and operation Diagnostics and maintenance Technical specifications Approvals PRP-compatible devices Documentation references Manual Part B 03/2022 C79000-G8976-C318-05...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    Preface Legend: ① X = Placeholder for hardware version ② Firmware version ③ LEDs ④ Ethernet interface: Interface X1P1 with 1 x 8-pin RJ-45 jack ⑤ RNA interface: Ports X2P1 / X2P2 with 2 x 8-pin RJ-45 jacks Designed for a redundant subnet ⑥...
  • Page 4 Current version of the manual and information on the Internet You will find the current version of this document and additional information (e.g. FAQs) on using the CP on the Internet at the following address: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15355) Select the appropriate entry type in the filter settings. Manual on DVD You can find the documentation on the product and the configuration on the "SIMATIC NET...
  • Page 5 Preface Compatibility with other modules - service and maintenance Note Read the information regarding extended functions and restrictions in section Replacing the modules used with CP 442-1 RNA (Page 58) of this manual! Address label: Unique MAC address preset for the CP The CP is supplied with a total of 2 default MAC addresses with the following assignment: •...
  • Page 6 Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers’...
  • Page 7 Preface Device defective If a fault develops, please send the device to your Siemens representative for repair. Repairs on-site are not possible. Decommissioning Shut down the device properly to prevent unauthorized persons from accessing confidential data in the device memory.
  • Page 8 Preface CP 442-1 RNA Equipment Manual, 03/2022, C79000-G8976-C318-05...

  • Page 9: Table Of Contents

    Table of contents Preface ..............................3 Application and functions........................11 Properties of the CP......................11 Communication services ....................12 Network topology with redundancy (PRP) ................13 Further services and characteristics of the CP..............16 Performance data ..........................19 General characteristic data ....................19 Characteristics of S7 communication ..................
  • Page 10 Table of contents Switching over interfaces ....................44 Memory reset / reset to factory defaults ................44 Network settings ....................... 46 6.4.1 Reserved MAC address ....................... 46 6.4.2 Transmission properties of the Ethernet and RNA interfaces ..........46 IP configuration ......................... 48 6.5.1 Setting the IP address......................

  • Page 11: Application And Functions

    Application and functions Properties of the CP Application The CP is intended for use in an S7400 or S7400H (faulttolerant) automation system. It allows the S7400 / S7400H to be connected to Industrial Ethernet. The CP has the following interfaces: •...

  • Page 12: Communication Services

    Application and functions 1.2 Communication services ① Connection to port X1P1 of the Ethernet interface (ISO transport) ② Connection of the RNA interface to a PRP network ③ Connection to port X2P1 of the RNA interface (ISO transport / ISO-on-TCP / TCP) Figure 1-1 CP 442-1 RNA - connection variants Communication services...

  • Page 13: Network Topology With Redundancy (Prp)

    Network topology with redundancy (PRP) Redundant Network Access (RNA) In Siemens Industry, Redundant Network Access (RNA) stands for devices and software that support the redundancy protocol "Parallel Redundancy Protocol" (PRP). RNA allows the connection of devices to redundant Ethernet network structures.
  • Page 14 Application and functions 1.3 Network topology with redundancy (PRP) Parallel Redundancy Protocol (PRP) The Parallel Redundancy Protocol (PRP) is a redundancy protocol for Ethernet networks. It is specified in IEC 62439-3. The areas of application of PRP are distributed applications with high reliability demands that depend on the high availability of the network.
  • Page 15 Application and functions 1.3 Network topology with redundancy (PRP) Connecting up and cabling Each frame duplicate sent using the PRP mechanisms is given in identifier that specifies whether it is sent via LAN A or LAN B. Note Cabling Make sure that all the PRP ports of the nodes and the SCALANCE X204RNA / RUGGEDCOM RS950G on LAN A and LAN B are connected correctly.

