SIMATIC NET
S7-400 - Industrial Ethernet
CP 443-1 (EX30)
Manual
Manual Part B
03/2019
C79000-G8976-C255-05
___________________
Preface
___________________
Properties and services
___________________
Performance data
___________________
Requirements for use
___________________
LEDs
___________________
Installation and
commissioning
___________________
Configuration and operation
___________________
Diagnostics and upkeep
___________________
Technical specifications
___________________
Certification
___________________
Documentation references
1
2
3
4
5
6
7
8
9
A

Advertisement

Table of Contents
loading

Related Manuals for Siemens SIMATIC NET S7-400

Summary of Contents for Siemens SIMATIC NET S7-400

  • Page 1 ___________________ Preface ___________________ Properties and services ___________________ SIMATIC NET Performance data ___________________ Requirements for use S7-400 - Industrial Ethernet CP 443-1 (EX30) ___________________ LEDs ___________________ Installation and commissioning Manual ___________________ Configuration and operation ___________________ Diagnostics and upkeep ___________________ Technical specifications ___________________ Certification ___________________...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    Preface Legend: X = placeholder for hardware product version Firmware version LEDs PROFINET interface: 2 x 8-pin RJ-45 jack Label with MAC address Validity and product names This description contains information on the following product: ● CP 443-1 Article number 6GK7 443-1EX30-0XE0 ●...
  • Page 4 Preface Firmware version V3.2 Communications processor for SIMATIC S7-400 / S7-400H Product names ● CP In this document, the term "CP" is also used instead of the full product name CP 443-1. ● STEP 7 The name STEP 7 is used for the configuration tool instead of the names STEP 7 V5.5 and STEP 7 Professional.

  • Page 5: Manual, 03/2019, C79000-G8976-C255

    You will find the current version of this document and further information (e.g. FAQs) on using the CP on the Internet at the following address: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15352) Select the appropriate entry type in the filter settings. CP documentation in the Manual Collection (order no. A5E00069051) The "SIMATIC NET Manual Collection"...
  • Page 6 Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers’...
  • Page 7 Preface CP 443-1 (EX30) Manual, 03/2019, C79000-G8976-C255-05...

  • Page 9: Table Of Contents

    Table of contents Preface ..............................3 Properties and services ......................... 13 Properties of the CP ........................ 13 Enhanced functions ........................ 13 Communication services ......................15 Further services and characteristics of the CP ............... 16 Performance data ..........................19 General characteristic data ..................... 19 Characteristics of S7 communication ..................
  • Page 10 Table of contents Effects of protection levels ..................... 48 Configuration in STEP 7 ......................49 Interface configuration ......................49 6.6.1 Fast Ethernet .......................... 49 6.6.2 IP configuration ........................51 6.6.2.1 Points to note about IP configuration ..................51 6.6.2.2 Restart after detection of a duplicate IP address in the network ........... 51 6.6.3 Port configuration with redundant partners ................
  • Page 11 Table of contents Documentation references ........................81 Introduction to the documentation ..................81 On configuring, commissioning and using the CP ..............81 A.2.1 /1/ ............................81 A.2.2 /2/ ............................82 A.2.3 /3/ ............................82 A.2.4 /4/ ............................82 A.2.5 /5/ ............................82 On installing and commissioning the CP ................
  • Page 12 Table of contents CP 443-1 (EX30) Manual, 03/2019, C79000-G8976-C255-05...

  • Page 13: Properties And Services

    Properties and services Properties of the CP Application The CP is intended for use in an S7400 or S7400H (faulttolerant) automation system. It allows the S7400 / S7400H to be connected to Industrial Ethernet. The CP has the following interfaces: ●...
  • Page 14 Properties and services 1.2 Enhanced functions Expanded functions of the older firmware versions V2.1 to V3.0 Functions The following characteristics are new and can be used during configuration with STEP 7, see section Project engineering (Page 30): ● Advanced Web diagnostics; among other things with the following additional options: –...

  • Page 15: Communication Services

    Properties and services 1.3 Communication services Communication services The CP supports the following communication services: ● PROFINET IO controller PROFINET IO allows direct access to PROFINET IO devices over Industrial Ethernet. – Prioritized startup The CP supports prioritized startup. Per PROFINET IO controller, a maximum of 32 PROFINET IO devices can be configured that support prioritized startup.

