Tankvision
Endress+Hauser
Name
Alarm Status 1
Alarm Status 2
Servo Status
Gauge Status
System Status
Gauge Mode
Extended Gauge Status
Element Temperatures
Element Temperature Status
Type
VT_UI2
(Bit mapped)
VT_UI2
(Bit mapped)
VT_I1
(Bit mapped)
VT_I1
(Bit mapped)
VT_I1
(Bit mapped)
VT_I2
(Bit mapped)
VT_UI2
(Bit mapped
Array of VT_R4
(Max 16)
Array of VT_I1
(Max 16)
Data Items Per Gauge
Properties
Bit 1 = HiHi Alarm
Bit 2 = Hi Alarm
Bit 3 = Lo Alarm
Bit 4 = LoLo Alarm
Bit 5 = Software Roof Alarm
Bit 6 = Software Float Alarm
Bit 7 = Software Diff Alarm
Bit 8 = Move Alarm
Bit 9 = Software HiHi Alarm
Bit 10 = Software Hi Alarm
Bit 11 = Software Lo Alarm
Bit 12 = Software LoLo Alarm
Bit 13 = Soft Temp Hi Alarm
Bit 14 = Soft Temp Lo Alarm
Bit 15 = Soft Hi Flow Alarm
Bit 16 = Soft Lo Flow Alarm
Bit 1 = Lo Density Alarm
Bit 2 = Hi Density Alarm
Bit 3 = Lo Temp Alarm
Bit 4 = Hi Temp Alarm
Bit 5 = Soft Lo Density Alarm
Bit 6 = Soft Hi Density Alarm
Bit 7 = Soft Density Dev Alarm
Bit 8 = Soft Temp Dev Alarm
Bit 9 = Soft Hi Water Alarm
Bit 10 = Soft Lo Water Alarm
Bit 11 = Density Dev Alarm
Bit 12 = Temp Dev Alarm
Bit 13 = Not Used
Bit 14 = Not Used
Bit 15 = Not Used
Bit 16 = Not Used
Bit 1 = Servo Up
Bit 2 = Servo Down
Bit 3 = Stowed / Top Stop
Bit 4 = Bottom Stop
Bit 5 = Off Level
Bit 6 = Water mode
Bit 7 = Testing
Bit 8 = Frozen
Bit 1 Config Command Data Ready
Bit 2 = Config Command Executing
Bit 3 = Gauge Command Data Ready
Bit 4 = Gauge Command Executing
Bit 5 = Gauge Initialisingl
Bit 6 = Fast Scan
Bit 7 = Manual Scan Completed
Bit 8 = Off Scan
Bit 1 = Test/Calibration Passed
Bit 2 = Test/Calibration Failed
Bit 3 = Config Command Failed
Bit 4 = Gauge Command Failed
Bit 5 = Gauge Fault
Bit 6 = Data Available
Bit 7 = Fault Data Available
Bit 8 = General Fault
–
–
Units
–
25