  • Page 16: Further Services And Characteristics Of The Cp

    Application and functions 1.4 Further services and characteristics of the CP Example of a configuration for a PRP network The following figure shows the options for connecting devices in a network topology in which the Parallel Redundancy Protocol (PRP) is used. Figure 1-2 Example of the configuration of a network topology with PRP Further services and characteristics of the CP...
  • Page 17 Application and functions 1.4 Further services and characteristics of the CP • SNMP agent on the RNA interface The CP supports data queries over SNMP in version V1 (Simple Network Management Protocol). It delivers the content of certain MIB objects according to the MIB II standard (RFC 1213), PRP-MIB IEC62439 (IEC-62439-3-MIB) and Automation MIB.
  • Page 18 Application and functions 1.4 Further services and characteristics of the CP • Support in the fault-tolerant system (H system) S7 communication is supported in the H system with the following protocols: – Ethernet interface ISO transport – RNA interface ISO transport and ISO-on-TCP (RFC1006) CP 442-1 RNA Equipment Manual, 03/2022, C79000-G8976-C318-05...

  • Page 19: Performance Data

    Performance data General characteristic data Characteristic Explanation / values Total number of connections on Industrial Ethernet The value applies to the total number of connections of the following types: • S7 connections • SEND/RECEIVE connections Example You can, for example, operate the following combination of connections: •...

  • Page 20: Send/Receive Interface

    Performance data 2.3 SEND/RECEIVE interface Note Effects of connections in the SPEED SEND/RECV mode Note the effects of connections on the SEND/RECEIVE interface that are used in the SPEED SEND/RECEIVE mode. The maximum configuration limits of S7 communication are reduced by each configured connection using the SPEED SEND/RECV mode.

  • Page 21: Number Of Simultaneous Send/Receive Calls

    Performance data 2.3 SEND/RECEIVE interface Characteristic Explanation / values Maximum data length for AG_LSEND and AG_LSEND and AG_LRECV allow the transfer of user data with the AG_LRECV program blocks following lengths: 1. ISO-on-TCP, TCP, ISO transport: 1 to 8192 bytes 2.
  • Page 22 Performance data 2.3 SEND/RECEIVE interface Limitation by the CPU In productive operation, the number of SEND/RECEIVE calls that can be used at one time depends on the CPU resources being used. Note the information on the available CPU resources in section System environment (Page 25). The following CPU resources are required: •...

  • Page 23: Characteristics Of Open Tcp/Ip Communication

    Performance data 2.4 Characteristics of open TCP/IP communication Characteristics of open TCP/IP communication Open TCP/IP communication provides a program interface for the transfer of connection- oriented and connectionless services. The establishment and termination of connections is initiated here only via the "dynamic" program interface. The CP supports communication via ISO-on-TCP connections for this interface.
  • Page 24 Performance data 2.5 Characteristic data of TCP connections for HTTP CP 442-1 RNA Equipment Manual, 03/2022, C79000-G8976-C318-05...

  • Page 25: Requirements For Use

    Requirements for use Configuration limits When using the CP type described here, the following limits apply: • Number of operable CPs within a rack: 14 System environment General requirements • The CP is released with CPUs as of firmware version 5.3.2. –...
  • Page 26 Requirements for use 3.2 System environment Order number of the as of firmware a = multiprocessor mode CPU: 6ES7... version b = number of operable CPs c = CPU resources for SEND/RECEIVE jobs d = LOCK/UNLOCK CPU 414-3 PN/DP ..414-3EM05-0AB0 V5.3.2 CPU 414-3 PN/DP ..414-3EM06-0AB0...

  • Page 27: Project Engineering

    You will find information on the current block versions and the current blocks to download from the Internet in our Customer Support under entry ID: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15355/dl) With older module types, this recommendation assumes that you are using the latest firmware for the particular module type.
  • Page 28 Requirements for use 3.4 Program blocks For fast data transmission up to a data length of 1452 bytes, the SPEED SEND/RECEIVE program blocks AG_SSEND (FC53) and AG_SRECV (FC63) are supported. Functionality Requirement Transfer of data fields <= 240 bytes • You require the program blocks AG_SEND (FC5) and AG_RECV (FC6) or alternatively the program blocks AG_LSEND (FC50) and AG_ LRECV (FC60).