  • Page 16: Further Services And Characteristics Of The Cp

    Properties and services 1.4 Further services and characteristics of the CP establishment) is always initiated by a SIMATIC S5 or a device from another range / – LOCK/UNLOCK with FETCH/WRITE services (CPU-dependent; see section Requirements for use (Page 27)) ● Open TCP/IP communication Open TCP/IP communication provides a program interface for the transfer of connection- oriented and connectionless services.
  • Page 17 Properties and services 1.4 Further services and characteristics of the CP ● Module access protection To protect the module from accidental or unauthorized access, protection can be configured at various levels. ● IP access protection (IPACL) Using IP access protection gives you the opportunity of restricting communication over the CP of the local S7 station to partners with specific IP addresses.
  • Page 18 Properties and services 1.4 Further services and characteristics of the CP ● Detection of double IP addressing in the network To save you timeconsuming troubleshooting in the network, the CP detects double addressing in the network. The reaction of the CP when double addressing is detected varies as follows: –...

  • Page 19: Performance Data

    Performance data Note Measurements of transmission and reaction times in Ethernet, PROFIBUS and PROFINET networks for a series of configurations can be found on the Internet under entry ID: 25209605 (http://support.automation.siemens.com/WW/view/en/25209605) General characteristic data Characteristic Explanation / values Total number of connections on Industrial Ethernet...

  • Page 20: Characteristics Of S7 Communication

    Performance data 2.2 Characteristics of S7 communication Characteristics of S7 communication S7 communication provides data transfer via the ISO Transport or ISO-on-TCP protocols. Characteristic Explanation / values Total number of S7 connections on Industrial 128 max., Ethernet of those max. 62 H connections LAN interface - data field length generated by CP per protocol data unit sending...

  • Page 21: Send/Receive Interface

    Performance data 2.3 SEND/RECEIVE interface SEND/RECEIVE interface 2.3.1 Characteristic data The SEND/RECEIVE interface provides access to communication using TCP, ISOonTCP, ISO transport, email, and UDP connections. The following characteristics are important: Characteristic Explanation / values Number of SEND/RECEIVE connections TCP connections: 1...64 •...

  • Page 22: Number Of Simultaneous Send/Receive Calls

    Performance data 2.3 SEND/RECEIVE interface Characteristic Explanation / values Maximum data length for the AG_SSEND and AG_SSEND and AG_SRECV allow the transfer of user data with the AG_SRECV program blocks following lengths: 1. ISO-on-TCP, TCP, ISO transport: 1 to 1452 bytes •...
  • Page 23 Performance data 2.3 SEND/RECEIVE interface The following CPU resources are required: ● Per SEND job short (AG_SEND) or long (AG_LSEND): 1 resource ● Per RECEIVE job short (AG_RECV): 1 resource ● Per RECEIVE job long (AG_LRECV): 2 resources ● Per SPEED SEND/RECV job (AG_SSEND, AG_SRECV): 0 resources Limitation by the CP A maximum of 64 SEND/RECEIVE connections can be operated by the CP.

  • Page 24: Characteristics Of Open Tcp/Ip Communication

    Performance data 2.4 Characteristics of open TCP/IP communication The maximum number of SPEED SEND/RECEIVE calls that can be used simultaneously (FC53, FC63) depends only on the CPU (see above). Characteristics of open TCP/IP communication Open TCP/IP communication provides a program interface for the transfer of connection- oriented and connectionless services.

  • Page 25: Characteristic Data Of Tcp Connections For Http

    Performance data 2.6 Characteristic data of TCP connections for HTTP Note Note the following for PROFINET IO: If you use modules with >=32 bytes of input/output data, this can lead to I/O access errors; access errors are entered in the diagnostics buffer of the CPU. These I/O access errors occur during operation only in the "consistent user data"...
  • Page 26 Performance data 2.7 Characteristic data of the integrated 2port switch CP 443-1 (EX30) Manual, 03/2019, C79000-G8976-C255-05...