  • Page 29: Leds

    LEDs LEDs on the housing front The following LEDs on the front panel show the operating and communication status of the Figure 4-1 LEDs of the CP 442-1 RNA The LEDs have the following meaning: • INTF: Internal error • EXTF: External error •...
  • Page 30 LEDs Table 4- 2 Meaning of the LED displays INTF EXTF BUSxF STOP MAINT CP operating mode (red) (red) (red) (green) (yellow) (yellow) Starting up (STOP->RUN) • Temporary LED pattern during startup (a few seconds) • With permanent LED pattern: Hardware fault in the CP Running (RUN) Stopping (RUN->STOP)
  • Page 31 LEDs INTF EXTF BUSxF STOP MAINT CP operating mode (red) (red) (red) (green) (yellow) (yellow) Loading using the Firmware Loader is active. The firmware download was aborted. (STOP LED and RUN LED flash alternately) Firmware is being activated. Module fault / system error The behavior applies to BUS1F and BUS2F if there is no restriction listed in the "CP mode"...
  • Page 32 LEDs Module identification Note Module identification - make the port LEDs flash briefly With the help of Web diagnostics or the online functions of STEP 7, you can search for and identify the module in the rack. The options for this are as follows: •...

  • Page 33: Installation, Wiring, Commissioning, Removal

    Installation, wiring, commissioning, removal Safety notices on the use of the device Note the following safety notices when setting up and operating the device and during all associated work such as installation, connecting up or replacing the device. Important notes on using the device 5.1.1 Notices on use in hazardous areas WARNING...

  • Page 34: Notes On Use In Hazardous Areas According To Ul Hazloc And Fm

    Installation, wiring, commissioning, removal 5.1 Important notes on using the device WARNING Suitable cables at high ambient temperatures in hazardous area Use heat-resistant cables with an ambient temperature ≥ 60 °C; these cables must be rated for an ambient temperature that is at least 20 °C higher. The cable entries used on the housing must comply with the IP degree of protection required by EN IEC 60079-0 / GB 3836.1.

  • Page 35: Installation, Removal And Repairs In Hazardous Areas

    Installation, wiring, commissioning, removal 5.2 Installation, removal and repairs in hazardous areas Installation, removal and repairs in hazardous areas WARNING Impermissible accessories and spare parts Risk of explosion in hazardous areas • Only use original accessories and original spare parts. •...

  • Page 36: Installing And Connecting

    • Observe the device approvals applicable for your country. WARNING Unauthorized repair of devices in explosion-proof design Risk of explosion in hazardous areas • Repair work may only be performed by personnel authorized by Siemens. Installing and connecting NOTICE Improper mounting Improper mounting may damage the device or impair its operation.
  • Page 37 Installation, wiring, commissioning, removal 5.3 Installing and connecting WARNING Power supply The device is designed for operation with a directly connectable safety extra low voltage (SELV) from a limited power source (LPS). The power supply therefore needs to meet at least one of the following conditions: •...

  • Page 38: Commissioning

    Installation, wiring, commissioning, removal 5.4 Commissioning Commissioning 5.4.1 Commissioning - procedure The steps for commissioning the CP are explained below. Commissioning involves the addressing and downloading the configuration data and user programs. Result: The CP is reachable in the network and has been supplied with configuration data. Follow the steps outlined below: 1.

  • Page 39: Disassembly

    Installation, wiring, commissioning, removal 5.5 Disassembly Change from RUN to STOP: The CP changes to STOP (transitional phase with LED display "Stopping"). The reaction is as follows in STOP: • Established connections (ISO transport, ISOonTCP, TCP, UDP connections) are terminated •...
  • Page 40 Installation, wiring, commissioning, removal 5.5 Disassembly CP 442-1 RNA Equipment Manual, 03/2022, C79000-G8976-C318-05...