  • Page 27: Requirements For Use

    Requirements for use Configuration limits When using the CP type described here, the following limits apply: ● Number of operable CPs within a rack: 14 ● Number of CPs operating as PROFINET IO controllers within an S7 station: 4 Note Number of CPs operating as PROFINET IO controllers The number of CPs operating as PROFINET IO controllers depends on the number of CP 4435 Extended modules operating as DP masters in the S7400 station.
  • Page 28 Requirements for use 3.2 System environment Restrictions for CPUs with older firmware versions ● The use of the program blocks AG_SSEND (FC53) and AG_SRECV (FC63) is only possible with CPUs as of firmware version V5.1. ● With CPUs with firmware versions up to and including V5.1, no PROFINET IO operation is possible.
  • Page 29 Requirements for use 3.2 System environment Order number of the as of firmware a = multiprocessor mode CPU: 6ES7... version b = number of operable CPs c = CPU resources for SEND/RECEIVE jobs d = LOCK/UNLOCK e = PROFINET IO CPU 416-2 ..416-2XN05-0AB0 V5.1...

  • Page 30: Project Engineering

    STEP 7 Professional STEP 7 Professional V13 The following are not supported: Innovations of firmware version V3.2 • * You will find the HSP on the Internet pages of Siemens Industry Online Support at the following address: Link: (https://support.industry.siemens.com/cs/ww/en/view/23183356) Programming Program blocks For some communications services, there are preprogrammed program blocks (FCs / FBs) available as the interface in your STEP 7 user program.
  • Page 31 Requirements for use 3.4 Programming Using program blocks for the SEND/RECEIVE interface For data transfer on the SEND/RECEIVE interface, there are program blocks for short and long blocks of data. For fast data transmission up to a data length of 1452 bytes, the SPEED SEND/RECEIVE program blocks AG_SSEND (FC53) and AG_SRECV (FC63) are supported.
  • Page 32 Requirements for use 3.4 Programming CP 443-1 (EX30) Manual, 03/2019, C79000-G8976-C255-05...

  • Page 33: Leds

    LEDs LED display The display on the front panel consists of 10 LEDs that indicate the operating mode and communication status. Figure 4-1 LEDs front panel CP 443-1 (EX30) The LEDs have the following meaning: ● INTF: Internal error ● EXTF: External error ●...
  • Page 34 LEDs INTF EXTF BUSF STOP CP operating mode (red) (red) (red) (green) (yellow) Starting up (STOP->RUN) Running (RUN) Stopping (RUN->STOP) Stopped (STOP) In STOP mode, configuring and per- forming diagnostics on the CP remain possible. STOP with internal error or memory reset.
  • Page 35 LEDs INTF EXTF BUSF STOP CP operating mode (red) (red) (red) (green) (yellow) Loading using the Firmware Loader is active. Note: does not apply to loading via the update center in Web diagnostics. The firmware download was aborted. (STOP LED and RUN LED flash alter- nately) Firmware activation after loading us- ing the Firmware Loader is active.
  • Page 36 LEDs CP communications status / LED display patterns Display Meaning TXD (green) CP sending over Ethernet. Note: Sending over PROFINET IO is not signaled here. RXD (green) CP is receiving over Ethernet. Note: Receiving over PROFINET IO is not signaled here. P1 / P2 Port has no connection over Ethernet.

  • Page 37: Installation And Commissioning

    Installation and commissioning Important notes on using the device Safety notices on the use of the device Note the following safety notices when setting up and operating the device and during all associated work such as installation, connecting up or replacing the device. WARNING Safety requirements for installation The devices are "open equipment"...

  • Page 38: Notices On Use In Hazardous Areas According To Atex / Iecex

    Installation and commissioning 5.1 Important notes on using the device WARNING Power supply The equipment is designed for operation with Safety Extra-Low Voltage (SELV) by a Limited Power Source (LPS). This means that only SELV / LPS complying with IEC 60950-1 / EN 60950-1 / VDE 0805-1 must be connected to the power supply terminals.