  • Page 41: Configuration And Operation

    • Do not connect the device directly to the Internet. Operate the device within a protected network area. • Check regularly for new features on the Siemens Internet pages. – You can find information on Industrial Security here: Link: (http://www.siemens.com/industrialsecurity) –...
  • Page 42 Configuration and operation 6.1 Security recommendations Security functions of the product Use the options for security settings in the configuration of the product. These includes among others: • Protection levels – Configure a protection level of the CPU. – Configure the protection level "Status-dependent". •...
  • Page 43 Configuration and operation 6.1 Security recommendations • Make sure that all passwords are protected and inaccessible to unauthorized personnel. See also the preceding section for information on this. • Do not use one password for different users and systems. Protocols Secure and non-secure protocols •...

  • Page 44: Switching Over Interfaces

    Configuration and operation 6.2 Switching over interfaces Switching over interfaces The choice of the interface to be used, RNA interface or Ethernet interface is made in the configuration of the CP. Each configuration or changeover of the interface therefore requires that the configuration data is downloaded again.
  • Page 45 Configuration and operation 6.3 Memory reset / reset to factory defaults How to use the functions You can start the memory reset functions in STEP 7. The CP must be in STOP. When you reset memory using special diagnostics, the CP is automatically changed to STOP. •...

  • Page 46: Network Settings

    Configuration and operation 6.4 Network settings Network settings 6.4.1 Reserved MAC address NOTICE Do not use the MAC address Internally, the CP uses the following reserved MAC address: 00-1B-1B-31-4D-00 Do not use this MAC address for communications partners of the CP, otherwise no communication is possible with the communications partner.
  • Page 47 Configuration and operation 6.4 Network settings STEP 7 special diagnostics and Web diagnostics display the network setting Diagnostics of the port settings for the CP described here is possible using the entries in the diagnostics buffer using SNMP, special diagnostics, and the LED displays. You will find information on the currently used network settings in STEP 7 as follows: •...

  • Page 48: Ip Configuration

    Configuration and operation 6.5 IP configuration IP configuration 6.5.1 Setting the IP address You can only assign the CP an IP address in the factory settings status. To be able to assign an already configured CP a new IP address via SINEC PNI or the STEP 7 function "Edit Ethernet node", you will need to reset it to factory settings.

  • Page 49: Time-Of-Day Synchronization

    Configuration and operation 6.6 Time-of-day synchronization Time-of-day synchronization General rules On the RNA interface, the CP supports the following two modes for timeofday synchronization: • SIMATIC mode • NTP mode (NTP: Network Time Protocol) Note No automatic changeover to daylight saving is defined in NTP. As a result, you may need to implement this changeover using a program application.

  • Page 50: Snmp Agent

    Configuration and operation 6.8 SNMP agent Remedy Note the following recommendations: • Do not call communication program blocks cyclically in OB1! Instead, call up communication time-controlled in a suitable time OB. The call interval of this OB should be significantly higher than the average cycle time of OB1. •...
  • Page 51 Configuration and operation 6.8 SNMP agent • ICMP • TCP • UDP • SNMP The other groups of the MIB II standard are not supported: • EGP • Transmission • at The CP also supports the Automation System MIB and the PRP-MIB (IEC-62439-3-MIB). Exceptions / restrictions: •...

  • Page 52: Interface In The User Program

    MIB files for your SNMP tools If you use an SNMP tool, you will find the MIB files relevant to the CP in the STEP 7 installation in the following folder: <Drive>\<Installation folder>\Siemens\Step7\S7DATA\snmp\mib There, you will find, for example, the following MIB files: • automationPS.mib •...

  • Page 53: Ping: Permitted Length Of Icmp Packets

    Configuration and operation 6.10 Ping: Permitted length of ICMP packets To allow the user program to exchange data with other TCP/IPcompliant communications partners, STEP 7 provides a UDT for the connection parameter assignment and four program blocks: • UDT 65 "TCON_PAR" with the data structure for connection parameter assignment •...

  • Page 54: Communication In Prp Mode

    Configuration and operation 6.11 Communication in PRP mode 6.11 Communication in PRP mode In PRP mode, the first frame from an unknown node is discarded and remains unanswered. This response must be taken into account with the services that do not generally cause any frame repetitions such as: •...