  • Page 39: Notices On Use In Hazardous Areas According To Ul Hazloc

    Installation and commissioning 5.2 Installation - procedure WARNING Cable If the cable or conduit entry point exceeds 70 °C or the branching point of conductors exceeds 80 °C, special precautions must be taken. If the equipment is operated in an air ambient in excess of 50 °C, only use cables with admitted maximum operating temperature of at least 80 °C.
  • Page 40 Installation and commissioning 5.2 Installation - procedure Follow the steps outlined below: 1. Turn off the power supply when you have configured the CP for PROFINET IO communication. NOTICE CP as PROFINET IO controller when used with a CPU version < V6.0 When installing the CP for use as a PROFINET IO controller with a CPU version <...
  • Page 41 Installation and commissioning 5.2 Installation - procedure 5. Connect the CP to Industrial Ethernet via one of the RJ45 jacks. You can find examples of network attachments in the general Part A of this manual /2/ (Page 82). 6. Where necessary, connect another component to the remaining free RJ45 jack. Note Autocrossing mechanism - effects on the attachments For small local area networks or for attaching several Ethernet devices, a 2port switch...

  • Page 42: Commissioning - Procedure

    Installation and commissioning 5.3 Commissioning - procedure Commissioning - procedure The steps for commissioning the CP are explained below. Commissioning involves the addressing and downloading the configuration data and user programs. Result: The CP is reachable in the network and has been supplied with configuration data. Follow the steps outlined below: 1.

  • Page 43: Configuration And Operation

    ● Keep the firmware up to date. Check regularly for security updates of the firmware and use them. ● Check regularly for new features on the Siemens Internet pages. – Here you will find information on industrial security: Link: (http://www.siemens.com/industrialsecurity) –...
  • Page 44 Configuration and operation 6.1 Security recommendations Security functions of the product Use the options for security settings in the configuration of the product. These includes among others: ● Protection levels – Configure a protection level of the CPU. – Configure the protection level "Status-dependent". ●...
  • Page 45 Configuration and operation 6.1 Security recommendations ● Make sure that all passwords are protected and inaccessible to unauthorized personnel. See also the preceding section for information on this. ● Do not use one password for different users and systems. Protocols List of available protocols The following is a list of all available protocols and their ports through which the device can be accessed.

  • Page 46: Controlling The Mode

    Configuration and operation 6.2 Controlling the mode ● Authentication Specifies whether the communication partner is authenticated. ● Encryption Specifies whether the transfer is encrypted. Ports of communication partners and routers Make sure that you enable the required client ports in the corresponding firewall on the communications partners and in intermediary routers.

  • Page 47: Recommendation For Use With A High Communications Load

    Configuration and operation 6.3 Recommendation for use with a high communications load Recommendation for use with a high communications load Reason When using the CP described here, the points below will help you to avoid overload situations on your CPU. In particular when you replace an older CP with the CP described here and are then confronted with overload problems, you should check your application for the pitfalls outlined below.

  • Page 48: Effects Of Protection Levels

    Configuration and operation 6.4 Effects of protection levels Effects of protection levels Module access protection on the CP If you enable the protection level "Status dependent" in the CP configuration (“Options” tab), the following actions are only possible when either the CPU or the CP is in the STOP state: ●...

  • Page 49: Configuration In Step 7

    Configuration and operation 6.5 Configuration in STEP 7 Configuration in STEP 7 Configuration in STEP 7 You configure the CP alternatively with the following configuration tools: ● STEP 7 V5 For configuring the security functions, you also require the Security Configuration Tool (SCT).
  • Page 50 Configuration and operation 6.6 Interface configuration Autocrossing mechanism With the autocrossing mechanism integrated in the switch, it is possible to use a standard cable to connect the PC/PG. A crossover cable is not necessary. Note Manual configuration If you have set a port to manual configuration and select the "Disable autonegotiation/autocrossover"...

  • Page 51: Ip Configuration

    Configuration and operation 6.6 Interface configuration ● No reaction to Autonegotiation query with manual configuration Remember that if you configure the CP manually and the "Autonegotiation" option is disabled, it will not react to an autonegotiation query! As a result, a connected partner may not be able to set the required mode and communication will not be ideal.

  • Page 52: Port Configuration With Redundant Partners

    Configuration and operation 6.7 PROFINET IO mode Behavior during operation (CP in RUN) If the CP detects double addressing on the network (new node with an IP address that has already been assigned), a message is generated in the diagnostics buffer and the bus fault LED lights up.

  • Page 53: Reduce The Communication Allocation Reserved For Profinet Io When Operating Alongside Other Services

    Configuration and operation 6.7 PROFINET IO mode 6.7.2 Reduce the communication allocation reserved for PROFINET IO when operating alongside other services. If cyclic data exchange over PROFINET IO is operating at the same time on the same Ethernet subnet, set the communications allocation for PROFINET IO in the properties dialog of the PROFINET IO system to a value <100%.

  • Page 54: Irt Communication: Types Of Synchronization

    For the PROFINET IO devices listed below, you should use the current firmware versions to operate the CP. ● IM151-3PN with order number 6ES7151-3AA20-0AB0 ● IM151-3PN with order number 6ES7151-3BA20-0AB0 You will find the current firmware versions on the Internet under the following entry ID: Link: (https://support.industry.siemens.com/cs/ww/en/view/22810435) CP 443-1 (EX30) Manual, 03/2019, C79000-G8976-C255-05...

  • Page 55: Media Redundancy

    Configuration and operation 6.8 Media redundancy Media redundancy You can use the CP in a ring topology with media redundancy. The CP itself can be redundancy manager. For more detailed information on configuration, refer to the online help of the "Media redundancy"...

  • Page 56: Ip Access Protection With Programmed Communications Connections

    Configuration and operation 6.9 Interface in the user program Special features / restriction Note No use of IP_CONFIG (FB55) when operating the CP with fault-tolerant S7 connections. If you configure fault-tolerant S7 connections via the CP, you cannot use program block IP_CONFIG (FB55) for IP configuration of the CP.

  • Page 57: Open Tcp/Ip Communication

    Configuration and operation 6.9 Interface in the user program 6.9.5 Open TCP/IP communication To allow the user program to exchange data with other TCP/IPcompliant communication partners, STEP 7 provides a UDT for the connection parameter assignment and four program blocks (FBs): ●...

  • Page 58: Time-Of-Day Synchronization

    Configuration and operation 6.10 Time-of-day synchronization 6.10 Time-of-day synchronization General rules The CP supports the two modes explained below for timeofday synchronization: ● SIMATIC mode ● NTP mode (NTP: Network Time Protocol) Note No automatic changeover to daylight saving is defined in NTP. As a result, you may need to implement this changeover using a program application.
  • Page 59 Configuration and operation 6.11 SNMP agent Further information For more detailed information on working with MIB files, refer to the documentation of the SNMP client you are using (example of an SNMP client: SNMP OPC server from SIMATIC NET). You will find more information on the MIB in /5/ (Page 82). Supported MIBs The CP supports the following groups of MIB objects of the standard MIB II according to RFC1213:...

  • Page 60: Ping: Permitted Length Of Icmp Packets

    If you use an SNMP tool, you will find the MIB files relevant to the CP in the STEP 7 installation in the following folder: <Drive>\<Installation folder>\Siemens\Step7\S7DATA\snmp\mib For the Automation System MIB, for example, these are the following files: ● automationPS.mib ●...

  • Page 61: Use In The H System

    Configuration and operation 6.13 Use in the H system 6.13 Use in the H system S7 connections as H connections via ISO-on-TCP - adapting the monitoring time When using the CP in the H system V4.5, you also have the option of creating fault-tolerant S7 connections via ISO-on-TCP.
  • Page 62 Configuration and operation 6.13 Use in the H system CP 443-1 (EX30) Manual, 03/2019, C79000-G8976-C255-05...

  • Page 63: Diagnostics And Upkeep

    Diagnostics and upkeep Diagnostics options Overview of the Diagnostics options The following diagnostics options are available: ● LEDs of the module For information on the LED displays, refer to the section LEDs (Page 33). ● Web diagnostics For information on Web diagnostics using HTTP, refer to the section The CP as Web server (Page 63).