  • Page 55: Diagnostics And Maintenance

    Diagnostics and maintenance WARNING Cleaning the housing • In hazardous areas Only clean the outer parts of the housing with a damp, but not wet, cloth. • In non-hazardous areas Only clean the outer parts of the housing with a dry cloth. Do not use any liquids or solvents.

  • Page 56: The Cp As Web Server

    Diagnostics and maintenance 7.2 The CP as Web server • STEP 7 Professional In the "Diagnostics" tab in the Inspector window, you will see the following information: – Entries in the diagnostics buffer of the CPU – Information on the online status In the "Online >...

  • Page 57: Loading New Firmware

    Diagnostics and maintenance 7.3 Loading new firmware Web browser To access the HTML pages on the CP, you require a Web browser. The following Web browsers are suitable for communication with the CP (other browsers also possible): • Internet Explorer (recommended version: as of 7.0) •...

  • Page 58: Replacing The Modules Used With Cp 442-1 Rna

    Diagnostics and maintenance 7.4 Replacing the modules used with CP 442-1 RNA Follow the steps outlined below: 1. Connect the CP module to the PG/PC via a LAN cable. 2. Start the download on your PG/PC using one of the firmware download functions described above.
  • Page 59 Diagnostics and maintenance 7.4 Replacing the modules used with CP 442-1 RNA When replacing modules, the following module types can be considered: • CP 443-1 EX20 / EX30 Taking into account the following information, the range of functions of the replaced module will continue to be supported with the specified restrictions.

  • Page 60: Replacing A Module Without A Programming Device

    Diagnostics and maintenance 7.5 Replacing a module without a programming device Replacing a module without a programming device General procedure The configuration data of the CP is stored on the CPU. This makes it possible to replace this module with a module of the same type (identical order number) without a PG. Note Configured MAC address is adopted When setting the ISO protocol, remember that MAC address set previously during...

  • Page 61: Technical Specifications

    Technical specifications Technical specifications Attachment to Industrial Ethernet Number 1 x Ethernet interface 1 x RNA interface with 2 ports Design of the Ethernet interface Connector 1 x RJ-45 jacks Transmission speed 10 / 100 Mbps half duplex or full duplex Design of the RNA interface Connector 2 x RJ-45 jacks...
  • Page 62 Technical specifications For further data, refer to section Performance data (Page 19) In addition to this, all the information in the S7-400/M7-400 reference manual "Module Data" /10/ (Page 75) in the section "General Technical Specifications" on the topics listed below applies to the CP •...

  • Page 63: Approvals

    You will find the declarations of conformity listed below and certificates of the product on the Internet at the following address: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15355/cert) You can see the current versions of the standards in the relevant certificate, which you will find on the Internet at the address specified above.
  • Page 64 Directive of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment UK Declaration of Conformity Importer UK: Siemens plc Sir William Siemens House Princess Road Manchester M20 2UR The product meets the requirements of the following regulations: •...
  • Page 65 • EN IEC 60079-0 - Explosive atmospheres - Part 0: Equipment - General requirements • EN 60079-7 - Explosive Atmospheres - Part 7: Equipment protection by increased safety 'e' Importer UK: Siemens plc (see above) Classification: Ex na IIC T4 Gc, Certificate no.: 2020322310002625 The product meets the requirements of the following standards: •...
  • Page 66 Approvals RoHS The CP meets the requirements of the following directives: • EU directive 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment. • SI 2012/3032 The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012 Applied standard: EN IEC 63000 c(UL)us...
  • Page 67 SIMATIC NET products are regularly submitted to the relevant authorities and approval centers for approvals relating to specific markets and applications. If you require a list of the current approvals for individual devices, consult your Siemens contact or check the Internet pages of Siemens Industry Online Support: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15351/cert)
  • Page 68 Approvals CP 442-1 RNA Equipment Manual, 03/2022, C79000-G8976-C318-05...