  • Page 64: Replacing Older Modules: Module Replacement / Upgrading

    Diagnostics and upkeep 7.3 Replacing older modules: module replacement / upgrading Diagnostics buffer entries When supplied, diagnostics buffer entries shown on diagnostics pages are always in English. This is not influenced by the language selected for display of the Web pages. How to download other languages to the CP and further information about Web diagnostics can be found in the general Part A of this manual /2/ (Page 82).
  • Page 65 Diagnostics and upkeep 7.3 Replacing older modules: module replacement / upgrading Distinction When replacing existing modules with the module described here, the following variants must be distinguished: ● Replacing a device Describes the situation when an existing module can be replaced with a new module simply by pulling/plugging without changing the configuration.

  • Page 66: Replacing Older Modules: Cps With Configurable Data Management

    Diagnostics and upkeep 7.4 Replacing older modules: CPs with configurable data management Note Replacing modules with IT functions In principle, you can also replace predecessor modules with IT functionality with a CP 443-1 EX30. The IT functionality is then, however, not supported! When operating the CP with CPUs of version V4.x, all functions are supported that were provided by the CP 443-1 EX11.

  • Page 67: Replacing A Module Without A Programming Device

    Diagnostics and upkeep 7.5 Replacing a module without a programming device 3. Save and compile the project. 4. Download the configuration data to the target system again. Variant B: STEP 7 project unchanged If you do not want to use any of the new features, you can replace the module as follows without any further configuration: 1.

  • Page 68: Loading New Firmware

    Diagnostics and upkeep 7.6 Loading new firmware Module replacement: Special feature of IP address assignment from a DHCP server During configuration of the CP you can specify the IP configuration in the properties dialog; one option is to obtain the IP address from a DHCP server. Note Recommendation: Configuring a client ID When replacing modules, remember that the factoryset MAC address of the new module is...

  • Page 69: Memory Reset / Reset To Factory Defaults

    Diagnostics and upkeep 7.7 Memory reset / reset to factory defaults How to download new firmware You can download the firmware via both interfaces of the CP. Note Operation with CPU version < V6.0 Remember that the CPU with version < V6.0 changes to STOP during downloading of the firmware if you are using PROFINET IO communication.
  • Page 70 Diagnostics and upkeep 7.7 Memory reset / reset to factory defaults Note Data on the CP is deleted - CPU data is retained The functions for resetting and resetting to factory defaults described here do not change the configuration data on the CPU! Only the data kept on the CP (flash and RAM areas) is deleted.
  • Page 71 Diagnostics and upkeep 7.7 Memory reset / reset to factory defaults Clear/reset module - effects Following the memory reset, the CP retains the configured MAC address and the IP address. The CP is therefore immediately ready for downloads using the IP address. The configuration data is retained on the CPU.
  • Page 72 Diagnostics and upkeep 7.7 Memory reset / reset to factory defaults CP 443-1 (EX30) Manual, 03/2019, C79000-G8976-C255-05...

  • Page 73: Technical Specifications

    Technical specifications Table 8- 1 Technical specifications of the CP 443-1 Technical specifications Article numbers CP 443-1 6GK7 443-1EX30-0XE0 • • CP 443-1 (conformal coating) 6GK7 443-1EX30-0XE1 • • Attachment to Industrial Ethernet Amount 1 x PROFINET interface with 2port switch Design of PROFINET interface (2port Connector 2 x RJ-45 jacks...
  • Page 74 Technical specifications Technical specifications Design, dimensions and weight Module format Compact module for S7-400, single width Degree of protection IP20 Weight Approx. 700 g Dimensions (W x H x D) 25 x 290 x 210 mm Installation options Mounting in an S7-400 rack Product functions ** * For details, refer to the catalog IK PI, Cabling technology.

  • Page 75: Certification

    Certification Approvals issued Note Issued approvals on the type plate of the device The specified approvals apply only when the corresponding mark is printed on the product. You can check which of the following approvals have been granted for your product by the markings on the type plate.
  • Page 76 Certification Siemens Aktiengesellschaft Division Process Industries and Drives Process Automation DE-76181 Karlsruhe Germany You will find the EC Declaration of Conformity on the Internet at the following address: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15352/cert) > Entry type: "Certificates", certificate type: "EC Declaration of Conformity"...
  • Page 77 You should also note the information in the document "Use of subassemblies/modules in a Zone 2 Hazardous Area" that you will find on the Internet at the following address: Link: (https://support.industry.siemens.com/cs/ww/en/view/78381013) Until 19.04.2016 the CP meets the requirements of the EC Directive:2004/108/EC "Electromagnetic Compatibility”...
  • Page 78 Certification Applied standard: ● EN 50581:2012 c(UL)us Applied standards: ● Underwriters Laboratories, Inc.: UL 508 Listed (Industrial Control Equipment) ● Canadian Standards Association: CSA C22.2 No. 142 (Process Control Equipment) Report / UL file: E85972 (NRAG, NRAG7) cULus Hazardous (Classified) Locations Underwriters Laboratories, Inc.: cULus IND.
  • Page 79 SIMATIC NET products are regularly submitted to the relevant authorities and approval centers for approvals relating to specific markets and applications. If you require a list of the current approvals for individual devices, consult your Siemens contact or check the Internet pages of Siemens Industry Online Support: Link: (https://support.industry.siemens.com/cs/ww/en/ps/15351/cert)
  • Page 80 Certification CP 443-1 (EX30) Manual, 03/2019, C79000-G8976-C255-05...

  • Page 81: Documentation References

    Introduction to the documentation Where to find Siemens documentation ● Article numbers You will find the article numbers for the Siemens products of relevance here in the following catalogs: – SIMATIC NET - Industrial Communication / Industrial Identification, catalog IK PI –...

  • Page 82: A.2.2 /2

    A.2 On configuring, commissioning and using the CP A.2.2 SIMATIC NET S7 CPs for Industrial Ethernet Configuring and Commissioning - configuration manual manual Part A - General Applications Siemens AG Link: (https://support.industry.siemens.com/cs/ww/en/view/30374198) A.2.3 SIMATIC NET Version History/Current Downloads for the SIMATIC NET S7 CPs History document...

  • Page 83: On Installing And Commissioning The Cp

    A.3 On installing and commissioning the CP On installing and commissioning the CP A.3.1 SIMATIC S7 Automation System S7-400, M7-400 Siemens AG ● Installation: Installation manual Link: (https://support.industry.siemens.com/cs/ww/en/view/1117849) ● Module Data: Reference Manual Link: (https://support.industry.siemens.com/cs/ww/en/view/1117740) ● CPU data: Device Manual Link: (https://support.industry.siemens.com/cs/ww/en/view/53385241)

  • Page 84: On Programming (Blocks, Opc)

    ● Programming with STEP 7 (ID: 18652056) ● Configuring Hardware and Connections with STEP 7 (ID: 18652631) ● From S5 to S7, Converter Manual (ID: 1118413) Siemens AG Order number 6ES7 810-4CA08-8AW0 (part of the online documentation in STEP 7) On programming (blocks, OPC) A.5.1...

  • Page 85: For Application And Configuration Of Profinet Io

    A.6 For application and configuration of PROFINET IO A.5.4 /14/ SIMATIC System and Standard Functions for S7-300/400 - Volume 1/2 Reference manual Siemens AG (Part of the STEP 7 documentation package STEP 7 Basic Knowledge) (Part of the online documentation in STEP 7) Link: (https://support.industry.siemens.com/cs/ww/en/view/1214574) A.5.5 /15/...

  • Page 86: On Setting Up And Operating An Industrial Ethernet Network

    A.7 On setting up and operating an Industrial Ethernet network On setting up and operating an Industrial Ethernet network A.7.1 /18/ SIMATIC NET Industrial Ethernet / PROFINET System manual Siemens AG ● Industrial Ethernet Link: (https://support.industry.siemens.com/cs/ww/en/view/60053848) ● Passive network components Link: (https://support.industry.siemens.com/cs/ww/en/view/27069465) CP 443-1 (EX30) Manual, 03/2019, C79000-G8976-C255-05...

  • Page 87: Index

    Index Connection and system diagnostics, 4 Redundancy, 52 Downloads, 5 Safety notices, 37 Service & Support, 6 SIMATIC NET glossary, 6 SIMATIC NET Manual Collection, 5 STEP 7, 4 Fault-tolerant system, 18 FETCH/WRITE Access coordination, 4 FTP services, 4 Training, 6 Glossary, 6 Version history, 5 H system, 18...