  • Page 69: Prp-Compatible Devices

    PRP-compatible devices PRP-compatible devices The devices listed below are compatible for use in PRP networks. You can process frames with excess length of up to 1532 bytes (oversize frames). Table A- 1 PRP-compatible devices Product Order number Version * SCALANCE XB004-1, unmanaged IE Switch for 10/100 Mbps 6GK5004-1BD00-1AB2 ES: 01 SCALANCE XB004-1LD, unmanaged IE Switch for 10/100 Mbps...
  • Page 70 PRP-compatible devices Product Order number Version * SCALANCE XF204-2, flat, managed IE Switch 6GK5204-2BC00-2AF2 V4.4 SCALANCE X204-2LD, managed IE Switch 6GK5204-2BC10-2AA3 V4.4 SCALANCE X206-1, managed IE Switch 6GK5206-1BB10-2AA3 V4.4 SCALANCE X206-2LD, managed IE Switch 6GK5206-1BC00-2AA3 V4.4 SCALANCE XF206-1 managed IE Switch 6GK5206-1BC00-2AF2 V4.4 SCALANCE X206-2LD, managed IE Switch...
  • Page 71 PRP-compatible devices Product Order number Version * SCALANCE X320-3LDFE, managed IE switch 6GK5320-3BF00-2AA3 V3.7.0 SCALANCE X308-2M , managed IE switch 6GK5308-2GG00-2AA2 V3.7.0 SCALANCE X308-2M TS, managed IE switch 6GK5308-2GG00-2CA2 V3.7.0 SCALANCE X308-2M POE , managed IE switch 6GK5308-2QG00-2AA2 V3.7.0 SCALANCE XR324-12M; MANAGED IE SWITCH, 24 VDC, cable outlet front 6GK5324-0GG00-1AR2 V3.7.0 SCALANCE XR324-12M;...
  • Page 72 PRP-compatible devices CP 442-1 RNA Equipment Manual, 03/2022, C79000-G8976-C318-05...

  • Page 73: Documentation References

    Introduction to the documentation Where to find Siemens documentation • Article numbers You will find the article numbers for the Siemens products of relevance here in the following catalogs: – SIMATIC NET - Industrial Communication / Industrial Identification, catalog IK PI –...
  • Page 74 0 For configuration with STEP 7 / NCM S7 For configuration with STEP 7 / NCM S7 SIMATIC NET Commissioning PC Stations - Manual and Quick Start Configuration Manual Siemens AG Link: (https://support.industry.siemens.com/cs/ww/en/ps/15362/man) SIMATIC Configuring Hardware and Connections with STEP 7 Siemens AG Part of the documentation package "STEP 7 Basic Knowledge"...
  • Page 75 0 S7 CPs On installing and commissioning the CP SIMATIC System and Standard Functions for S7-300/400 - Volume 1/2 Reference manual Siemens AG (Part of the STEP 7 documentation package STEP 7 Basic Knowledge) (Part of the online documentation in STEP 7) Link: (https://support.industry.siemens.com/cs/ww/en/view/109474421)
  • Page 76 0 Establishing and diagnosing an Ethernet network Establishing and diagnosing an Ethernet network /11/ SIMATIC NET Industrial Ethernet System manual Siemens AG • Volume 1: Industrial Ethernet Link: (https://support.industry.siemens.com/cs/ww/en/view/27069465) • Volume 2: Passive network components Link: (https://support.industry.siemens.com/cs/ww/en/view/84922825) /12/ SIMATIC NET...

  • Page 77: Index

    Index " "Interfaces" MIB group, 51 Fault-tolerant system, 11, 18 FETCH/WRITE, 12 Access coordination, 4 Abbreviations/acronyms, 5 Access permissions using community name, 51 Autocrossing mechanism, 46 Glossary, 7 Autocrossover, 11 Automatic setting or individual network settings, 46 Autonegotiation, 11, 47 H communication, 25 H system, 18, 18 High communications load, 49...
  • Page 78 Index Module identification LEDs, 32 S5/S7 addressing mode, 17 STEP 7, 32 S7 connections, 19 Web diagnostics, 32 Number, 19 Module replacement without PG, 60 S7-400, 11 Multicast, 12 S7-400H, 11 Multicomputing mode, 28 Safety notices, 33 SEND/RECEIVE calls, 21 Number operable simultaneously, 21 SEND/RECEIVE connections, 19 Network setup - PRP, 15...
